LOGISTAR Tailorbelt-V Sloped Conveyance Applications (Reference Inclination Angle: 15° or Less)

LOGISTAR Tailorbelt-V Sloped Conveyance Applications (Reference Inclination Angle: 15° or Less)

MITSUBOSHI BELTING

MITSUBOSHI BELTING

Suitable for a wide range of applications from transporting cardboard boxes to agricultural products

Adopts high-quality PVC with outstanding oil, chemical, ozone and abrasion resistance.
Can also support transportation of logistics applications to machine parts, steel plates, building boards, etc.

(i)Remark

  • The product image is representative and may differ from the actual product. For details of color and surface shape, etc., refer to the catalog.

    * When attaching a meandering prevention bar it is necessary to specify a belt perimeter of 500 mm or more.

Data sheet

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.


Data to be displayed
30
45
60
  1. 1
Part Number
NS82VKG0/15GYA-[10-1200/5]X[220-9990/10]-E
NS82VKG0/15GYA-[30-1000/5]X[220-9990/10]-E-[A,​B]
NS82VKUG5/8DBT-[10-1200/5]X[220-9990/10]-E
NS82VKUG5/8DBT-[30-1000/5]X[220-9990/10]-E-[A,​B]
NS82VX0/8GBW-[10-1200/5]X[220-9990/10]-E
NS82VX0/8GBW-[30-1000/5]X[220-9990/10]-E-[A,​B]
Part Number
Standard Unit Price
Minimum order quantityVolume Discount
Standard
Shipping Days
?
RoHSSurface Cover Color Surface Cover Material Belt width
(mm) 		Surface Cover Shape Endless Type Belt circumferential length
(mm) 		Thickness
(mm) 		Meandering Prevention Crosspiece

-

1 11 Days -[Gray] GrayVinyl Chloride10 ～ 1200[Woven Fabric] Shallow GrooveFinger220 ～ 9990Front side: 1.5; Reverse side: -NA

-

1 11 Days -[Gray] GrayVinyl Chloride30 ～ 1000[Woven Fabric] Shallow GrooveFinger220 ～ 9990Front side: 1.5; Reverse side: -A Type / B Type

-

1 10 Days -Navy BluePolyurethane10 ～ 1200Vertical GrooveButt Stairs220 ～ 9990Front side: 0.8; Reverse side: 0.5NA

-

1 10 Days -Navy BluePolyurethane30 ～ 1000Vertical GrooveButt Stairs220 ～ 9990Front side: 0.8; Reverse side: 0.5A Type / B Type

-

1 11 Days 10[Green] GreenVinyl Chloride10 ～ 1200[Woven Fabric] Basket weaveFinger220 ～ 9990Front side: 0.8; Reverse side: -NA

-

1 11 Days -[Green] GreenVinyl Chloride30 ～ 1000[Woven Fabric] Basket weaveFinger220 ～ 9990Front side: 0.8; Reverse side: -A Type / B Type

Loading...

  1. 1

Basic information

Belt Specification Slope / Electrical Conductivity Core Body Material Polyester The Number of Tire Ply 2 Ply

Configure

Clear all

6Suggestion of an applicable part number.

View Part Numbers

Some specification is not specified yet.
The part number is completed.

Basic Attributes

  • Surface Cover Color

    • Green
      • Green
    • Navy Blue
    • Gray
      • Gray

    Clear

  • Surface Cover Material

    • Polyurethane
    • Vinyl Chloride

    Clear

  • Belt width(mm)

     [10-1200/5mm Unit(s)]

    Clear

  • Surface Cover Shape

    • Vertical Groove
    • Woven Fabric
      • Basket weave
      • Shallow Groove

    Clear

  • Endless Type

    • Finger
    • Butt Stairs

    Clear

  • Belt circumferential length(mm)

     [220-9990/10mm Unit(s)]

    Clear

  • Thickness(mm)

    • Front side: 0.8; Reverse side: -
    • Front side: 0.8; Reverse side: 0.5
    • Front side: 1.5; Reverse side: -

    Clear

  • Meandering Prevention Crosspiece

    • A Type
    • B Type
    • NA

    Clear

  • Type

    • NS82VKG0/15GYA
    • NS82VKUG5/8DBT
    • NS82VX0/8GBW

    Clear

Filter by standard shipping days

    • All
    • 10 Days or Less
    • 11 Days or Less

    Reset

Optional Attributes
