GSX MILL 2-Flute Blade 2.5D GSX2C-2.5D
- Volume Discount
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Blade diameter (D) (φ) | Blade length (ℓ) (mm) | Shank diameter (d) (mm) | Overall Length (L) (mm) | O.D. Dc (mm) | |
|---|---|---|---|---|---|---|---|---|---|
40.52 € | 1 | Available | 6 Days | 0.2 | 0.5 | 4 | 40 | 0.2 | |
33.41 € | 1 | Available | 6 Days | 0.3 | 0.8 | 4 | 40 | 0.3 | |
38.89 € | 1 | Available | 6 Days | 0.4 | 1 | 4 | 40 | 0.4 | |
19.73 € | 1 | Available | 6 Days | 0.5 | 1.3 | 4 | 40 | 0.5 | |
29.96 € | 1 | Available | 10 Days | 0.6 | 1.5 | 4 | 40 | 0.6 | |
33.05 € | 1 | Available | 6 Days | 0.7 | 1.8 | 4 | 40 | 0.7 | |
18.80 € | 1 | Available | 6 Days | 0.8 | 2 | 4 | 40 | 0.8 | |
32.20 € | 1 | Available | 6 Days | 0.9 | 2.3 | 4 | 40 | 0.9 | |
41.21 € | 1 | Available | 6 Days | 1.1 | 2.8 | 4 | 40 | 1.1 | |
19.83 € | 1 | Available | 6 Days | 1.2 | 3 | 4 | 40 | 1.2 | |
48.57 € | 1 | Available | 6 Days | 1.3 | 3.3 | 4 | 40 | 1.3 | |
41.21 € | 1 | Available | 6 Days | 1.4 | 3.5 | 4 | 40 | 1.4 | |
18.44 € | 1 | 6 Days | 1.5 | 3.8 | 4 | 40 | 1.5 | ||
41.21 € | 1 | Available | 6 Days | 1.6 | 4 | 4 | 40 | 1.6 | |
41.21 € | 1 | Available | 6 Days | 1.7 | 4.3 | 4 | 40 | 1.7 | |
19.83 € | 1 | Available | 6 Days | 1.8 | 4.5 | 4 | 40 | 1.8 | |
41.21 € | 1 | Available | 6 Days | 1.9 | 4.8 | 4 | 40 | 1.9 | |
25.80 € | 1 | 6 Days | 2 | 5 | 4 | 40 | 2 | ||
43.28 € | 1 | 6 Days | 2.1 | 5.3 | 4 | 40 | 2.1 | ||
41.21 € | 1 | Available | 6 Days | 2.2 | 5.5 | 4 | 40 | 2.2 | |
41.21 € | 1 | Available | 6 Days | 2.3 | 5.8 | 4 | 40 | 2.3 | |
41.21 € | 1 | Available | 6 Days | 2.4 | 6 | 4 | 40 | 2.4 | |
18.44 € | 1 | 6 Days | 2.5 | 6.3 | 4 | 40 | 2.5 | ||
48.60 € | 1 | Available | 6 Days | 2.6 | 6.5 | 4 | 40 | 2.6 | |
58.36 € | 1 | 6 Days | 2.7 | 6.8 | 4 | 40 | 2.7 | ||
48.60 € | 1 | Available | 6 Days | 2.8 | 7 | 4 | 40 | 2.8 | |
48.60 € | 1 | Available | 6 Days | 2.9 | 7.3 | 4 | 40 | 2.9 | |
22.38 € | 1 | Available | 6 Days | 3 | 7.5 | 6 | 45 | 3 | |
49.52 € | 1 | Available | 6 Days | 3.1 | 7.8 | 6 | 45 | 3.1 | |
49.52 € | 1 | Available | 6 Days | 3.2 | 8 | 6 | 45 | 3.2 | |
59.31 € | 1 | 6 Days | 3.3 | 8.3 | 6 | 45 | 3.3 | ||
52.01 € | 1 | 6 Days | 3.4 | 8.5 | 6 | 45 | 3.4 | ||
41.36 € | 1 | 6 Days | 3.5 | 8.8 | 6 | 45 | 3.5 | ||
49.52 € | 1 | Available | 6 Days | 3.6 | 9 | 6 | 45 | 3.6 | |
49.52 € | 1 | Available | 6 Days | 3.7 | 9.3 | 6 | 45 | 3.7 | |
49.52 € | 1 | Available | 6 Days | 3.8 | 9.5 | 6 | 45 | 3.8 | |
49.52 € | 1 | Available | 6 Days | 3.9 | 9.8 | 6 | 45 | 3.9 | |
25.74 € | 1 | Available |
Same day
Stock | 4 | 10 | 6 | 45 | 4 | |
53.64 € | 1 | Available | 6 Days | 4.1 | 10.3 | 6 | 45 | 4.1 | |
53.64 € | 1 | Available | 6 Days | 4.2 | 10.5 | 6 | 45 | 4.2 | |
53.64 € | 1 | Available | 6 Days | 4.3 | 10.8 | 6 | 45 | 4.3 | |
53.64 € | 1 | Available | 6 Days | 4.4 | 11 | 6 | 45 | 4.4 | |
46.44 € | 1 | Available | 6 Days | 4.5 | 11.3 | 6 | 50 | 4.5 | |
53.66 € | 1 | Available | 6 Days | 4.6 | 11.5 | 6 | 50 | 4.6 | |
53.66 € | 1 | Available | 6 Days | 4.7 | 11.8 | 6 | 50 | 4.7 | |
53.66 € | 1 | Available | 6 Days | 4.8 | 12 | 6 | 50 | 4.8 | |
53.66 € | 1 | Available | 6 Days | 4.9 | 12.3 | 6 | 50 | 4.9 | |
27.54 € | 1 | Available | 6 Days | 5 | 12.5 | 6 | 50 | 5 | |
55.71 € | 1 | Available | 6 Days | 5.1 | 12.8 | 6 | 50 | 5.1 | |
55.71 € | 1 | Available | 6 Days | 5.2 | 13 | 6 | 50 | 5.2 | |
55.71 € | 1 | Available | 6 Days | 5.3 | 13.3 | 6 | 50 | 5.3 | |
55.71 € | 1 | Available | 6 Days | 5.4 | 13.5 | 6 | 50 | 5.4 | |
46.44 € | 1 | Available | 9 Days | 5.5 | 13.8 | 6 | 50 | 5.5 | |
55.71 € | 1 | Available | 6 Days | 5.6 | 14 | 6 | 50 | 5.6 | |
55.71 € | 1 | Available | 6 Days | 5.7 | 14.3 | 6 | 50 | 5.7 | |
55.71 € | 1 | Available | 6 Days | 5.8 | 14.5 | 6 | 50 | 5.8 | |
55.71 € | 1 | Available | 6 Days | 5.9 | 14.8 | 6 | 50 | 5.9 | |
30.89 € | 1 | 6 Days | 6 | 15 | 6 | 50 | 6 | ||
69.55 € | 1 | 6 Days | 7 | 17.5 | 8 | 60 | 7 | ||
50.92 € | 1 | 6 Days | 8 | 20 | 8 | 60 | 8 |
Loading...
Basic information
| work material | General Steel / Quenched and tempered steel / High Hardness Steel: to HRC55 / High Hardness Steel: to HRC60 / Stainless Steel / Cast Iron / Titanium | Number of flutes(sheet) | 2 | Type | Square |
|---|---|---|---|---|---|
| Coating | For General Steels (AlCrN, etc.) | Machining Application | Plane / Side / Groove / Inclined Cuts | Blade tip shape | With Lead |
| Torsion Angle (θ) | Standard Helix (30˚ to 40˚) |
Configure
Stock
-
- Show only stock items
Basic Attributes
-
Blade diameter (D)(φ)
-
Blade length (ℓ)(mm)
-
Shank diameter (d)(mm)
-
Overall Length (L)(mm)
-
Type
- GSX2C-2.5D
Filter by standard shipping days
-
- All
- Same day
- 6 Days or Less
- 9 Days or Less
- 10 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
