General Purpose Ductile Iron 10K Lift Check Valve Screw-in
- Volume Discount
· Materials: ductile cast iron
· Type: Swing
· Working fluid: water, air, oil, gas
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| 10SF-15A |
| 10SF-20A |
| 10SF-25A |
| 10SF-32A |
| 10SF-40A |
| 10SF-50A |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Supply Side, Plumbing Thread Nominal | Control Side, Plumbing Thread Nominal | |
|---|---|---|---|---|---|---|
33.68 € | 1 | 8 Days | 1/2B(15A) | 1/2B(15A) | ||
54.33 € | 1 | Available | 6 Days | 3/4B(20A) | 3/4B(20A) | |
63.04 € | 1 | 8 Days | 1B(25A) | 1B(25A) | ||
86.93 € | 1 | 8 Days | 1 1/4B(32A) | 1 1/4B(32A) | ||
114.86 € | 1 | 8 Days | 1 1/2B(40A) | 1 1/2B(40A) | ||
149.76 € | 1 | 8 Days | 2B(50A) | 2B(50A) |
Loading...
Basic information
| Type | Lift type | Applicable Fluid | Water / Air / Oil / Gas | Nominal Pressure | 10K |
|---|---|---|---|---|---|
| Main Body | Ductile | Supply Side, Connection Type | Rc | Control Side, Connection Type | Rc |
| Max. Operating Pressure(MPa) | 1.37 |
Configure
Basic Attributes
-
Supply Side, Plumbing Thread Nominal
-
Control Side, Plumbing Thread Nominal
-
Type
- 10SF
Filter by standard shipping days
-
- All
- 6 Days or Less
- 8 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
