Tac Heran

Tac Heran

Uses abrasion resistant rubber for three times the abrasion resistance of TAC SD-A. Conductive for anti-static effects.

PDF

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.

Part Number
25101-38-[1-50/1]
25101-50-[1-50/1]
25101-65-[1-50/1]
25101-75-[1-50/1]
25101-90-[1-50/1]
25101-100-[1-50/1]
25101-125-[1-20/1]
25101-150-[1-20/1]
Part NumberStandard Unit PriceVolume DiscountShipping Days?RoHSNominal Diameter (mm) Outer Diameter
(Ø)
Allowable Bending Radius
(mm)
Nominal Diameter (inch) Allowable Pressure (Normal Temperature)
(MPa)
Length
(m)

-

7 Days 103847.01301 1/20.151 ~ 50

-

7 Days 105060.516520.121 ~ 50

-

7 Days 106575.11952 1/20.121 ~ 50

-

7 Days 107589.621030.101 ~ 50

-

7 Days 1090104.23003 1/20.101 ~ 50

-

7 Days 10100118.433040.101 ~ 50

-

7 Days 10125144.540550.101 ~ 20

-

7 Days 10150172.067560.101 ~ 20

Loading...

  1. 1

Basic information

Applicable Fluid / Usage Water / Powder / Food / Cement / Grains Cutting Service Usage Available Properties Antistatic Performance / Abrasion Resistance / Vacuum
Hose Material Abrasion Resistant Rubber+Hard PVC Mounting Metal Fittings NA Color Black
Use Temperature Range, Suction(°C) -20 – 50 Operating Temperature Range, Delivery Discharge(°C) -20 – 50
