Swivel Castors with all-steel wheel
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| L-HS-STS-100-K-3 |
| L-HS-STS-125-K-3 |
| L-HS-STS-150-K-3 |
| L-HS-STS-200-K-3 |
| L-HS-STS-200-K-3-B80 |
| L-HS-STS-250-K-3 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Plate length (mm) | Plate width (mm) | Wheel diameter (mm) | Wheel width (mm) | Load capacity dynamic (kg) | overall height (mm) | Discharge swivel castor (mm) | Bolt Hole Length (mm) | Bolt hole width (mm) | Surface coating | Screw hole (mm) | Number of wheels [piece] | Swivel Radius (mm) | Tread type | Weight (kg) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
191.42 € | 1 | 4 Days | 135 | 110 | 100 | 40 | 1700 | 145 | 50 | 105 | 80 | galvanized | 11 | 1 | 100 | cylindrical | 5.29 | ||
249.63 € | 1 | 5 Days | 135 | 110 | 125 | 55 | 1750 | 170 | 50 | 105 | 80 | galvanized | 11 | 1 | 112.5 | crowned | 8.06 | ||
282.93 € | 1 | 5 Days | 175 | 140 | 150 | 55 | 3000 | 205 | 56 | 140 | 105 | galvanized | 14 | - | 131 | cylindrical | 13.09 | ||
552.91 € | 1 | 5 Days | 175 | 140 | 200 | 55 | 3000 | 255 | 65 | 140 | 105 | Painted | 14 | 1 | 165 | cylindrical | - | ||
481.17 € | 1 | 5 Days | 255 | 200 | 200 | 80 | 6000 | 280 | 70 | 210 | 160 | Painted | 18 | 1 | 170 | cylindrical | 33 | ||
2,222.49 € | 1 | 5 Days | 400 | 300 | 250 | 65 | 10000 | 380 | 110 | 340 | 240 | Painted | 26 | 1 | - | cylindrical | 83 |
Loading...
Basic information
| Rolls and case type | Steering housing | Mounting type | Mounting plate | Wheel bearing | Ball-bearing |
|---|---|---|---|---|---|
| Housing Series Type | HS (LPSX/BPSX) | Housing material RR | Steel | Rim material | Steel |
| Tread material | Steel | electrically conductive | electrically conductive | Housing design | welded |
| Clevis bearing seal | closed fork head | Bearing shell type | hardened | Housing classification | Super heavy duty housing HS |
Configure
Basic Attributes
-
Plate length(mm)
-
Plate width(mm)
-
Wheel diameter(mm)
-
Wheel width(mm)
-
Load capacity dynamic(kg)
-
overall height(mm)
-
Discharge swivel castor(mm)
-
Bolt Hole Length(mm)
-
Bolt hole width(mm)
-
Surface coating
- Painted
- galvanized
-
Screw hole(mm)
-
Number of wheels [piece]
- 1
-
Swivel Radius(mm)
-
Tread type
- crowned
- cylindrical
Filter by standard shipping days
-
- All
- 4 Days or Less
- 5 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
