Absodex TS type driver single unit

Absodex TS type driver single unit
[Features]
· Power is divided into main power and control power.
· Changes the wiring method from terminal blocks to connectors.
· Small and lightweight (adopts a resin body)
· 7-segment 2-digit LED display.
· Encoder output added (parallel I/O only).
· Supports serial communication options (built-in to the circuit board).
· Monitor function added for position information, alarm status, etc. (U2, U3, and U4 options only.)

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.

Part Number
AX9000TS-U1
AX9000TS-U4
Part Number
Standard Unit Price
Minimum order quantityVolume Discount
Standard
Shipping Days
?
Interface Specification

2,095.44 €

1 9 Days Parallel I/O (PNP type)

2,273.58 €

1 9 Days DeviceNet

Loading...

  1. 1

Basic information

Main Body/Peripheral Components Driver Details of Main Body Single Item Driver Type TS Type
Driver Power Supply Voltage Three-phase/Single-phase AC200V±10%~AC230V±10%
