Total Lock Castors for Scaffolding 515SA Wheel Diameter 125-200mm
- Volume Discount
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| 515SA-RB125 |
| 515SA-RB150 |
| 515SA-RB200 |
| 515SA-UB200 |
| 515SA-URB125 |
| 515SA-URB150 |
| 515SA-URB200 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Mounting Height H or H1 and H2 (mm) | Load Range (daN) | Allowable Load 1 piece (daN) | Wheel Material | Wheel Characteristics | Wheel Dia. D (mm) | Car width (mm) | Swivel Radius (mm) | Eccentricity E or E1, E2 (mm) | Variety of Vehicles | Wheel configuration | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
138.78 € | 1 | Available | 11 Days | 171 | 140.01~220.00 | 180 | Rubber | - | 125 | 44 | 112 | 48.0 | RB | Iron Plate Wheel Rubber Winding Wheel with Roller Bearings | |
101.60 € | 1 | Available | 11 Days | 196 | 220.01~320.00 | 230 | Rubber | - | 150 | 46 | 126 | 50.0 | RB | Iron Plate Wheel Rubber Winding Wheel with Roller Bearings | |
111.97 € | 1 | 11 Days | 240 | 220.01~320.00 | 250 | Rubber | - | 200 | 46 | 156 | 55.0 | RB | Iron Plate Wheel Rubber Winding Wheel with Roller Bearings | ||
137.05 € | 1 | Available | 11 Days | 240 | 220.01~320.00 | 250 | Urethane | Abrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil) | 200 | 44 | 156 | 55.0 | UB | Nylon-Wheel Thermoplastic Urethane Foam Winding Wheel with Radial Ball Bearings | |
108.35 € | 1 | Available | 11 Days | 171 | 140.01~220.00 | 180 | Urethane | Abrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil) | 125 | 44 | 112 | 48.0 | URB | Iron Plate Wheel Thermosetting Urethane Winding Wheel with Roller Bearings | |
116.96 € | 1 | 11 Days | 196 | 220.01~320.00 | 230 | Urethane | Abrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil) | 150 | 46 | 126 | 50.0 | URB | Iron Plate Wheel Thermosetting Urethane Winding Wheel with Roller Bearings | ||
142.15 € | 1 | 11 Days | 240 | 220.01~320.00 | 250 | Urethane | Abrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil) | 200 | 46 | 156 | 55.0 | URB | Iron Plate Wheel Thermosetting Urethane Winding Wheel with Roller Bearings |
Loading...
Basic information
| Caster Type | Screw-In Type | Stopper | Total Lock Caster | Fitting Material | Steel |
|---|---|---|---|---|---|
| Screw T or Mounting Screw Hole M | UNF1 | Load Category | Medium Load | Axial length L(mm) | 300 |
| (Metal Fitting/Main Body) Processing - Finish | Integrated Casting Wheel Uni-chrome Finish | Part Number | SA |
Configure
Basic Attributes
-
Mounting Height H or H1 and H2(mm)
-
Load Range(daN)
- 140.01~220.00
- 220.01~320.00
-
Allowable Load 1 piece(daN)
-
Wheel Material
- Rubber
- Urethane
-
Wheel Characteristics
- Abrasion Resistance
- Gasoline Resistance
- Oil Resistance (Machine Oil)
-
Wheel Dia. D(mm)
-
Car width(mm)
-
Swivel Radius(mm)
-
Eccentricity E or E1, E2(mm)
-
Variety of Vehicles
-
Type
- 515SA
Filter by standard shipping days
-
- All
- 11 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
