Rod clevis, SG Series
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| SG-M4 |
| SG-M27X2-B |
| SG-M36X2 |
| SG-M42X2 |
| SG-M48X2 |
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Size | Threaded connection | Manufacturer part # | Weight (g) | |
|---|---|---|---|---|---|---|---|---|---|
3.71 € | 1 | 3 Days | M4 | Internal thread M4 | 6532 | 8 | |||
86.48 € | 1 | 4 Days | M27x2 | Internal thread M27x2 | 14987 | 2135 | |||
148.72 € | 1 | 4 Days | M36x2 | Internal thread M36x2 | 9581 | 4320 | |||
350.45 € | 1 | 4 Days | M42x2 | Internal thread M42x2 | 9582 | 7520 | |||
661.65 € | 1 | 4 Days | M48x2 | Internal thread M48x2 | 9583 | 10029 |
Loading...
Basic information
| Nut material | Steel, galvanized | Bolt material | Steel, galvanized | Clevis material | Steel, galvanized |
|---|---|---|---|---|---|
| Min. Ambient temperature(°C) | -40 | Max. Ambient temperature(°C) | 150 | Corrosion resistance class (CRC) | 1 - Low corrosion stress |
Configure
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
