Linear Bushing with Flange, Pilot, Long Type, Two Face Flange

Linear Bushing with Flange, Pilot, Long Type, Two Face Flange

Brand-name products provided by MISUMI-VONA are carefully-selected from the products of Asian manufacturers and offered based on customers' needs. Please select the right item for your individual usage environment. This manufacturer is a linear parts manufacturer based in China. MYT products are manufactured under a strict quality management system and have been adopted all over the world.

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.

Part Number
LMYMHP16LUU
LMYMHP20LUU
LMYMHP25LUU
Part NumberStandard Unit PriceVolume DiscountShipping Days?Shaft Diameter
(φ)
Overall Length L
(mm)
Outer Diameter D
(φ)
Basic Load Rating Dynamic Rating (Detail)
(N)
Basic Load Rating Static Rating
(N)
Tolerance of Inscribed Circle (Minus Side)
(mm)
Eccentricity
(μm)

16.85 €

4 Days 16702812302350-0.0115

18.19 €

4 Days 20803214002740-0.01220

24.92 €

4 Days 251124015603140-0.01220

Loading...

  1. 1

Basic information

Type Flange Style Standard Flange Type Pilot Flange
Material of Outer Cylinder Bearing Steel Outer Cylinder Surface Treatment No Surface Treatment Motion Linear Motion
Lubrication Type N/A The circulation type of balls Long Type Accuracy Standard Grade
Type Flanged Inlay Length Long Flange Shape Round-shaped, 2 Set Screw Flats
The material of a ball Bearing Steel Seal Available W/ or w/o metal retainer NA
