Deep groove ball bearings / single row / 618xx / 2RZ Radial seal / 618xx-2RZ / similar to DIN 625-1 / FAG
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Inner Diameter d (φ) | Outer Diameter D (φ) | Width B (or T) (mm) | Basic Dynamic Load Rating (N) | Maximum Allowable Rotational Speed (1/min) | Load Direction | Basic Load Rating Static Rating (N) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
38.43 € | 1 | Available | 4 Days | 45 | 58 | 7 | 7000 | 14300 | Radial | 5900 | ||
33.69 € | 1 | Available | 3 Days | 50 | 65 | 7 | 7200 | 12900 | Radial | 6300 | ||
51.41 € | 1 | Available | 4 Days | 55 | 72 | 9 | 9600 | 11500 | Radial | 8500 | ||
60.42 € | 2 | Available | 2 Days | 60 | 78 | 10 | 12600 | 10400 | Radial | 11100 | ||
52.23 € | 1 | Available | 3 Days | 65 | 85 | 10 | 13000 | 9600 | Radial | 12000 | ||
56.15 € | 1 | Available | 3 Days | 70 | 90 | 10 | 13200 | 9000 | Radial | 12400 | ||
85.62 € | 1 | Available |
Same day
Stock | 75 | 95 | 10 | 13700 | 8500 | Radial | 13400 | ||
91.67 € | 1 | Available |
Same day
Stock | 80 | 100 | 10 | 13800 | 8000 | Radial | 13800 | ||
87.98 € | 1 | Available |
Same day
Stock | 85 | 110 | 13 | 20400 | 7200 | Radial | 19800 | ||
96.88 € | 5 | Available |
Same day
Stock | 90 | 115 | 13 | 20700 | 6900 | Radial | 20600 | ||
104.55 € | 1 | Available |
Same day
Stock | 95 | 120 | 13 | 21000 | 6600 | Radial | 21300 | ||
143.13 € | 1 | Available | 3 Days | 100 | 125 | 13 | 21300 | 6300 | Radial | 22100 | ||
157.60 € | 1 | Available | 4 Days | 105 | 130 | 13 | 22100 | 6000 | Radial | 23600 | ||
132.85 € | 1 | Available |
Same day
Stock | 110 | 140 | 16 | 30000 | 5600 | Radial | 30500 | ||
200.93 € | 1 | Available | 3 Days | 120 | 150 | 16 | 30500 | 5100 | Radial | 33000 | ||
| - | 186.38 € | 1 | Available |
Same day
Stock | 130 | 165 | 18 | - | - | - | - | |
| - | 220.22 € | 1 | Available |
Same day
Stock | 140 | 175 | 18 | - | - | - | - |
Loading...
Configure
Stock
-
- Show only stock items
Basic Attributes
-
Inner Diameter d(φ)
-
Outer Diameter D(φ)
-
Width B (or T)(mm)
-
Basic Dynamic Load Rating(N)
-
Load Direction
- Radial
-
Type
- 618
-
Filter by CAD data type
- 3D
Filter by standard shipping days
-
- All
- Same day
- 2 Days or Less
- 3 Days or Less
- 4 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
