Hybrid axial ball bearings / UKB (KASHIMA KAGAKU)
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | RoHS | I.D. D (φ) | Outer Diameter D (φ) | Width (mm) | The material of a ball | Details about Outer Ring, Inner Ring, Retainer Material | Details of ball material | Nominal Sign (Features, please refer to the catalog) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
34.52 € | 1 | 14 Days | 10 | 10 | 24 | 9 | Ceramic | UHMWPE (Ultra High-Molecular-Weight Polyethylene) | Al2O3 / Alumina | PE | ||
32.63 € | 1 | 14 Days | 10 | 10 | 24 | 9 | Glass | UHMWPE (Ultra High-Molecular-Weight Polyethylene) | Soda-lime glass | PE | ||
29.02 € | 1 | 14 Days | 10 | 10 | 24 | 9 | Plastic | UHMWPE (Ultra High-Molecular-Weight Polyethylene) | PP (Polypropylene) | PE | ||
28.51 € | 1 | 14 Days | 10 | 10 | 24 | 9 | Stainless Steel | UHMWPE (Ultra High-Molecular-Weight Polyethylene) | Stainless Steel (EN 1.4301 Equiv.) | PE | ||
29.19 € | 1 | 14 Days | 10 | 10 | 24 | 9 | Stainless Steel | UHMWPE (Ultra High-Molecular-Weight Polyethylene) | Stainless Steel (EN 1.4401 Equiv.) | PE | ||
63.49 € | 1 | 14 Days | 10 | 10 | 24 | 9 | Ceramic | PEEK (Polyetheretherketone) | Al2O3 / Alumina | PK | ||
61.78 € | 1 | 14 Days | 10 | 10 | 24 | 9 | Glass | PEEK (Polyetheretherketone) | Soda-lime glass | PK | ||
57.66 € | 1 | 14 Days | 10 | 10 | 24 | 9 | Stainless Steel | PEEK (Polyetheretherketone) | Stainless Steel (EN 1.4301 Equiv.) | PK | ||
58.17 € | 1 | 14 Days | 10 | 10 | 24 | 9 | Stainless Steel | PEEK (Polyetheretherketone) | Stainless Steel (EN 1.4401 Equiv.) | PK | ||
106.88 € | 1 | 14 Days | 10 | 10 | 24 | 9 | Ceramic | PEEK (Polyetheretherketone) | Al2O3 / Alumina | PKG | ||
101.04 € | 1 | 14 Days | 10 | 10 | 24 | 9 | Stainless Steel | PEEK (Polyetheretherketone) | Stainless Steel (EN 1.4301 Equiv.) | PKG | ||
101.56 € | 1 | 14 Days | 10 | 10 | 24 | 9 | Stainless Steel | PEEK (Polyetheretherketone) | Stainless Steel (EN 1.4401 Equiv.) | PKG | ||
34.17 € | 1 | 14 Days | 10 | 10 | 24 | 9 | Ceramic | PP (Polypropylene) | Al2O3 / Alumina | PP | ||
32.29 € | 1 | 14 Days | 10 | 10 | 24 | 9 | Glass | PP (Polypropylene) | Soda-lime glass | PP | ||
28.68 € | 1 | 14 Days | 10 | 10 | 24 | 9 | Plastic | PP (Polypropylene) | PP (Polypropylene) | PP | ||
28.34 € | 1 | 14 Days | 10 | 10 | 24 | 9 | Stainless Steel | PP (Polypropylene) | Stainless Steel (EN 1.4301 Equiv.) | PP | ||
28.85 € | 1 | 14 Days | 10 | 10 | 24 | 9 | Stainless Steel | PP (Polypropylene) | Stainless Steel (EN 1.4401 Equiv.) | PP | ||
56.46 € | 1 | 14 Days | 10 | 10 | 24 | 9 | Ceramic | PPS (Polyphenylene sulfide) | Al2O3 / Alumina | PS | ||
54.75 € | 1 | 14 Days | 10 | 10 | 24 | 9 | Glass | PPS (Polyphenylene sulfide) | Soda-lime glass | PS | ||
50.64 € | 1 | 14 Days | 10 | 10 | 24 | 9 | Stainless Steel | PPS (Polyphenylene sulfide) | Stainless Steel (EN 1.4301 Equiv.) | PS | ||
51.15 € | 1 | 14 Days | 10 | 10 | 24 | 9 | Stainless Steel | PPS (Polyphenylene sulfide) | Stainless Steel (EN 1.4401 Equiv.) | PS | ||
61.61 € | 1 | 19 Days | 10 | 10 | 24 | 9 | Ceramic | PTFE (fluoropolymer) | Al2O3 / Alumina | PT | ||
55.60 € | 1 | 19 Days | 10 | 10 | 24 | 9 | Stainless Steel | PTFE (fluoropolymer) | Stainless Steel (EN 1.4301 Equiv.) | PT | ||
56.29 € | 1 | 19 Days | 10 | 10 | 24 | 9 | Stainless Steel | PTFE (fluoropolymer) | Stainless Steel (EN 1.4401 Equiv.) | PT | ||
67.44 € | 1 | 19 Days | 10 | 10 | 24 | 9 | Ceramic | PTFE (fluoropolymer) | Al2O3 / Alumina | PTE | ||
65.55 € | 1 | 19 Days | 10 | 10 | 24 | 9 | Glass | PTFE (fluoropolymer) | Soda-lime glass | PTE | ||
61.61 € | 1 | 19 Days | 10 | 10 | 24 | 9 | Stainless Steel | PTFE (fluoropolymer) | Stainless Steel (EN 1.4301 Equiv.) | PTE | ||
62.12 € | 1 | 19 Days | 10 | 10 | 24 | 9 | Stainless Steel | PTFE (fluoropolymer) | Stainless Steel (EN 1.4401 Equiv.) | PTE | ||
60.92 € | 1 | 19 Days | 10 | 10 | 24 | 9 | Ceramic | PTFE (fluoropolymer) | Al2O3 / Alumina | PTG | ||
59.04 € | 1 | 19 Days | 10 | 10 | 24 | 9 | Glass | PTFE (fluoropolymer) | Soda-lime glass | PTG | ||
55.09 € | 1 | 19 Days | 10 | 10 | 24 | 9 | Stainless Steel | PTFE (fluoropolymer) | Stainless Steel (EN 1.4301 Equiv.) | PTG | ||
55.60 € | 1 | 19 Days | 10 | 10 | 24 | 9 | Stainless Steel | PTFE (fluoropolymer) | Stainless Steel (EN 1.4401 Equiv.) | PTG | ||
51.32 € | 1 | 19 Days | 10 | 10 | 24 | 9 | Ceramic | PTFE (fluoropolymer) | Al2O3 / Alumina | PTN | ||
49.44 € | 1 | 19 Days | 10 | 10 | 24 | 9 | Glass | PTFE (fluoropolymer) | Soda-lime glass | PTN | ||
45.49 € | 1 | 19 Days | 10 | 10 | 24 | 9 | Stainless Steel | PTFE (fluoropolymer) | Stainless Steel (EN 1.4301 Equiv.) | PTN | ||
46.00 € | 1 | 19 Days | 10 | 10 | 24 | 9 | Stainless Steel | PTFE (fluoropolymer) | Stainless Steel (EN 1.4401 Equiv.) | PTN | ||
36.23 € | 1 | 14 Days | 10 | 12 | 26 | 9 | Ceramic | UHMWPE (Ultra High-Molecular-Weight Polyethylene) | Al2O3 / Alumina | PE | ||
34.34 € | 1 | 14 Days | 10 | 12 | 26 | 9 | Glass | UHMWPE (Ultra High-Molecular-Weight Polyethylene) | Soda-lime glass | PE | ||
30.73 € | 1 | 14 Days | 10 | 12 | 26 | 9 | Plastic | UHMWPE (Ultra High-Molecular-Weight Polyethylene) | PP (Polypropylene) | PE | ||
30.39 € | 1 | 14 Days | 10 | 12 | 26 | 9 | Stainless Steel | UHMWPE (Ultra High-Molecular-Weight Polyethylene) | Stainless Steel (EN 1.4301 Equiv.) | PE | ||
30.92 € | 1 | 14 Days | 10 | 12 | 26 | 9 | Stainless Steel | UHMWPE (Ultra High-Molecular-Weight Polyethylene) | Stainless Steel (EN 1.4401 Equiv.) | PE | ||
72.41 € | 1 | 14 Days | 10 | 12 | 26 | 9 | Ceramic | PEEK (Polyetheretherketone) | Al2O3 / Alumina | PK | ||
70.53 € | 1 | 14 Days | 10 | 12 | 26 | 9 | Glass | PEEK (Polyetheretherketone) | Soda-lime glass | PK | ||
66.57 € | 1 | 14 Days | 10 | 12 | 26 | 9 | Stainless Steel | PEEK (Polyetheretherketone) | Stainless Steel (EN 1.4301 Equiv.) | PK | ||
67.09 € | 1 | 14 Days | 10 | 12 | 26 | 9 | Stainless Steel | PEEK (Polyetheretherketone) | Stainless Steel (EN 1.4401 Equiv.) | PK | ||
86.33 € | 1 | 14 Days | 10 | 12 | 26 | 9 | Ceramic | PEEK (Polyetheretherketone) | Al2O3 / Alumina | PKG | ||
82.17 € | 1 | 14 Days | 10 | 12 | 26 | 9 | Stainless Steel | PEEK (Polyetheretherketone) | Stainless Steel (EN 1.4301 Equiv.) | PKG | ||
82.54 € | 1 | 14 Days | 10 | 12 | 26 | 9 | Stainless Steel | PEEK (Polyetheretherketone) | Stainless Steel (EN 1.4401 Equiv.) | PKG | ||
35.54 € | 1 | 14 Days | 10 | 12 | 26 | 9 | Ceramic | PP (Polypropylene) | Al2O3 / Alumina | PP | ||
33.83 € | 1 | 14 Days | 10 | 12 | 26 | 9 | Glass | PP (Polypropylene) | Soda-lime glass | PP | ||
30.22 € | 1 | 14 Days | 10 | 12 | 26 | 9 | Plastic | PP (Polypropylene) | PP (Polypropylene) | PP | ||
29.88 € | 1 | 14 Days | 10 | 12 | 26 | 9 | Stainless Steel | PP (Polypropylene) | Stainless Steel (EN 1.4301 Equiv.) | PP | ||
30.22 € | 1 | 14 Days | 10 | 12 | 26 | 9 | Stainless Steel | PP (Polypropylene) | Stainless Steel (EN 1.4401 Equiv.) | PP | ||
60.58 € | 1 | 14 Days | 10 | 12 | 26 | 9 | Ceramic | PPS (Polyphenylene sulfide) | Al2O3 / Alumina | PS | ||
58.70 € | 1 | 14 Days | 10 | 12 | 26 | 9 | Glass | PPS (Polyphenylene sulfide) | Soda-lime glass | PS | ||
54.75 € | 1 | 14 Days | 10 | 12 | 26 | 9 | Stainless Steel | PPS (Polyphenylene sulfide) | Stainless Steel (EN 1.4301 Equiv.) | PS | ||
55.26 € | 1 | 14 Days | 10 | 12 | 26 | 9 | Stainless Steel | PPS (Polyphenylene sulfide) | Stainless Steel (EN 1.4401 Equiv.) | PS | ||
67.09 € | 1 | 19 Days | 10 | 12 | 26 | 9 | Ceramic | PTFE (fluoropolymer) | Al2O3 / Alumina | PT | ||
74.12 € | 1 | 23 Days | 10 | 12 | 26 | 9 | Ceramic | PTFE (fluoropolymer) | Silicon nitride | PT | ||
61.27 € | 1 | 19 Days | 10 | 12 | 26 | 9 | Stainless Steel | PTFE (fluoropolymer) | Stainless Steel (EN 1.4301 Equiv.) | PT |
Loading...
Basic information
| Bearing Ring Shape | Thrust Ball | Outer Ring, Inner Ring, Retainer Material | Resin | Shield material and shape | Single Shielded |
|---|---|---|---|---|---|
| Outer Ring Type | Flat | Specifications/Environment | Water-Resistant / Non-Magnetic | Load Direction | Axial |
| Number of Bearing Ring Rows | Single Row | Size Standard | Metric System | Shape | Thrust shape |
Configure
Basic Attributes
-
I.D. D(φ)
-
Outer Diameter D(φ)
-
Width(mm)
-
The material of a ball
- Stainless Steel
- Ceramic
- Plastic
- Glass
-
Details about Outer Ring, Inner Ring, Retainer Material
- PEEK (Polyetheretherketone)
- PP (Polypropylene)
- PPS (Polyphenylene sulfide)
- PTFE (fluoropolymer)
- UHMWPE (Ultra High-Molecular-Weight Polyethylene)
-
Details of ball material
-
Nominal Sign (Features, please refer to the catalog)
- PE
- PK
- PKG
- PP
- PS
- PT
- PTE
- PTG
- PTN
-
Type
- UKB51100
- UKB51101
- UKB51102
- UKB51103
- UKB51104
- UKB51105
- UKB51106
- UKB51107
- UKB51108
- UKB51109
- UKB51110
- UKB51200
- UKB51201
- UKB51202
- UKB51203
- UKB51204
- UKB51205
- UKB51206
- UKB51207
- UKB51208
- UKB51209
- UKB51210
- UKB51305
- UKB51306
- UKB51307
- UKB51308
- UKB51309
- UKB51310
Filter by standard shipping days
-
- All
- 14 Days or Less
- 19 Days or Less
- 23 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
