Cylindrical roller bearings NU4, main dimensions to DIN 5412-1, non-locating bearing, separable, with cage
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| NU406-XL-M1 |
| NU407-XL |
| NU407-XL-M1 |
| NU408-XL-M1 |
| NU409-XL-M1 |
| NU410-XL-M1 |
| NU411-XL-M1 |
| NU412-XL-M1 |
| NU413-XL-M1 |
| NU414-XL-M1 |
| NU415-XL-M1 |
| NU416-XL-M1 |
| NU416-XL-M1-C3 |
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Inner Diameter d (mm) | Outer Diameter D (mm) | Width B (or T) (mm) | Rotational Speed (1/min) | Basic Load Rating, Dynamic Rating (N) | Basic Load Rating, Static Rating (N) | Bearing clearance identifier | RoHS Certificate | REACH Certificate | Customs tariff — weight | Customs tariff — weight unit | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
118.43 € | 1 | Available | 3 Days | 30 | 90 | 23 | 13400 | 84000 | 65000 | - | - | - | - | - | ||
| - | 166.25 € | 1 | Available | 5 Days | 35 | 100 | 25 | - | - | - | - | - | - | - | - | |
- | 1 | 4 Days | 35 | 100 | 25 | 11800 | 103000 | 83000 | - | Available | Available | 1.14 | kg | |||
241.26 € | 1 | Available | 5 Days | 40 | 110 | 27 | 10500 | 119000 | 95000 | - | - | - | - | - | ||
220.63 € | 1 | Available | 3 Days | 45 | 120 | 29 | 9600 | 143000 | 119000 | - | - | - | - | - | ||
266.10 € | 1 | Available | 5 Days | 50 | 130 | 31 | 8600 | 175000 | 148000 | - | - | - | - | - | ||
326.43 € | 1 | Available | 5 Days | 55 | 140 | 33 | - | - | - | - | - | - | - | - | ||
321.95 € | 1 | Available | 3 Days | 60 | 150 | 35 | 7500 | 211000 | 184000 | - | Available | Available | 3.39 | kg | ||
377.23 € | 1 | Available | 3 Days | 65 | 160 | 37 | 7000 | 230000 | 203000 | - | - | - | - | - | ||
547.19 € | 1 | 17 Days | 70 | 180 | 42 | 6200 | 285000 | 255000 | - | - | - | - | - | |||
562.34 € | 1 | Available | 3 Days | 75 | 190 | 45 | 5800 | 325000 | 295000 | - | - | - | - | - | ||
747.25 € | 1 | 17 Days | 80 | 200 | 48 | 5400 | 395000 | 365000 | - | - | - | - | - | |||
| - | 642.15 € | 1 | Available | 3 Days | 80 | 200 | 48 | - | - | - | C3 | - | - | - | - |
Loading...
Configure
Basic Attributes
-
Inner Diameter d(mm)
-
Outer Diameter D(mm)
-
Width B (or T)(mm)
-
Bearing clearance identifier
- C3
-
RoHS Certificate
- Available
-
REACH Certificate
- Available
-
Customs tariff — weight
-
Customs tariff — weight unit
- kg
-
Type
- NU40
- NU41
-
Filter by CAD data type
- 3D
Filter by standard shipping days
-
- All
- 3 Days or Less
- 4 Days or Less
- 5 Days or Less
- 17 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
