THT female header 2091【100-200 Pieces Per Package】
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 2091-1302 |
| 2091-1304 |
| 2091-1308 |
| Part Number | Related to |
Standard Unit Price
| Number of pc(s). included in pkg. | Minimum order quantity | Volume Discount | Number of pins (Pole) | Pins per row | Product size (height) (mm) | Product size (length) (mm) | Product size (width) (mm) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
447.05 € | 200 Pieces Per Package | 1 pack | 4 Days | 2 | 2 | 11.6 | 7.00 | 17.40 | |||
671.15 € | 200 Pieces Per Package | 1 pack | 4 Days | 4 | 4 | 14.00 | 11.60 | 17.40 | |||
666.67 € | 100 Pieces Per Package | 1 pack | 4 Days | 8 | 8 | 17.40 | 11.60 | 28 |
Loading...
Basic information
| Color | Light grey | Contact spacing(mm) | 3.50 | No. of rows | 1 |
|---|---|---|---|---|---|
| Nominal current(A) | 10 | Nominal voltage(V) | 160 | Series (connectors) | 2091 |
| Connection (components) | Connector orientation | Perpendicular (to the PCB) | Connector type | Pin strip, straight | |
| Connectors | wire-to-board | Contact material | Cathode copper | Contact surface | Tin plated |
| Insulation material | Polyphthalamide (PPA GF) | Pin strip type (category) | Pin enclosure - PCB | Industrial goods | Yes |
Configure
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
