Quick Seal Series Insert Type (Brass) Female Connector (Inch Size)
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| FC1N1/2-PT3/8 |
| FC1N1/4-PT1/4 |
| FC1N1/4-PT1/8 |
| FC1N3/8-PT1/4 |
| FC1N3/8-PT3/8 |
| FC1N5/16-PT1/4 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Thread Nominal | Compatible Tube Outer Diameter (mm) | Minimum Internal Diameter d2 | Effective Sectional Area | Compatible Tube Outer Diameter (inch) | |
|---|---|---|---|---|---|---|---|---|---|
12.36 € | 1 | 8 Days | 3/8 | 12.7 | 8.2 | 45.0 | 1/2 | ||
2.63 € | 1 | 8 Days | 1/4 | 6.35 | 3.4 | 8.5 | 1/4 | ||
2.05 € | 1 | 8 Days | 1/8 | 6.35 | 3.4 | 8.5 | 1/4 | ||
3.02 € | 1 | 8 Days | 1/4 | 9.53 | 5.7 | 22.5 | 3/8 | ||
4.84 € | 1 |
Same day
Stock | 3/8 | 9.53 | 5.7 | 22.5 | 3/8 | ||
2.75 € | 10 | 8 Days | 1/4 | 7.94 | 4.7 | 16.0 | 5/16 |
Loading...
Basic information
| Connection Type | Screw⇔Tube Connection | Thread-to-Tube Connection Type | Female Connector | Material | Brass |
|---|---|---|---|---|---|
| Surface Treatment | NA | Screw Type | Rc |
Configure
Stock
-
- Show only stock items
Basic Attributes
-
Thread Nominal
-
Compatible Tube Outer Diameter(mm)
-
Minimum Internal Diameter d2
-
Effective Sectional Area
-
Compatible Tube Outer Diameter(inch)
- 1/2
- 1/4
- 3/8
- 5/16
-
Type
- FC1N
-
Filter by CAD data type
- 2D
Filter by standard shipping days
-
- All
- Same day
- 8 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
