Quick Seal Series Insert-Less Type Connector
[Features]
· Screw-in type.
· 3 parts: fitting unit, nut, and sleeve.
· Guarantees a high flow rate.
· Has no insert, giving it a wider cross-section.
· Only the connectors are sealed, so there is no need to wrap them with sealing tape.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 4A01-2402 |
| 4A01-2602 |
| 4A01-2604 |
| 4A01-2802 |
| 4A01-2804 |
| 4A01-3004 |
| 4A01-3006 |
| 4A01-3208 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Thread Nominal | Compatible Tube Outer Diameter (mm) | Min Inner Diameter | Effective Sectional Area | |
|---|---|---|---|---|---|---|---|---|
1.60 € | 1 | 6 Days | 1/8 | 4 | 2.0 | 3.0 | ||
1.62 € | 1 | 6 Days | 1/8 | 6 | 4.0 | 10.0 | ||
1.96 € | 1 | 8 Days | 1/4 | 6 | 4.0 | 10.0 | ||
2.13 € | 1 | 6 Days | 1/8 | 8 | 5.0 | 18.0 | ||
2.33 € | 1 | 6 Days | 1/4 | 8 | 6.0 | 25.0 | ||
2.38 € | 1 | 8 Days | 1/4 | 10 | 7.5 | 39.0 | ||
2.97 € | 1 | 6 Days | 3/8 | 10 | 7.5 | 39.0 | ||
4.90 € | 1 | 8 Days | 1/2 | 12 | 8.0 | 45.0 |
Loading...
Basic information
| Connection Type | Screw⇔Tube Connection | Thread-to-Tube Connection Type | Connector (Male Thread) | Material | Brass |
|---|---|---|---|---|---|
| Surface Treatment | NA | Screw Type | R | Specifications | Millimeter Size |
Configure
Basic Attributes
-
Thread Nominal
-
Compatible Tube Outer Diameter(mm)
-
Min Inner Diameter
-
Effective Sectional Area
-
Type
- 4A01
-
Filter by CAD data type
- 2D
Filter by standard shipping days
-
- All
- 6 Days or Less
- 8 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
