PARKER Parkrimp No-Skive Fitting 1D948
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| 1D948-4-4 |
| 1D948-4-5 |
| 1D948-6-4 |
| 1D948-6-5 |
| 1D948-6-6 |
| 1D948-8-6 |
| 1D948-8-8 |
| 1D948-10-10 |
| 1D948-12-8 |
| 1D948-12-10 |
| 1D948-12-12 |
| 1D948-16-12 |
| 1D948-16-16 |
| 1D948-20-20 |
| 1D948-24-24 |
| 1D948-32-32 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Nominal Dia. (mm) | A (mm) | Customs tariff weight (kg) | Thread or tube size | H (mm) | B (mm) | Operating pressure Mpa | Hose fitting size | Thread diameter BSP | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
16.76 € | 1 | 5 Days | 6 | 51 | 0.079 | -04 | 19 | 27 | 63 | -04 | 1/4x19 | ||
75.80 € | 1 | 5 Days | 8 | 49 | 0.058 | -04 | 19 | 27 | 63 | -05 | 1/4x19 | ||
26.81 € | 1 | 5 Days | 6 | 53 | 0.075 | -06 | 22 | 31 | 55 | -04 | 3/8x19 | ||
28.32 € | 1 | 5 Days | 8 | 55 | 0.116 | -06 | 22 | 31 | 55 | -05 | 3/8x19 | ||
16.87 € | 1 | 5 Days | 10 | 54 | 0.121 | -06 | 22 | 31 | 55 | -06 | 3/8x19 | ||
27.09 € | 1 | 5 Days | 10 | 56 | 0.108 | -08 | 27 | 33 | 43 | -06 | 1/2x14 | ||
23.35 € | 1 | 5 Days | 12 | 57 | 0.158 | -08 | 27 | 33 | 43 | -08 | 1/2x14 | ||
46.40 € | 1 | 5 Days | 16 | 60 | 0.192 | -10 | 30 | 35 | - | -10 | 5/8x14 | ||
70.23 € | 1 | 5 Days | 12 | 60 | 0.195 | -12 | 32 | 36 | 35 | -08 | 3/4x14 | ||
53.78 € | 1 | 5 Days | 16 | 62 | 0.217 | -12 | 32 | 37 | 35 | -10 | 3/4x14 | ||
36.82 € | 1 | 5 Days | 19 | 62 | 0.11 | -12 | 32 | 36 | 35 | -12 | 3/4x14 | ||
67.83 € | 1 | 5 Days | 19 | 67 | 0.345 | -16 | 41 | 41 | 28 | -12 | 1x11 | ||
68.43 € | 1 | 5 Days | 25 | 72 | 0.408 | -16 | 41 | 42 | 28 | -16 | 1x11 | ||
236.24 € | 1 | 5 Days | 31 | 92 | 0.634 | -20 | 50 | 45 | 25 | -20 | 1-1/4x11 | ||
282.06 € | 1 | 5 Days | 40 | 87 | 1.112 | -24 | 60 | 49 | 21 | -24 | 1-1/2x11 | ||
473.41 € | 1 | 5 Days | 51 | 102 | 1.383 | -32 | 70 | 54 | 21 | -32 | 2x11 |
Loading...
Basic information
| Customs tariff weight unit | kg | Steel | Galvanized steel, Cr(VI)-free | Connection group | BSP |
|---|---|---|---|---|---|
| Norm | BS5200 | Common name | AGR | Description of connection type | BSP screw-in stud - cylindrical |
| Connection type | D9 | Fitting series | 48 | Customs tariff item number | 73269098 |
| Customs tariff weight per | 1 | Fitting | Parkrimp fitting | Customs tariff country of origin | DE |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
