Parts for DSH-20N / 25N Heat Insulated Drain Hose
- Volume Discount
· Parts for connecting heat insulated drain hoses and VP pipes.
[Applications]
· For VP pipe fittings.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| DSH-20NC |
| DSH-20NJ |
| DSH-20NV |
| DSH-25NC |
| DSH-25NJ |
| DSH-25NV |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Compatible Pipe | Type | A Dimension (mm) | B Dimension (mm) | C Dimension (mm) | D Dimension (mm) | E Dimensions (mm) | JAN Code | Order Code | Mass (g) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
1.88 € | 1 | 6 Days | Compatible Drain Hose:DSH-20N | Main body cuffs | 17.0 | 35.0 | 26.0 | 37 | 64 | 4518301057600 | 761-3008 | 24 | ||
3.07 € | 1 | Available | 9 Days | Compatible Drain Hose:DSH-20N | Linear joint | 17.0 | 35.5 | 32.0 | 52 | NA | 4518301057662 | 761-3016 | 22 | |
2.16 € | 1 | Available | 9 Days | Compatible Drain Hose:DSH-20N | VP pipe joint | 16.0 | 35.0 | 26.5 | 35 | 63 | 4518301057723 | 761-3024 | 36 | |
2.37 € | 1 | Available | 6 Days | Compatible Drain Hose:DSH-25N | Main body cuffs | 22.5 | 40 | 32.0 | 42 | 69 | 4518301057631 | 761-3041 | 28 | |
3.64 € | 1 | 9 Days | Compatible Drain Hose:DSH-25N | Linear joint | 22.5 | 41.5 | 32.0 | 52 | NA | 4518301057693 | 761-3059 | 28 | ||
2.68 € | 1 | 6 Days | Compatible Drain Hose:DSH-25N | VP pipe joint | 21.5 | 40 | 32.6 | 40 | 68 | 4518301057754 | 761-3067 | 36 |
Loading...
Basic information
| Classification | For Drain Pipe | Type | Fitting | Material | Polyvinyl Chloride (PVC) |
|---|---|---|---|---|---|
| Number Contained In A Packet | 1 pc. |
Configure
Basic Attributes
-
Compatible Pipe
- Compatible Drain Hose:DSH-25N
- Compatible Drain Hose:DSH-20N
-
Type
- Linear joint
- Main body cuffs
- VP pipe joint
-
A Dimension(mm)
-
B Dimension(mm)
-
C Dimension(mm)
-
D Dimension(mm)
-
E Dimensions(mm)
-
JAN Code
-
Order Code
-
Type
- DSH-NC
- DSH-NJ
- DSH-NV
Filter by standard shipping days
-
- All
- 6 Days or Less
- 9 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
