Stainless steel fixed Castors with polyamide wheel
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Plate length (mm) | Plate width (mm) | Wheel diameter (mm) | Wheel width (mm) | Load capacity dynamic (kg) | overall height (mm) | Wheel bearing | Housing Series Type | Bolt Hole Length (mm) | Bolt hole width (mm) | Screw hole (mm) | Number of wheels [piece] | Rim material | Tread material | electrically conductive | Housing classification | Weight (kg) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
80.87 € | 1 | 5 Days | 135 | 110 | 125 | 40 | 400 | 178 | - | HV (RLP/RBP) | 105 | 80 | - | - | - | - | - | Heavy stainless steel series HV | 2.76 | ||
102.20 € | 1 | 5 Days | 135 | 110 | 150 | 45 | 700 | 211 | - | HV (RLP/RBP) | 105 | 80 | - | - | - | - | - | Heavy stainless steel series HV | 3.3 | ||
114.26 € | 1 | 5 Days | 135 | 110 | 200 | 50 | 1000 | 250 | - | HV (RLP/RBP) | 105 | 80 | - | - | - | - | - | Heavy stainless steel series HV | 3.75 | ||
10.72 € | 1 | 5 Days | 100 | 80 | 80 | 33 | 130 | 108 | Bearing | IV (LF/BF) | 80 | 60 | - | - | - | - | - | Stainless steel standard series IV | 0.42 | ||
12.48 € | 1 | 5 Days | 100 | 80 | 100 | 35 | 130 | 128 | Bearing | IV (LF/BF) | 80 | 60 | - | - | - | - | - | Stainless steel standard series IV | 0.5 | ||
18.30 € | 1 | 5 Days | 100 | 80 | 125 | 35 | 130 | 155 | Bearing | IV (LF/BF) | 80 | 60 | - | - | - | - | - | Stainless steel standard series IV | 0.7 | ||
27.12 € | 1 | 5 Days | 135 | 110 | 125 | 36 | 200 | 160 | Bearing | IV (LF/BF) | 105 | 80 | - | - | - | - | - | Stainless steel standard series IV | 0.75 | ||
34.33 € | 1 | 5 Days | 130 | 106 | 200 | 50 | 270 | 240 | Bearing | IV (LF/BF) | 105 | 80 | - | - | - | - | - | Stainless steel standard series IV | 1.65 | ||
21.75 € | 1 | 5 Days | 100 | 80 | 80 | 30 | 130 | 108 | - | IV (LF/BF) | 80 | 60 | 8 | - | Polyamide | Polyamide | electrically conductive | Stainless steel standard series IV | 0.4 | ||
24.67 € | 1 | 5 Days | 100 | 80 | 100 | 35 | 130 | 128 | - | IV (LF/BF) | 80 | 60 | 8 | - | Polyamide | Polyamide | electrically conductive | Stainless steel standard series IV | 0.45 | ||
30.44 € | 1 | 5 Days | 100 | 80 | 125 | 40 | 130 | 155 | - | IV (LF/BF) | 80 | 60 | 10 | - | Polyamide | Polyamide | electrically conductive | Stainless steel standard series IV | 0.55 | ||
30.18 € | 1 | 5 Days | 130 | 106 | 160 | 40 | 270 | 197 | Bearing | IV (LF/BF) | 105 | 80 | - | - | - | - | - | Stainless steel standard series IV | 1.02 | ||
88.73 € | 1 | 4 Days | 130 | 106 | 150 | 45 | 270 | 195 | - | - | 105 | 80 | 12 | - | Polyamide | Polyamide | electrically conductive | Stainless steel standard series IV | 1.6 | ||
117.53 € | 1 | 4 Days | 130 | 106 | 200 | 50 | 270 | 245 | Ball-bearing | IV (LF/BF) | 105 | 80 | 12 | 1 | Polyamide | Polyamide | electrically conductive | Stainless steel standard series IV | 2.15 |
Loading...
Basic information
| Rolls and case type | Fixed bracket | Mounting type | Mounting plate |
|---|
Configure
Basic Attributes
-
Plate length(mm)
-
Plate width(mm)
-
Wheel diameter(mm)
-
Wheel width(mm)
-
Load capacity dynamic(kg)
-
overall height(mm)
-
Wheel bearing
- Ball-bearing
- Bearing
-
Housing Series Type
-
Bolt Hole Length(mm)
-
Bolt hole width(mm)
-
Screw hole(mm)
-
Number of wheels [piece]
- 1
-
Rim material
- Polyamide
-
Tread material
- Polyamide
-
electrically conductive
- electrically conductive
-
Housing classification
- Heavy stainless steel series HV
- Stainless steel standard series IV
Filter by standard shipping days
-
- All
- 4 Days or Less
- 5 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
