Stainless Steel Castors 320S / 315S Wheel Diameter 50-75mm

Stainless Steel Castors 320S / 315S Wheel Diameter 50-75mm

Click on this image to zoom in.

Click on this image to zoom in.

  • Volume Discount

TAKIGEN(HAMMER CASTER)

TAKIGEN(HAMMER CASTER)

[Features]
· An all-stainless steel caster with excellent corrosion resistance and water resistance.
· Ideal for carts, equipment, etc., that are used in environments where rust and corrosion are unacceptable, such as food factories, shops, offices, etc.
· An all-stainless steel construction with excellent corrosion resistance and water resistance.
· The swivel parts includes two vertically arranged steel balls. load resistance is high, and swiveling is smooth.

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.

Data to be displayed
30
45
60
  1. 1
Part Number
315S-N50
315S-N65
315S-N75
315S-NRB50
315S-NRB65
315S-NRB75
315S-PH50
315S-PH65
315S-PH75
315S-R65
315S-R75
315S-RD50
315S-UB50
315S-UB65
315S-UB75
320S-N50
320S-N65
320S-N75
320S-NRB50
320S-NRB65
320S-NRB75
320S-PH50
320S-PH65
320S-PH75
320S-R65
320S-R75
320S-RD50
320S-UB50
320S-UB65
320S-UB75
Part Number
Standard Unit Price
Minimum order quantityVolume Discount
Standard
Shipping Days
?
Mounting Height H or H1 and H2
(mm) 		Stopper Allowable Load 1 piece
(daN) 		Wheel Material Wheel Characteristics Wheel Dia. D
(mm) 		Car width
(mm) 		Swivel Radius
(mm) 		Eccentricity E or E1, E2
(mm) 		Variety of Vehicles Wheel configuration

23.11 €

1 Available 11 Days 70With Rotation Stopper60[Nylon] NylonAbrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil) / Chemical Resistance (Weak Acids/Alkalis)50256126.0NNylon Integral Wheel

29.29 €

1 5 Days 85With Rotation Stopper70[Nylon] NylonAbrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil) / Chemical Resistance (Weak Acids/Alkalis)65257129.0NNylon Integral Wheel

29.56 €

1 Same day

Stock

93With Rotation Stopper80[Nylon] NylonAbrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil) / Chemical Resistance (Weak Acids/Alkalis)75256828.0NNylon Integral Wheel

28.26 €

1 11 Days 70With Rotation Stopper60[Nylon] NylonAbrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil) / Chemical Resistance (Weak Acids/Alkalis)50256126.0NRBNylon Integral Wheel with Roller Bearings

28.80 €

1 Available 11 Days 85With Rotation Stopper70[Nylon] NylonAbrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil) / Chemical Resistance (Weak Acids/Alkalis)65257129.0NRBNylon Integral Wheel with Roller Bearings

31.36 €

1 Available 11 Days 93With Rotation Stopper80[Nylon] NylonAbrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil) / Chemical Resistance (Weak Acids/Alkalis)75256828.0NRBNylon Integral Wheel with Roller Bearings

26.31 €

1 Available 11 Days 70With Rotation Stopper70PhenolGasoline Resistance / Oil Resistance (Machine Oil) / Chemical Resistance (Weak Acids/Alkalis)50256126.0PHPhenol Integrated Wheel Resin Bushings Built-In

36.23 €

1 14 Days 85With Rotation Stopper70PhenolGasoline Resistance / Oil Resistance (Machine Oil) / Chemical Resistance (Weak Acids/Alkalis)65277129.0PHPhenol Integrated Wheel Resin Bushings Built-In

40.09 €

1 14 Days 93With Rotation Stopper80PhenolGasoline Resistance / Oil Resistance (Machine Oil) / Chemical Resistance (Weak Acids/Alkalis)75276828.0PHPhenol Integrated Wheel Resin Bushings Built-In

30.83 €

1 5 Days 85With Rotation Stopper50Rubber-65267129.0RRubber Integrated Wheels Containing Resin Bush

33.91 €

1 5 Days 93With Rotation Stopper60Rubber-75266828.0RRubber Integrated Wheels Containing Resin Bush

23.90 €

1 11 Days 70With Rotation Stopper50Rubber-50266126.0RDRubber Integrated Wheels Containing Resin Bush

30.00 €

1 Available 11 Days 70With Rotation Stopper60UrethaneAbrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil)50256126.0UBNylon-Wheel Thermoplastic Urethane Foam Winding Wheel with Roller Bearings

40.87 €

1 5 Days 85With Rotation Stopper70UrethaneAbrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil)65277129.0UBNylon-Wheel Thermoplastic Urethane Foam Winding Wheel with Roller Bearings

42.41 €

1 5 Days 93With Rotation Stopper80UrethaneAbrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil)75276828.0UBNylon-Wheel Thermoplastic Urethane Foam Winding Wheel with Roller Bearings

20.42 €

1 Available 6 Days 70NA60[Nylon] NylonAbrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil) / Chemical Resistance (Weak Acids/Alkalis)50255226.0NNylon Integral Wheel

26.21 €

1 5 Days 85NA70[Nylon] NylonAbrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil) / Chemical Resistance (Weak Acids/Alkalis)65256329.0NNylon Integral Wheel

29.29 €

1 5 Days 93NA80[Nylon] NylonAbrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil) / Chemical Resistance (Weak Acids/Alkalis)75256728.0NNylon Integral Wheel

24.29 €

1 Available 11 Days 70NA60[Nylon] NylonAbrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil) / Chemical Resistance (Weak Acids/Alkalis)50255226.0NRBNylon Integral Wheel with Roller Bearings

25.63 €

1 Available 6 Days 85NA70[Nylon] NylonAbrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil) / Chemical Resistance (Weak Acids/Alkalis)65256329.0NRBNylon Integral Wheel with Roller Bearings

28.00 €

1 Available 11 Days 93NA80[Nylon] NylonAbrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil) / Chemical Resistance (Weak Acids/Alkalis)75256728.0NRBNylon Integral Wheel with Roller Bearings

23.05 €

1 Available 11 Days 70NA70PhenolGasoline Resistance / Oil Resistance (Machine Oil) / Chemical Resistance (Weak Acids/Alkalis)50255226.0PHPhenol Integrated Wheel Resin Bushings Built-In

32.37 €

1 14 Days 85NA70PhenolGasoline Resistance / Oil Resistance (Machine Oil) / Chemical Resistance (Weak Acids/Alkalis)65276329.0PHPhenol Integrated Wheel Resin Bushings Built-In

36.23 €

1 14 Days 93NA80PhenolGasoline Resistance / Oil Resistance (Machine Oil) / Chemical Resistance (Weak Acids/Alkalis)75276728.0PHPhenol Integrated Wheel Resin Bushings Built-In

27.75 €

1 5 Days 85NA50Rubber-65266329.0RRubber Integrated Wheels Containing Resin Bush

30.05 €

1 5 Days 93NA60Rubber-75266728.0RRubber Integrated Wheels Containing Resin Bush

20.60 €

1 Available 6 Days 70NA50Rubber-50265226.0RDRubber Integrated Wheels Containing Resin Bush

26.81 €

1 Available 7 Days 70NA60UrethaneAbrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil)50255226.0UBNylon-Wheel Thermoplastic Urethane Foam Winding Wheel with Roller Bearings

37.01 €

1 5 Days 85NA70UrethaneAbrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil)65276329.0UBNylon-Wheel Thermoplastic Urethane Foam Winding Wheel with Roller Bearings

40.09 €

1 5 Days 93NA80UrethaneAbrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil)75276728.0UBNylon-Wheel Thermoplastic Urethane Foam Winding Wheel with Roller Bearings

Loading...

  1. 1

Basic information

Caster Type Swiveling Direct Mount Plate Load Range(daN) 35.01~80.00 Fitting Material Stainless Steel
Mounting Hole Pitch Longitudinal direction (X)(mm) 55 Mounting Hole Pitch Transverse Direction (Y)(mm) 42 Mounting Seat A (Plate Length)(mm) 70
Mounting Seat B (Plate Width)(mm) 58 Load Category Light Load Mounting Hole Diameter P(mm) 8.8
(Metal Fitting/Main Body) Processing - Finish All Stainless Swiveling/Fixed Swiveling Part Number S
