EPIC® H-B 24 TBFH-LB
- Volume Discount
The robust metal housing with a single lever and a direct cable entry is ideal for use in the plastics industry and for investment construction applications.Housing design H-B. The industry standard.More interior space for wiringSingle Lever version for quick locking and simple unlocking with lifting aidProtection rating UL50E tested
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Basic information
| Degree of protection (IP), mounted | IP65 | Height | 78,8 | Length | 120 |
|---|---|---|---|---|---|
| Width | 43 | Operation temperature | 125 | Inflammability class of insulation material acc. with UL94 | HB |
| Housing coating | With powder coating | Locking mechanism | Single locking lever | Position cable feed | Above |
| Position of the shackle | Base unit | Material housing | Aluminium | Type of housing | Coupling housing |
| Corrosion resistant | True | EMC-version | False | UV resistant | True |
| With cable screw gland | False | With hinged lid | False | With interlocking device | True |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
