Vacuum Pad Multistage Bellows VPMB Barb Fitting Type
[Features]
· Supports tilted work and transport of vinyl packages.
· A wide range of pad sizes, pad materials, and holder shapes are available.
· Downsizes holders (A and B types) for existing vacuum pads to save space.
· As is conventionally done, you can change the pad section without removing the holder from the equipment.
· Moreover, it is compatible with the optional fall prevention valve and pad direct attachment type filter.
· Pad holders have been added to applications with "copper-based metal not used" and "reduce ozone concentrations” requirements.
· Copper-based metal is not used for metal parts. HNBR is used for sealing rubber material.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Dimensions
Standard table
| Model code | Pad O.D. ød | Tube I.D. øD | B | L | E | C | Connection config. code |
|---|---|---|---|---|---|---|---|
| VPMB10W[5]-3B[9] | 10 | 2 | 33.5 | 14.5 | 13.4 | 6 | -M4 |
| VPMB10W[5]-4B[9] | 2.5 | 14.9 | 7 | ||||
| VPMB10W[5]-6B[9] | 4 | ||||||
| VPMB20W[5]-3B[9] | 20 | 2 | 46.2 | 25 | 13.4 | 6 | -M6 |
| VPMB20W[5]-4B[9] | 2.5 | 14.9 | 7 | ||||
| VPMB20W[5]-6B[9] | 4 | ||||||
| VPMB30W[5]-3B[9] | 30 | 2 | 59.7 | 38.5 | 13.4 | 6 | |
| VPMB30W[5]-4B[9] | 2.5 | 14.9 | 7 | ||||
| VPMB30W[5]-6B[9] | 4 | ||||||
| VPMB40W[5]-3B[9] | 40 | 2 | 66.2 | 45 | 13.4 | 6 | |
| VPMB40W[5]-4B[9] | 2.5 | 14.9 | 7 | ||||
| VPMB40W[5]-6B[9] | 4 | ||||||
| VPMB50W[5]-3B[9] | 50 | 2 | 77.2 | 56 | 13.4 | 6 | |
| VPMB50W[5]-4B[9] | 2.5 | 14.9 | 7 | ||||
| VPMB50W[5]-6B[9] | 4 |
Units: mm
*[5]: Replaced with Pad rubber material code. Refer to the catalog for details.
*[9]: Replaced with "-S3" for -S3 spec. (Copper alloy free material for metal parts and FKM or HNBR for sealing parts).
*Pad material N, NE, and G are not suitable for use under ozone environment.
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Rubber Group Material | Color | Outer Diameter D (φ) | Height L1 (mm) | Full length B (mm) | Vacuum Outlet Tube Outer Diameter (φ) | |
|---|---|---|---|---|---|---|---|---|---|---|
16.73 € | 1 | 10 Days | NBR which conforms to Food Sanitation Law | Gray | 10 | 14.5 | 33.5 | 3 | ||
16.73 € | 1 | 10 Days | NBR which conforms to Food Sanitation Law | Gray | 10 | 14.5 | 33.5 | 4 | ||
16.09 € | 1 | 10 Days | [Nitrile Rubber] Nitrile Rubber | Black | 10 | 14.5 | 33.5 | 3 | ||
16.09 € | 1 | 10 Days | [Nitrile Rubber] Nitrile Rubber | Black | 10 | 14.5 | 33.5 | 4 | ||
17.66 € | 1 | 10 Days | [Silicone Rubber] Silicone Rubber | [White] White | 10 | 14.5 | 33.5 | 3 | ||
17.66 € | 1 | 10 Days | [Silicone Rubber] Silicone Rubber | [White] White | 10 | 14.5 | 33.5 | 4 | ||
19.09 € | 1 | 10 Days | NBR which conforms to Food Sanitation Law | Gray | 20 | 25 | 46.2 | 4 | ||
19.09 € | 1 | 10 Days | NBR which conforms to Food Sanitation Law | Gray | 20 | 25 | 46.2 | 6 | ||
18.46 € | 1 | 10 Days | [Nitrile Rubber] Nitrile Rubber | Black | 20 | 25 | 46.2 | 4 | ||
18.46 € | 1 | 10 Days | [Nitrile Rubber] Nitrile Rubber | Black | 20 | 25 | 46.2 | 6 | ||
20.43 € | 1 | 10 Days | [Silicone Rubber] Silicone Rubber | [White] White | 20 | 25 | 46.2 | 4 | ||
20.43 € | 1 | 10 Days | [Silicone Rubber] Silicone Rubber | [White] White | 20 | 25 | 46.2 | 6 | ||
19.89 € | 1 | 10 Days | NBR which conforms to Food Sanitation Law | Gray | 30 | 38.5 | 59.7 | 4 | ||
19.89 € | 1 | 10 Days | NBR which conforms to Food Sanitation Law | Gray | 30 | 38.5 | 59.7 | 6 | ||
19.25 € | 1 | 10 Days | [Nitrile Rubber] Nitrile Rubber | Black | 30 | 38.5 | 59.7 | 4 | ||
19.25 € | 1 | 10 Days | [Nitrile Rubber] Nitrile Rubber | Black | 30 | 38.5 | 59.7 | 6 | ||
21.21 € | 1 | 10 Days | [Silicone Rubber] Silicone Rubber | [White] White | 30 | 38.5 | 59.7 | 4 | ||
21.21 € | 1 | 10 Days | [Silicone Rubber] Silicone Rubber | [White] White | 30 | 38.5 | 59.7 | 6 |
Loading...
Basic information
| Pad type | Standard / Holder Set | Pad Type | Multi-stage bellows | Mounting Method | Pad Screw Fixed |
|---|---|---|---|---|---|
| Material | Rubber-Based | Usage Environment | Standard | Mounting Bracket | Fixed Type |
| Vacuum Outlet Direction | Horizontal | Mount Connection Screw | M5 × 0.8 | Fall Prevention Valve | None |
| Direct Attached Filter | None | Metal parts material | Standard Specifications |
Configure
Basic Attributes
-
Rubber Group Material
- Nitrile Rubber
- NBR which conforms to Food Sanitation Law
- Silicone Rubber
- Nitrile Rubber
-
Color
- Black
- Gray
- White
-
Outer Diameter D(φ)
-
Height L1(mm)
-
Full length B(mm)
-
Vacuum Outlet Tube Outer Diameter(φ)
- 3
- 4
- 6
-
Type
- VPMB
-
Filter by CAD data type
- 2D
- 3D
Filter by standard shipping days
-
- All
- 10 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
