Rubber wheel (B80)
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| B80.100 |
| B80.125 |
| B80.126 |
| B80.127 |
| B80.160 |
| B80.161 |
| B80.200 |
| B80.250 |
| B80.251 |
| B80.252 |
| B80.300 |
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Wheel O.D. (mm) | Wheel Width (mm) | Hole Diameter (mm) | Hub Width (mm) | Max. Load / Allowable Load (kg) | |
|---|---|---|---|---|---|---|---|---|---|---|
25.60 € | 4 | 2 Days | 100 | 40 | 15 | 40 | 150 | |||
32.42 € | 4 | 2 Days | 125 | 50 | 20 | 50 | 220 | |||
26.92 € | 1 | 3 Days | 125 | 40 | 20 | 45 | 200 | |||
31.60 € | 1 | 3 Days | 125 | 40 | 15 | 40 | 180 | |||
41.86 € | 4 | 2 Days | 160 | 50 | 20 | 60 | 300 | |||
47.06 € | 1 | 3 Days | 160 | 50 | 20 | 50 | 350 | |||
53.96 € | 4 | 2 Days | 200 | 50 | 20 | 60 | 450 | |||
103.16 € | 1 | 3 Days | 250 | 60 | 20 | 70 | 600 | |||
75.04 € | 1 | 3 Days | 250 | 50 | 20 | 60 | 550 | |||
119.86 € | 1 | 3 Days | 250 | 63 | 20 | 70 | 580 | |||
131.20 € | 1 | 3 Days | 300 | 60 | 30 | 75 | 700 |
Loading...
Basic information
| Wheel Material | Rubber | Bearing | Provided | Wheel Material | Aluminum |
|---|
Configure
Basic Attributes
-
Wheel O.D.(mm)
-
Wheel Width(mm)
-
Hole Diameter(mm)
-
Hub Width(mm)
-
Max. Load / Allowable Load(kg)
-
Type
- B80
-
Filter by CAD data type
- 2D
- 3D
Filter by standard shipping days
-
- All
- 2 Days or Less
- 3 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
