10K Gate Valve

10K Gate Valve

TOUAVALVE

TOUAVALVE

Stainless steel valve, 10 K gate Toa Valve Industry.

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.

Data to be displayed
30
45
60
  1. 1
Part Number
T-UL-15
T-UL-20
T-UL-25
T-UL-32
T-UL-50
Part Number
Standard Unit Price
Minimum order quantityVolume Discount
Standard
Shipping Days
?
Supply Side, Nominal Designation of Piping Thread Supply Side, Nominal Designation of Pipe Flange Control SideNominal Pipe Threads Control Side Nominal The Pipe Flange Length L
(mm) 		Height h
(mm) 		Handle diameter D
(φ)

79.71 €

1 8 Days 1/2B1/2B1/2B1/2B548555

95.85 €

1 8 Days 3/4B3/4B3/4B3/4B589563

116.06 €

1 36 Days 1B1B1B1B6610370

111.67 €

1 8 Days 1 1/4B1 1/4B1 1/4B1 1/4B7512280

198.20 €

1 8 Days 2B2B2B2B8715890

Loading...

  1. 1

Basic information

Main Body Shape Straight Main Body Material Stainless Steel Applicable Fluids Water / Air / Oil / Gas / Vapor
Nominal Pressure 10K Type of Gate Valve Internal Thread Type Supply Side, Connection Type G
Control Side Connection Types G Handle Shape Round-shaped handle Main Body Lining N/A
Operation Method Manual Operation Type

Configure

Clear all

5Suggestion of an applicable part number.

View Part Numbers

Some specification is not specified yet.
The part number is completed.
