Fixed Castors with pneumatic wheel, sheet steel housing, with sheet steel rim

Fixed Castors with pneumatic wheel, sheet steel housing, with sheet steel rim

Product Details:

Manufacturer part number: B-IS-LRS1-185-R-GRAU

Brand: TORWEGGE

Price: 40.76

Delivery time: 5 Days

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.

B-IS-LRS1-185-R-GRAU

Part Number
B-IS-LRS1-185-R-GRAU
Part Number
Standard Unit Price
Minimum order quantityVolume Discount
Standard
Shipping Days
?

40.76 €

1 5 Days

Loading...

  1. 1

Basic information

Plate length(mm) 135 Plate width(mm) 114 Wheel diameter(mm) 185
Wheel width(mm) 45 Load capacity dynamic(kg) 50 overall height(mm) 210
Rolls and case type Fixed bracket Mounting type Mounting plate Wheel bearing Roller bearing
Housing Series Type IS (LI/BI) Bolt Hole Length(mm) 105 Housing material RR Steel galvanized
Bolt hole width(mm) 80 Material Description Housing Sheet steel housing, galvanized Surface coating galvanized
Screw hole(mm) 11 Number of wheels [piece] 1 Rim material Sheet steel, painted
Tread material Pneumatic tires electrically conductive none Housing design drawn
Tread color Grey Tread type crowned Housing classification Standard housing IL
Min. temperature resistance(° C) -20 Max. temperature resistance(° C) 50 Weight(kg) 2.3

This page is Fixed Castors with pneumatic wheel, sheet steel housing, with sheet steel rim, part number B-IS-LRS1-185-R-GRAU.
You can find the detail information about specifications and dimensions on part number B-IS-LRS1-185-R-GRAU.
