8-50 Series/slot width 10/50x100mm

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.

8-50 Series/slot width 10/50x100mm:Related Image



Specifications

Part Number - L
HFS8-50100 - 800
KHFS8-50100 - 4000
■Configurable Length Extrusions
Type Material Surface Treatment Part Number L
0.5mm Increment
Mass
kg/m
Sectional Area mm2 Cross Sectional Moment of Inertia mm4
ℓx ℓy
HFS EN AC-51400-T5 Equiv. Clear Anodize HFS8-50100 50~4000 5.96 2206 51.67x104 211.19x104
HFS EN AC-51400-T5 Equiv. Black Anodize HFSB8-50100 50~4000 5.96 2206 51.67x104 211.19x104
EFS EN AC-51400-T5 Equiv. Clear Anodize EFS8-50100 50~4000 5.39 1996 53.0x104 211.21x104
EFS EN AC-51400-T5 Equiv. Black Anodize EFSB8-50100 50~4000 5.39 1996 53.0x104 211.21x104
GFS A6061SS-T6 Equiv. Clear Anodize GFS8-50100 50~4000 7 2593 68.08x104 273.12x104
NEFS EN AW-6063-T5 Equiv. Clear Anodize NEFS8-50100 50~4000 5.39 1996 53.0x104 211.21x104
Applicable to 6000mm depending on products.
For some extrusions, MISUMI may be unable to accept the order.
Refer to Information of Special Orders (P.103) and contact the person in charge of Special Orders at MISUMI QCT Center.

■Fixed Length Extrusions (Effective Length 4000mm)
Part numbers beginning with the character "K" indicate Fixed Length Extrusion.
Type Material Surface Treatment Part Number L
mm
Sectional Area mm2 Cross Sectional Moment of Inertia mm4
ℓx ℓy
HFS EN AC-51400-T5 Equiv. Clear Anodize KHFS8-50100 4000 2206 51.67x104 211.19x104
HFS EN AC-51400-T5 Equiv. Black Anodize KHFSB8-50100 4000 2206 51.67x104 211.19x104
EFS EN AC-51400-T5 Equiv. Clear Anodize KEFS8-50100 4000 1996 53.0x104 211.21x104
EFS EN AC-51400-T5 Equiv. Black Anodize KEFSB8-50100 4000 1996 53.0x104 211.21x104
GFS A6061SS-T6 Equiv. Clear Anodize KGFS8-50100 4000 2593 68.08x104 273.12x104
NEFS EN AW-6063-T5 Equiv. Clear Anodize KNEFS8-50100 4000 1996 53.0x104 211.21x104
"Effective Length 4000mm" represents the extrusion with 4000mm or more effective length.
The actual length with extra lengths on ends is more than 4000mm (several tens of mm).
Fixed Length Extrusions need to be cut by users thus the exact length cannot be specified.

Alterations

8-50 Series/slot width 10/50x100mm:Related Image

Part Number:

  • Incomplete part number.
    Please use left hand selections to complete a part number.
Loading...
Part Number
EFS8-50100-[50-4000/0.5]
EFSB8-50100-[50-4000/0.5]
GFS8-50100-[50-4000/0.5]
HFS8-50100-[50-4000/0.5]
HFSB8-50100-[50-4000/0.5]
KEFS8-50100-4000
KEFSB8-50100-4000
KGFS8-50100-4000
KHFS8-50100-4000
KHFSB8-50100-4000
KNEFS8-50100-4000
NEFS8-50100-[50-4000/0.5]
Part NumberStandard Unit PriceVolume DiscountShipping Days?RoHSExtrusion Type Surface Treatment Material L Dimension Fixed, Specified Overall Length L (Effective Length)
(mm)
Overall Length L
(mm)

-

3 Days 10EFS (Lightweight)Clear AnodizeEN AC-51400-T5 Equiv.Configuration-50 ~ 4000

-

3 Days 10EFS (Lightweight)Black AnodizeEN AC-51400-T5 Equiv.Configuration-50 ~ 4000

-

3 Days 10GFS (High Rigidity)Clear AnodizeEN AW-6061-T6 Equiv.Configuration-50 ~ 4000

-

3 Days 10HFS (Standard)Clear AnodizeEN AC-51400-T5 Equiv.Configuration-50 ~ 4000

-

3 Days 10HFS (Standard)Black AnodizeEN AC-51400-T5 Equiv.Configuration-50 ~ 4000

262.70 €

Available 3 Days 10EFS (Lightweight)Clear AnodizeEN AC-51400-T5 Equiv.Stationary4000-

321.41 €

Available 3 Days 10EFS (Lightweight)Black AnodizeEN AC-51400-T5 Equiv.Stationary4000-

318.09 €

Available 3 Days 10GFS (High Rigidity)Clear AnodizeEN AW-6061-T6 Equiv.Stationary4000-

266.02 €

Available 3 Days 10HFS (Standard)Clear AnodizeEN AC-51400-T5 Equiv.Stationary4000-

324.85 €

Available 3 Days 10HFS (Standard)Black AnodizeEN AC-51400-T5 Equiv.Stationary4000-

236.37 €

Available 3 Days 10NEFS (Economy Type)Clear AnodizeEN AW-6063-T5 Equiv.Stationary4000-

-

3 Days 10NEFS (Economy Type)Clear AnodizeEN AW-6063-T5 Equiv.Configuration-50 ~ 4000
