Insertion Boss Type Castors 920EK / 915EK Wheel Diameter 75-125mm
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 915EK-FR75 |
| 915EK-FR100 |
| 915EK-FR125 |
| 915EK-PR75 |
| 915EK-PR100 |
| 915EK-PR125 |
| 920EK-FR75 |
| 920EK-FR100 |
| 920EK-FR125 |
| 920EK-PR75 |
| 920EK-PR100 |
| 920EK-PR125 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Mounting Height H or H1 and H2 (mm) | Stopper | Allowable Load 1 piece (daN) | Wheel Dia. D (mm) | Car width (mm) | Swivel Radius (mm) | Eccentricity E or E1, E2 (mm) | V (mm) | Variety of Vehicles | Wheel configuration | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
28.82 € | 1 | 11 Days | 110 | Total Lock Caster | 60 | 75 | 27 | 113 | 32 | 113 | FR | Nylon-Wheel Rubber Winding Wheel with Radial Ball Bearings | ||
34.03 € | 1 | 11 Days | 135 | Total Lock Caster | 50 | 100 | 27 | 125 | 39.0 | 125 | FR | Nylon-Wheel Rubber Winding Wheel with Radial Ball Bearings | ||
43.06 € | 1 | 11 Days | 163 | Total Lock Caster | 50 | 125 | 27 | 125 | 42.0 | 125 | FR | Nylon-Wheel Rubber Winding Wheel with Radial Ball Bearings | ||
27.23 € | 1 | 11 Days | 110 | Total Lock Caster | 40 | 75 | 22 | 113 | 32 | 113 | PR | Iron Plate Wheel Rubber Winding Wheel with Resin Bushing | ||
31.20 € | 1 | 11 Days | 135 | Total Lock Caster | 60 | 100 | 22 | 125 | 39.0 | 125 | PR | Iron Plate Wheel Rubber Winding Wheel with Resin Bushing | ||
38.05 € | 1 | 11 Days | 163 | Total Lock Caster | 60 | 125 | 22 | 125 | 42.0 | 125 | PR | Iron Plate Wheel Rubber Winding Wheel with Resin Bushing | ||
19.75 € | 1 | 11 Days | 110 | NA | 60 | 75 | 27 | 71 | 32 | - | FR | Nylon-Wheel Rubber Winding Wheel with Radial Ball Bearings | ||
24.81 € | 1 | 11 Days | 135 | NA | 50 | 100 | 27 | 90 | 39.0 | - | FR | Nylon-Wheel Rubber Winding Wheel with Radial Ball Bearings | ||
34.22 € | 1 | 11 Days | 163 | NA | 50 | 125 | 27 | 106 | 42.0 | - | FR | Nylon-Wheel Rubber Winding Wheel with Radial Ball Bearings | ||
19.05 € | 1 | 11 Days | 110 | NA | 40 | 75 | 22 | 71 | 32 | - | PR | Iron Plate Wheel Rubber Winding Wheel with Resin Bushing | ||
23.47 € | 1 | 11 Days | 135 | NA | 60 | 100 | 22 | 90 | 39.0 | - | PR | Iron Plate Wheel Rubber Winding Wheel with Resin Bushing | ||
29.63 € | 1 | 11 Days | 163 | NA | 60 | 125 | 22 | 106 | 42.0 | - | PR | Iron Plate Wheel Rubber Winding Wheel with Resin Bushing |
Loading...
Basic information
| Caster Type | Plug Style | Load Range(daN) | 35.01~80.00 | Wheel Material | Rubber |
|---|---|---|---|---|---|
| Fitting Material | Steel | Load Category | Light Load | Axial length L(mm) | 40 |
| Shaft diameter T(mm) | 22 | (Metal Fitting/Main Body) Processing - Finish | Chrome Plating Finish | Swiveling/Fixed | Swiveling |
| Part Number | EK |
Configure
Basic Attributes
-
Mounting Height H or H1 and H2(mm)
-
Stopper
- NA
- Total Lock Caster
-
Allowable Load 1 piece(daN)
-
Wheel Dia. D(mm)
-
Car width(mm)
-
Swivel Radius(mm)
-
Eccentricity E or E1, E2(mm)
-
V(mm)
-
Variety of Vehicles
-
Type
- 915EK
- 920EK
-
Filter by CAD data type
- 2D
- 3D
Filter by standard shipping days
-
- All
- 11 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
