General Purpose Ductile Iron 10K Gate Valve Flange
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 10SMBF-15A |
| 10SMBF-20A |
| 10SMBF-25A |
| 10SMBF-32A |
| 10SMBF-40A |
| 10SMBF-50A |
| 10SMBOF-40A |
| 10SMBOF-50A |
| 10SMBOF-65A |
| 10SMBOF-80A |
| 10SMBOF-100A |
| 10SMBOF-125A |
| 10SMBOF-150A |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Type of Gate Valve | Supply Side, Nominal Designation of Pipe Flange | Control Side Nominal The Pipe Flange | |
|---|---|---|---|---|---|---|---|
110.42 € | 1 | 8 Days | Internal Thread Type | 1/2B(15A) | 1/2B(15A) | ||
115.93 € | 1 | 8 Days | Internal Thread Type | 3/4B(20A) | 3/4B(20A) | ||
158.22 € | 1 | 8 Days | Internal Thread Type | 1B(25A) | 1B(25A) | ||
197.89 € | 1 | 8 Days | Internal Thread Type | 1 1/4B(32A) | 1 1/4B(32A) | ||
237.99 € | 1 | 8 Days | Internal Thread Type | 1 1/2B(40A) | 1 1/2B(40A) | ||
346.72 € | 1 | 8 Days | Internal Thread Type | 2B(50A) | 2B(50A) | ||
350.78 € | 1 | 8 Days | Outside Screw Type | 1 1/2B(40A) | 1 1/2B(40A) | ||
435.49 € | 1 | 8 Days | Outside Screw Type | 2B(50A) | 2B(50A) | ||
530.31 € | 1 | 8 Days | Outside Screw Type | 2 1/2B(65A) | 2 1/2B(65A) | ||
679.31 € | 1 | 8 Days | Outside Screw Type | 3B(80A) | 3B(80A) | ||
806.25 € | 1 | 8 Days | Outside Screw Type | 4B(100A) | 4B(100A) | ||
1,225.58 € | 1 | 8 Days | Outside Screw Type | 5B(125A) | 5B(125A) | ||
1,325.53 € | 1 | 8 Days | Outside Screw Type | 6B(150A) | 6B(150A) |
Loading...
Basic information
| Main Body Shape | Straight | Main Body Material | Grey Casting Ductile | Applicable Fluids | Water / Air / Oil / Gas / Vapor |
|---|---|---|---|---|---|
| Nominal Pressure | 10K | Supply Side, Connection Type | Pipe flange | Control Side Connection Types | Pipe flange |
| Handle Shape | Round-shaped handle | Main Body Lining | N/A | Operation Method | Manual Operation Type |
Configure
Basic Attributes
-
Type of Gate Valve
- Outside Screw Type
- Internal Thread Type
-
Supply Side, Nominal Designation of Pipe Flange
-
Control Side Nominal The Pipe Flange
-
Type
- 10SMBF
- 10SMBOF
-
Filter by CAD data type
- 2D
Filter by standard shipping days
-
- All
- 8 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
