Strong Spring for High Deflection TU
- Volume Discount
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | RoHS | Max. Load (Secified Range) (N) | Customer-Specified Length (mm) | Outer Diameter (mm) | Coil I.D. ID (mm) | Spring Constant (N/mm) | |
|---|---|---|---|---|---|---|---|---|---|---|
1.81 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 20 | 10.5 | 6 | 5.72 | ||
1.98 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 25 | 10.5 | 6 | 4.57 | ||
2.13 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 30 | 10.5 | 6 | 3.81 | ||
2.30 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 35 | 10.5 | 6 | 3.27 | ||
2.46 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 40 | 10.5 | 6 | 2.86 | ||
3.50 € | 1 | Available |
Same day
Stock | 10 | 73.01 to 107.00 | 45 | 10.5 | 6 | 2.54 | |
2.63 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 50 | 10.5 | 6 | 2.29 | ||
2.72 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 55 | 10.5 | 6 | 2.08 | ||
2.88 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 60 | 10.5 | 6 | 1.91 | ||
3.05 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 65 | 10.5 | 6 | 1.76 | ||
3.11 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 70 | 10.5 | 6 | 1.63 | ||
3.21 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 75 | 10.5 | 6 | 1.52 | ||
3.38 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 80 | 10.5 | 6 | 1.43 | ||
2.30 € | 1 | 5 Days | 10 | 73.01 to 107.00 | 15 | 12.5 | 7 | 8.71 | ||
2.30 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 20 | 12.5 | 7 | 6.53 | ||
2.46 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 25 | 12.5 | 7 | 5.23 | ||
2.46 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 30 | 12.5 | 7 | 4.36 | ||
2.55 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 35 | 12.5 | 7 | 3.73 | ||
2.72 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 40 | 12.5 | 7 | 3.27 | ||
2.96 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 45 | 12.5 | 7 | 2.9 | ||
3.11 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 50 | 12.5 | 7 | 2.61 | ||
3.26 € | 1 |
Same day
Stock | 10 | 73.01 to 107.00 | 55 | 12.5 | 7 | 2.38 | ||
3.38 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 60 | 12.5 | 7 | 2.18 | ||
3.53 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 65 | 12.5 | 7 | 2.01 | ||
3.70 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 70 | 12.5 | 7 | 1.87 | ||
3.86 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 75 | 12.5 | 7 | 1.74 | ||
4.19 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 80 | 12.5 | 7 | 1.63 | ||
4.33 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 90 | 12.5 | 7 | 1.45 | ||
4.65 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 100 | 12.5 | 7 | 1.31 | ||
2.30 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 20 | 14.5 | 8.5 | 8.18 | ||
2.63 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 25 | 14.5 | 8.5 | 6.54 | ||
2.79 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 30 | 14.5 | 8.5 | 5.45 | ||
2.96 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 35 | 14.5 | 8.5 | 4.67 | ||
3.11 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 40 | 14.5 | 8.5 | 4.09 | ||
3.27 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 45 | 14.5 | 8.5 | 3.63 | ||
3.44 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 50 | 14.5 | 8.5 | 3.27 | ||
3.59 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 55 | 14.5 | 8.5 | 2.97 | ||
3.77 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 60 | 14.5 | 8.5 | 2.73 | ||
4.15 € | 1 |
Same day
Stock | 10 | 73.01 to 107.00 | 65 | 14.5 | 8.5 | 2.52 | ||
4.25 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 70 | 14.5 | 8.5 | 2.34 | ||
4.42 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 75 | 14.5 | 8.5 | 2.18 | ||
4.65 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 80 | 14.5 | 8.5 | 2.04 | ||
4.75 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 90 | 14.5 | 8.5 | 1.82 | ||
5.06 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 100 | 14.5 | 8.5 | 1.64 | ||
5.23 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 110 | 14.5 | 8.5 | 1.49 | ||
5.31 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 120 | 14.5 | 8.5 | 1.36 | ||
5.38 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 125 | 14.5 | 8.5 | 1.31 | ||
5.71 € | 1 | 7 Days | 10 | 73.01 to 107.00 | 150 | 14.5 | 8.5 | 1.09 | ||
2.96 € | 1 | 7 Days | 10 | 150.01 to 230.00 | 30 | 17 | 10.5 | 8.17 | ||
3.05 € | 1 | 7 Days | 10 | 150.01 to 230.00 | 35 | 17 | 10.5 | 7 | ||
3.11 € | 1 | 7 Days | 10 | 150.01 to 230.00 | 40 | 17 | 10.5 | 6.13 | ||
3.44 € | 1 | 7 Days | 10 | 150.01 to 230.00 | 45 | 17 | 10.5 | 5.44 | ||
3.59 € | 1 | 7 Days | 10 | 150.01 to 230.00 | 50 | 17 | 10.5 | 4.9 | ||
3.92 € | 1 | 7 Days | 10 | 150.01 to 230.00 | 55 | 17 | 10.5 | 4.45 | ||
4.09 € | 1 | 7 Days | 10 | 150.01 to 230.00 | 60 | 17 | 10.5 | 4.08 | ||
4.25 € | 1 | 7 Days | 10 | 150.01 to 230.00 | 65 | 17 | 10.5 | 3.77 | ||
4.42 € | 1 | 7 Days | 10 | 150.01 to 230.00 | 70 | 17 | 10.5 | 3.5 | ||
4.65 € | 1 | 7 Days | 10 | 150.01 to 230.00 | 75 | 17 | 10.5 | 3.27 | ||
4.75 € | 1 | 7 Days | 10 | 150.01 to 230.00 | 80 | 17 | 10.5 | 3.06 | ||
5.06 € | 1 | 7 Days | 10 | 150.01 to 230.00 | 90 | 17 | 10.5 | 2.72 |
Loading...
Basic information
| Material | Silicon Chrome Steel for Springs |
|---|
Configure
Stock
-
- Show only stock items
Basic Attributes
-
Max. Load (Secified Range)(N)
- 73.01 to 107.00
- 150.01 to 230.00
- 230.01 to 580.00
-
Customer-Specified Length(mm)
-
Outer Diameter(mm)
-
Coil I.D. ID(mm)
-
Spring Constant(N/mm)
- 1.09
- 1.31
- 1.36
- 1.4
- 1.43
- 1.45
- 1.49
- 1.52
- 1.63
- 1.64
- 1.74
- 1.76
- 1.82
- 1.87
- 1.88
- 1.91
- 1.96
- 2.01
- 2.04
- 2.07
- 2.08
- 2.15
- 2.18
- 2.23
- 2.29
- 2.34
- 2.38
- 2.45
- 2.48
- 2.51
- 2.52
- 2.54
- 2.56
- 2.61
- 2.69
- 2.72
- 2.73
- 2.79
- 2.8
- 2.86
- 2.89
- 2.9
- 2.97
- 3.01
- 3.06
- 3.07
- 3.11
- 3.13
- 3.27
- 3.41
- 3.42
- 3.45
- 3.5
- 3.55
- 3.57
- 3.63
- 3.65
- 3.73
- 3.76
- 3.77
- 3.81
- 3.84
- 3.88
- 3.92
- 4.04
- 4.08
- 4.09
- 4.14
- 4.18
- 4.27
- 4.36
- 4.44
- 4.45
- 4.46
- 4.52
- 4.57
- 4.67
- 4.7
- 4.78
- 4.8
- 4.9
- 4.97
- 5.01
- 5.12
- 5.16
- 5.18
- 5.23
- 5.37
- 5.44
- 5.45
- 5.49
- 5.65
- 5.72
- 5.77
- 5.78
- 5.91
- 6.13
- 6.21
- 6.27
- 6.4
- 6.53
- 6.54
- 6.84
- 6.9
- 6.98
- 7
- 7.52
- 7.54
- 7.68
- 7.76
- 8.17
- 8.18
- 8.28
- 8.36
- 8.54
- 8.71
- 8.87
- 8.92
- 9.4
- 9.56
- 9.6
- 9.81
- 10.24
- 10.35
- 10.74
- 10.9
- 10.97
- 11.29
- 11.82
- 12.26
- 12.42
- 12.53
- 12.8
- 13.8
- 13.97
- 14.01
- 15.04
- 15.36
- 15.53
- 16.34
- 17.07
- 17.75
- 19.2
- 19.61
-
Type
- TU10.5
- TU12.5
- TU14.5
- TU17
- TU21
- TU26
- TU31
- TU37
- TU43
Filter by standard shipping days
-
- All
- Same day
- 5 Days or Less
- 7 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
