Cast Handles (Stainless Steel)
- Volume Discount
[Features]·A cast iron handle. ·The mounting hole type is a round hole. [Material]·stainless steel.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Material: EN 1.4301 Equiv.
Surface Treatment: Buffed Finish
Specifications
| Part Number |
| UWSD100 UWASND80 |
| Part Number | L1 | H | h | T | A | W | R | N | Allowable Load (N) | Mass (g) | ||
| Type | L | Through | Countersink | |||||||||
| UWASND | 80 | 96 | 32 | 20 | 6 | 18 | 12 | 20 | 4.5 | 8.5 | 500 | 97 |
| 100 | 116 | 23 | 116 | |||||||||
| 150 | 170 | 46 | 30 | 9 | 22 | 16 | 30 | 6.5 | 12.5 | 301 | ||
| 200 | 220 | 46 | 30 | 9 | 22 | 16 | 30 | 6.5 | 12.5 | 354 | ||
Part Number:
- In order to open the 3D preview, the part number must be fixed.
3D preview is not available, because the part number has not yet been determined.
Loading...
Loading...
Basic information
| Type | U-Shaped / Straight | Mounting Method | Round Hole | Material | EN 1.4301 Equiv. |
|---|---|---|---|---|---|
| Surface Treatment | Buffed Surface |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
