Pressure sensor, SPAW Series
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Pneumatic connection | Switching output | Pressure measuring range initial value (bar) | Pressure measuring range end value (bar) | Max. overload pressure (bar) | Manufacturer part # | |
|---|---|---|---|---|---|---|---|---|---|---|---|
301.57 € | 1 | Quote | External thread G1/2 | 2xNPN | -1 | 1 | 2 | 8022767 | |||
349.71 € | 1 | 4 Days | External thread G1/2 | 2xNPN | -1 | 1 | 2 | 8022821 | |||
349.71 € | 1 | 4 Days | External thread G1/2 | 2xNPN | -1 | 1 | 2 | 8022839 | |||
301.57 € | 1 | 12 Days | External thread G1/2 | 2xPNP | -1 | 1 | 2 | 8022749 | |||
349.71 € | 1 | 4 Days | External thread G1/2 | 2xPNP | -1 | 1 | 2 | 8022785 | |||
349.71 € | 1 | 4 Days | External thread G1/2 | 2xPNP | -1 | 1 | 2 | 8022803 | |||
301.57 € | 1 | 4 Days | Internal thread G1/4 | 2xNPN | -1 | 1 | 2 | 8022758 | |||
349.71 € | 1 | 4 Days | Internal thread G1/4 | 2xNPN | -1 | 1 | 2 | 8022812 | |||
349.71 € | 1 | 4 Days | Internal thread G1/4 | 2xNPN | -1 | 1 | 2 | 8022830 | |||
301.57 € | 1 | 4 Days | Internal thread G1/4 | 2xPNP | -1 | 1 | 2 | 8022740 | |||
349.71 € | 1 | 4 Days | Internal thread G1/4 | 2xPNP | -1 | 1 | 2 | 8022776 | |||
349.71 € | 1 | 4 Days | Internal thread G1/4 | 2xPNP | -1 | 1 | 2 | 8022794 | |||
301.57 € | 1 | 4 Days | External thread G1/2 | 2xNPN | -1 | 10 | 20 | 8022768 | |||
349.71 € | 1 | 4 Days | External thread G1/2 | 2xNPN | -1 | 10 | 20 | 8022822 | |||
349.71 € | 1 | Quote | External thread G1/2 | 2xNPN | -1 | 10 | 20 | 8022840 | |||
301.57 € | 1 | 4 Days | External thread G1/2 | 2xPNP | -1 | 10 | 20 | 8022750 | |||
349.71 € | 1 | 4 Days | External thread G1/2 | 2xPNP | -1 | 10 | 20 | 8022786 | |||
349.71 € | 1 | 4 Days | External thread G1/2 | 2xPNP | -1 | 10 | 20 | 8022804 | |||
301.57 € | 1 | 4 Days | Internal thread G1/4 | 2xNPN | -1 | 10 | 20 | 8022759 | |||
349.71 € | 1 | 4 Days | Internal thread G1/4 | 2xNPN | -1 | 10 | 20 | 8022813 | |||
349.71 € | 1 | 4 Days | Internal thread G1/4 | 2xNPN | -1 | 10 | 20 | 8022831 | |||
301.57 € | 1 | 4 Days | Internal thread G1/4 | 2xPNP | -1 | 10 | 20 | 8022741 | |||
349.71 € | 1 | 4 Days | Internal thread G1/4 | 2xPNP | -1 | 10 | 20 | 8022777 | |||
349.71 € | 1 | 4 Days | Internal thread G1/4 | 2xPNP | -1 | 10 | 20 | 8022795 | |||
280.72 € | 1 | 4 Days | External thread G1/2 | 2xNPN | 0 | 2 | 4 | 8022769 | |||
328.86 € | 1 | 4 Days | External thread G1/2 | 2xNPN | 0 | 2 | 4 | 8022823 | |||
328.86 € | 1 | Quote | External thread G1/2 | 2xNPN | 0 | 2 | 4 | 8022841 | |||
280.72 € | 1 | 4 Days | External thread G1/2 | 2xPNP | 0 | 2 | 4 | 8022751 | |||
328.86 € | 1 | 4 Days | External thread G1/2 | 2xPNP | 0 | 2 | 4 | 8022787 | |||
328.86 € | 1 | 4 Days | External thread G1/2 | 2xPNP | 0 | 2 | 4 | 8022805 | |||
280.72 € | 1 | 4 Days | Internal thread G1/4 | 2xNPN | 0 | 2 | 4 | 8022760 | |||
328.86 € | 1 | 4 Days | Internal thread G1/4 | 2xNPN | 0 | 2 | 4 | 8022814 | |||
328.86 € | 1 | 4 Days | Internal thread G1/4 | 2xNPN | 0 | 2 | 4 | 8022832 | |||
280.72 € | 1 | 4 Days | Internal thread G1/4 | 2xPNP | 0 | 2 | 4 | 8022742 | |||
328.86 € | 1 | 4 Days | Internal thread G1/4 | 2xPNP | 0 | 2 | 4 | 8022778 | |||
328.86 € | 1 | 4 Days | Internal thread G1/4 | 2xPNP | 0 | 2 | 4 | 8022796 | |||
280.72 € | 1 | Quote | External thread G1/2 | 2xNPN | 0 | 6 | 12 | 8022770 | |||
328.86 € | 1 | Quote | External thread G1/2 | 2xNPN | 0 | 6 | 12 | 8022824 | |||
328.86 € | 1 | Quote | External thread G1/2 | 2xNPN | 0 | 6 | 12 | 8022842 | |||
280.72 € | 1 | 12 Days | External thread G1/2 | 2xPNP | 0 | 6 | 12 | 8022752 | |||
328.86 € | 1 | 12 Days | External thread G1/2 | 2xPNP | 0 | 6 | 12 | 8022788 | |||
328.86 € | 1 | 4 Days | External thread G1/2 | 2xPNP | 0 | 6 | 12 | 8022806 | |||
280.72 € | 1 | 4 Days | Internal thread G1/4 | 2xNPN | 0 | 6 | 12 | 8022761 | |||
328.86 € | 1 | 4 Days | Internal thread G1/4 | 2xNPN | 0 | 6 | 12 | 8022815 | |||
328.86 € | 1 | 4 Days | Internal thread G1/4 | 2xNPN | 0 | 6 | 12 | 8022833 | |||
280.72 € | 1 | 3 Days | Internal thread G1/4 | 2xPNP | 0 | 6 | 12 | 8022743 | |||
328.86 € | 1 | 12 Days | Internal thread G1/4 | 2xPNP | 0 | 6 | 12 | 8022779 | |||
328.86 € | 1 | 4 Days | Internal thread G1/4 | 2xPNP | 0 | 6 | 12 | 8022797 | |||
280.72 € | 1 | 5 Days | External thread G1/2 | 2xNPN | 0 | 10 | 20 | 8022771 | |||
328.86 € | 1 | 4 Days | External thread G1/2 | 2xNPN | 0 | 10 | 20 | 8022825 | |||
328.86 € | 1 | 4 Days | External thread G1/2 | 2xNPN | 0 | 10 | 20 | 8022843 | |||
280.72 € | 1 | 4 Days | External thread G1/2 | 2xPNP | 0 | 10 | 20 | 8022753 | |||
328.86 € | 1 | 4 Days | External thread G1/2 | 2xPNP | 0 | 10 | 20 | 8022789 | |||
328.86 € | 1 | 4 Days | External thread G1/2 | 2xPNP | 0 | 10 | 20 | 8022807 | |||
280.72 € | 1 | 4 Days | Internal thread G1/4 | 2xNPN | 0 | 10 | 20 | 8022762 | |||
328.86 € | 1 | 4 Days | Internal thread G1/4 | 2xNPN | 0 | 10 | 20 | 8022816 | |||
328.86 € | 1 | 4 Days | Internal thread G1/4 | 2xNPN | 0 | 10 | 20 | 8022834 | |||
280.72 € | 1 | 4 Days | Internal thread G1/4 | 2xPNP | 0 | 10 | 20 | 8022744 | |||
328.86 € | 1 | 4 Days | Internal thread G1/4 | 2xPNP | 0 | 10 | 20 | 8022780 | |||
328.86 € | 1 | 4 Days | Internal thread G1/4 | 2xPNP | 0 | 10 | 20 | 8022798 |
Loading...
Basic information
| Operating Temperature Range(℃) | 0::80 | Protection Rating | IP67 | Housing material | High-alloy stainless steel, ABS |
|---|---|---|---|---|---|
| Materials in contact with the media | High-alloy stainless steel | Display type | LED display, 4-character alphanumeric | Switching element function | N/C contact, N/O contact, Switchable |
| Max. output current(mA) | 250 | Min. Temperature of medium(°C) | -20 | Max. Temperature of medium(°C) | 85 |
| IP rating | IP65, IP67 | DC operating voltage range(V) | 15-35 | Repetition accuracy in ± %FS | 0.15 %FS |
| Operating medium | Compressed air as per ISO 8573-1:2010 [-:-:-], Gaseous media, Liquid media | Corrosion resistance class (CRC) | 4 - Particularly high corrosion stress | Weight(g) | 230 |
Configure
Basic Attributes
-
Pneumatic connection
-
Switching output
- 2xNPN
- 2xPNP
-
Pressure measuring range initial value(bar)
- -1
- 0
-
Pressure measuring range end value(bar)
- 1
- 2
- 6
- 10
- 16
- 25
- 50
- 100
-
Max. overload pressure(bar)
Filter by standard shipping days
-
- All
- 3 Days or Less
- 4 Days or Less
- 5 Days or Less
- 11 Days or Less
- 12 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
