Radial insert ball bearings / single row / outer ring spherical / 2RSR / adapter sleeve / GSHxx2RSR-B / INA
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| GSH20-2RSR-B |
| GSH20-XL-2RSR-B |
| GSH25-2RSR-B |
| GSH25-XL-2RSR-B |
| GSH30-2RSR-B |
| GSH30-XL-2RSR-B |
| GSH35-2RSR-B |
| GSH35-XL-2RSR-B |
| GSH40-2RSR-B |
| GSH40-XL-2RSR-B |
| GSH50-2RSR-B |
| GSH50-XL-2RSR-B |
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Inner Diameter d (φ) | Outer Diameter D (φ) | Width B (or T) (mm) | Basic Dynamic Load Rating (N) | Maximum Allowable Rotational Speed (1/min) | Basic Load Rating Static Rating (N) | Width with mounting components B1 (mm) | RoHS Certificate | REACH Certificate | Customs tariff — weight (kg) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| - | - | 1 | 4 Days | 20 | 47 | 15 | 12700 | 17900 | 6600 | 28 | - | - | - | ||
- | 1 | 4 Days | 20 | 47 | 15 | 12700 | 17900 | 6600 | 28 | Available | Available | 0.15 | |||
| - | - | 1 | 4 Days | 25 | 52 | 15 | 13600 | 16000 | 7800 | 28 | - | - | - | ||
36.49 € | 1 | Available | 3 Days | 25 | 52 | 15 | 13600 | 16000 | 7800 | 28 | Available | Available | 0.16 | ||
| - | - | 1 | 4 Days | 30 | 62 | 18 | 18900 | 13300 | 11300 | 32 | - | - | - | ||
40.12 € | 1 | Available | 3 Days | 30 | 62 | 18 | 18900 | 13300 | 11300 | 32 | Available | Available | 0.28 | ||
| - | - | 1 | 4 Days | 35 | 72 | 19 | 24900 | 11400 | 15300 | 34 | - | - | - | ||
48.97 € | 1 | Available | 3 Days | 35 | 72 | 19 | 24900 | 11400 | 15300 | 34 | Available | Available | 0.4 | ||
| - | - | 1 | 4 Days | 40 | 80 | 22 | 29500 | 10200 | 19800 | 38 | - | - | - | ||
- | 1 | 4 Days | 40 | 80 | 22 | 29500 | 10200 | 19800 | 38 | Available | Available | 0.52 | |||
| - | - | 1 | 4 Days | 50 | 90 | 22 | 35000 | 8800 | 23100 | 40 | - | - | - | ||
- | 1 | 4 Days | 50 | 90 | 22 | 35000 | 8800 | 23100 | 40 | Available | Available | 0.71 |
Loading...
Basic information
| Load Direction | Radial |
|---|
Configure
Basic Attributes
-
Inner Diameter d(φ)
-
Outer Diameter D(φ)
-
Width B (or T)(mm)
-
Basic Dynamic Load Rating(N)
-
Width with mounting components B1(mm)
-
RoHS Certificate
-
REACH Certificate
- Available
-
Customs tariff — weight(kg)
-
Type
- GSH
-
Filter by CAD data type
- 3D
Filter by standard shipping days
-
- All
- 3 Days or Less
- 4 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
