Adapter sleeves H32, main dimensions to DIN 5415, taper 1:12
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| H3260-HG |
| H3264-HG |
| H3268-HG |
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Inner diameter (mm) | Outer diameter (mm) | Width (mm) | Thread G | Sleeve length B1 (mm) | Bore diameter bearing d (mm) | Fuse | Locknut | Width nut and lock B3 (mm) | Distance oil connector a (mm) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
2,777.97 € | 1 | Available | 5 Days | 280 | 380 | 240 | Tr300X4 | 240 | 300 | MS3160 | HM3160 | 52 | 4.2 | ||
4,011.55 € | 1 | Available | 5 Days | 300 | 400 | 258 | Tr320X5 | 258 | 320 | MS3164 | HM3164 | 55 | 3.5 | ||
5,060.40 € | 1 | Available | 5 Days | 320 | 440 | 288 | Tr340X5 | 288 | 340 | MS3168 | HM3168 | 70 | 3.5 |
Loading...
Basic information
| Taper | 1:12 | Thread oil connector G1 | M6 | Thread depth oil connector IG1(mm) | 7 |
|---|
Configure
Basic Attributes
-
Inner diameter(mm)
-
Outer diameter(mm)
-
Width(mm)
-
Thread G
-
Sleeve length B1(mm)
-
Bore diameter bearing d(mm)
-
Fuse
-
Locknut
-
Width nut and lock B3(mm)
-
Distance oil connector a(mm)
- 3.5
- 4.2
-
Type
- H32
Filter by standard shipping days
-
- All
- 5 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
