Spherical roller bearings 222..-BE-K, main dimensions to DIN 635-2, with tapered bore, taper 1:12
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| 22238-BE-XL-K |
| 22238-BE-XL-K-C4 |
| 22240-BE-XL-K |
| 22240-BE-XL-K-C3 |
| 22240-BE-XL-K-C4 |
| 22244-BE-XL-K |
| 22244-BE-XL-K-C3 |
| 22244-BE-XL-K-C4 |
| 22248-BE-XL-K |
| 22248-BE-XL-K-C3 |
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Inner Diameter d (mm) | Outer Diameter D (mm) | Width B (or T) (mm) | Rotational Speed (1/min) | Basic Load Rating, Dynamic Rating (N) | Basic Load Rating, Static Rating (N) | Bearing clearance identifier | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
1,482.20 € | 1 | Available | 3 Days | 190 | 340 | 92 | 2480 | 1360000 | 1760000 | - | ||
| - | 2,042.88 € | 1 | Available | 5 Days | 190 | 340 | 92 | - | - | - | - | |
1,792.95 € | 1 | Available | 3 Days | 200 | 360 | 98 | 2330 | 1520000 | 1990000 | - | ||
| - | 1,792.95 € | 1 | Available | 3 Days | 200 | 360 | 98 | - | - | - | C3 | |
| - | 2,471.50 € | 1 | Available | 5 Days | 200 | 360 | 98 | - | - | - | - | |
2,330.75 € | 1 | Available | 3 Days | 220 | 400 | 108 | 2140 | 1840000 | 2360000 | - | ||
| - | 2,330.75 € | 1 | Available | 3 Days | 220 | 400 | 108 | - | - | - | C3 | |
| - | 2,671.82 € | 1 | 17 Days | 220 | 400 | 108 | - | - | - | - | ||
4,467.99 € | 1 | Available | 5 Days | 240 | 440 | 120 | 1900 | 2230000 | 2900000 | - | ||
| - | 4,467.99 € | 1 | Available | 5 Days | 240 | 440 | 120 | - | - | - | C3 |
Loading...
Configure
Basic Attributes
-
Inner Diameter d(mm)
-
Outer Diameter D(mm)
-
Width B (or T)(mm)
-
Bearing clearance identifier
- C3
-
Type
- 2223
- 2224
Filter by standard shipping days
-
- All
- 3 Days or Less
- 5 Days or Less
- 17 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
