6 Surface Milled Mounting Plates/Brackets

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.

6 Surface Milled Mounting Plates/Brackets:Related Image
6 Surface Milled Mounting Plates/Brackets:Related Image
・Materials
Part NumberMaterialSurface Treatment
TypeMaterial Symbol
HFMDASCEN 1.1191 Equiv.-
SCBBlack Oxide
SCMElectroless Nickel Plating
AMEN AW-5052 Equiv.-
AMWAnodize (Clear)
AMBAnodize (Black)
SUEN 1.4301 Equiv.-
There may be some hanger holes on anodized HFZZA.

Specifications

Part Number-A-B-T-X-V-Y-W-Hole
Specification
Code, Nominal Value
-K-L-H-D-F-S-G-Hole
Specification
Code, Nominal Value
-J

Type-Material Symbol
HFMCC-AMB-A100-B80-T10-X15-V70-Y10-W60-Z6  -L50-H40-D30-F50    -MA6
Part Number0.1mm IncrementXVYWHole SpecificationLFSGHole Specification
TypeMaterial SymbolABTCodeNominal Dia.CodeNominal Dia.
HFMDA SC
SCB
SCM
AM
AMW
AMB
SU
25.0
~
200.0
10.0
~
200.0
3.0
~
30.0
0.1mm IncrementN
M
Z


For the machining dimensions, see Hole Type Selection Chart.
0
(No Hole)
3
4
5
6
8
10
12
14
16
0.1mm IncrementNA
MA
ZF
ZB


For the machining dimensions, see Hole Type Selection Chart.
0
(No Hole)
3
4
5
6
8
10
12
14
16
     For AMW and AMB, T≥5 For SU, T≤25.0

Alterations

6 Surface Milled Mounting Plates/Brackets:Related Image

Part Number:

  • Incomplete part number.
    Please use left hand selections to complete a part number.
Loading...
Part Number
HFMDA-AM-A[25-200/0.1]-B[10-200/0.1]-T[3-30/0.1]
HFMDA-AMB-A[25-200/0.1]-B[10-200/0.1]-T[5-30/0.1]
HFMDA-AMW-A[25-200/0.1]-B[10-200/0.1]-T[5-30/0.1]
HFMDA-SC-A[25-200/0.1]-B[10-200/0.1]-T[3-30/0.1]
HFMDA-SCB-A[25-200/0.1]-B[10-200/0.1]-T[3-30/0.1]
HFMDA-SCM-A[25-200/0.1]-B[10-200/0.1]-T[3-30/0.1]
HFMDA-SU-A[25-200/0.1]-B[10-200/0.1]-T[3-25/0.1]
Part NumberStandard Unit PriceVolume DiscountShipping Days?RoHSMaterial Surface Treatment External Dimension A
(mm)
External Dimension B
(mm)
Plate Thickness t
(mm)

-

5 Days 10Aluminum Alloy 5000 seriesNot Provided25 ~ 20010 ~ 2003 ~ 30

-

10 Days 10EN AW-5052 Equiv.Black Anodize25 ~ 20010 ~ 2005 ~ 30

-

10 Days 10EN AW-5052 Equiv.Clear Anodize25 ~ 20010 ~ 2005 ~ 30

-

5 Days 10EN 1.1191 Equiv.Not Provided25 ~ 20010 ~ 2003 ~ 30

-

7 Days 10EN 1.1191 Equiv.Black Oxide25 ~ 20010 ~ 2003 ~ 30

-

7 Days 10EN 1.1191 Equiv.Electroless Nickel Plating25 ~ 20010 ~ 2003 ~ 30

-

5 Days 10EN 1.4301 Equiv.Not Provided25 ~ 20010 ~ 2003 ~ 25
