Ductile Iron DJ (FCD450+ENP / NBR) 5K / 10K Butterfly Valve (Lever)
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 10DJ-50A |
| 10DJ-65A |
| 10DJ-80A |
| 10DJ-100A |
| 10DJ-125A |
| 10DJ-150A |
| G-10DJ-50A |
| G-10DJ-65A |
| G-10DJ-80A |
| G-10DJ-100A |
| G-10DJ-125A |
| G-10DJ-150A |
| G-10DJ-200A |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Supply Side, Nominal Designation of Pipe Flange | Control Side Nominal The Pipe Flange | Handle Shape | |
|---|---|---|---|---|---|---|---|
101.98 € | 1 | 6 Days | 2B(50A) | 2B(50A) | Lever | ||
110.61 € | 1 | 6 Days | 2 1/2B(65A) | 2 1/2B(65A) | Lever | ||
124.14 € | 1 | 6 Days | 3B(80A) | 3B(80A) | Lever | ||
148.15 € | 1 | 5 Days | 4B(100A) | 4B(100A) | Lever | ||
204.98 € | 1 | 6 Days | 5B(125A) | 5B(125A) | Lever | ||
229.84 € | 1 | 6 Days | 6B(150A) | 6B(150A) | Lever | ||
240.98 € | 1 | 6 Days | 2B(50A) | 2B(50A) | [Other] Lateral Gear | ||
250.82 € | 1 | 6 Days | 2 1/2B(65A) | 2 1/2B(65A) | [Other] Lateral Gear | ||
271.17 € | 1 | 6 Days | 3B(80A) | 3B(80A) | [Other] Lateral Gear | ||
288.25 € | 1 | 6 Days | 4B(100A) | 4B(100A) | [Other] Lateral Gear | ||
368.34 € | 1 | 6 Days | 5B(125A) | 5B(125A) | [Other] Lateral Gear | ||
401.17 € | 1 | 6 Days | 6B(150A) | 6B(150A) | [Other] Lateral Gear | ||
576.48 € | 1 | 6 Days | 8B(200A) | 8B(200A) | [Other] Lateral Gear |
Loading...
Basic information
| Types of Valve | Butterfly Valve | Main Body Material | Cast Iron | Applicable Fluids | Water |
|---|---|---|---|---|---|
| Nominal Pressure | 5K/10K | Supply Side, Connection Type | Wafer | Control Side Connection Types | Wafer |
| Sheet | NBR: Baked Integrated Type | Operation Method | Manual Operation Type |
Configure
Basic Attributes
-
Supply Side, Nominal Designation of Pipe Flange
-
Control Side Nominal The Pipe Flange
-
Handle Shape
- Lever
- Other
-
Type
- 10DJ
- G-10DJ
-
Filter by CAD data type
- 2D
Filter by standard shipping days
-
- All
- 5 Days or Less
- 6 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
