Non-Return Valve Check Valve Union Straight
- Volume Discount
· It is possible to retain the pressure from the output side because only air input from one side flows.
· Resin type is low cost and light weight.
· Can be used with piping for vacuum retention and low pressure.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| CVU4-4 |
| CVU6-6 |
| CVU8-8 |
| CVU10-10 |
| CVU12-12 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Effective Sectional Area (mm2) | Effective Sectional Area【classification】 (㎜2) | Applicable Tube Diameter (φ) | |
|---|---|---|---|---|---|---|---|
12.65 € | 1 | 5 Days | 2.7 | 5 or Less | 4 | ||
16.87 € | 1 | Available |
Same day
Stock | 6 | Up to 10 | 6 | |
20.13 € | 1 | Available |
Same day
Stock | 13.5 | Up to 15 | 8 | |
40.96 € | 1 |
Same day
Stock | 32 | Up to 40 | 10 | ||
43.04 € | 1 |
Same day
Stock | 46 | Up to 50 | 12 |
Loading...
Basic information
| Type | Standard | Shape | Union Straight | Main Body Material | Aluminum |
|---|---|---|---|---|---|
| Seal Material | NBR | Input Side, Port Type P | Single-Action Coupling | Output Side, Port Type A | Single-Action Coupling |
| Operating Pressure Range(MPa) | 0::0.9 | No oil treatment | Turbine Oil Application |
Configure
Stock
-
- Show only stock items
Basic Attributes
-
Effective Sectional Area(mm2)
-
Effective Sectional Area【classification】(㎜2)
-
Applicable Tube Diameter(φ)
- 4
- 6
- 8
- 10
- 12
-
Type
- CVU
-
Filter by CAD data type
- 3D
Filter by standard shipping days
-
- All
- Same day
- 5 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
