Carbide Stub Type for Small Diameter / Precision Machining WX-MS-GDS
- Volume Discount
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Hole diameter (drill diameter) Dc (mm) | Groove Length L (mm) | Overall Length L (mm) | Shank Type | Shank diameter (mm) | Tool No. | Tip angle (°) | Thinning | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
49.90 € | 1 | Available | 6 Days | 0.2 | 1.5 | 38 | End Mill Shank | 3 | 3300020 | 140 | NA | |
44.10 € | 1 | Available | 6 Days | 0.3 | 1.5 | 38 | End Mill Shank | 3 | 3300030 | 140 | NA | |
44.10 € | 1 | Available | 6 Days | 0.4 | 2.5 | 38 | End Mill Shank | 3 | 3300040 | 140 | NA | |
48.70 € | 1 | Available | 6 Days | 0.5 | 3 | 38 | End Mill Shank | 3 | 3300050 | 140 | NA | |
33.70 € | 1 | Available | 6 Days | 0.6 | 3.5 | 38 | End Mill Shank | 3 | 3300060 | 140 | NA | |
33.70 € | 1 | Available | 6 Days | 0.7 | 4.5 | 38 | End Mill Shank | 3 | 3300070 | 140 | NA | |
33.70 € | 1 | Available | 6 Days | 0.8 | 5 | 38 | End Mill Shank | 3 | 3300080 | 140 | NA | |
33.70 € | 1 | Available | 6 Days | 0.9 | 5.5 | 38 | End Mill Shank | 3 | 3300090 | 140 | NA | |
48.92 € | 1 | Available | 6 Days | 0.19 | 1.2 | 38 | End Mill Shank | 3 | - | 120 | NA | |
56.40 € | 1 | Available | 6 Days | 0.21 | 1.5 | 38 | End Mill Shank | 3 | 3300021 | 140 | NA | |
56.40 € | 1 | Available | 6 Days | 0.22 | 1.5 | 38 | End Mill Shank | 3 | 3300022 | 140 | NA | |
56.40 € | 1 | Available | 6 Days | 0.23 | 1.5 | 38 | End Mill Shank | 3 | 3300023 | 140 | NA | |
56.40 € | 1 | Available | 6 Days | 0.24 | 1.5 | 38 | End Mill Shank | 3 | 3300024 | 140 | NA | |
56.40 € | 1 | Available | 6 Days | 0.25 | 1.5 | 38 | End Mill Shank | 3 | 3300025 | 140 | NA | |
53.90 € | 1 | Available | 6 Days | 0.26 | 1.5 | 38 | End Mill Shank | 3 | 3300026 | 140 | NA | |
53.90 € | 1 | Available | 6 Days | 0.27 | 1.5 | 38 | End Mill Shank | 3 | 3300027 | 140 | NA | |
53.90 € | 1 | Available | 6 Days | 0.28 | 1.5 | 38 | End Mill Shank | 3 | 3300028 | 140 | NA | |
53.90 € | 1 | Available | 6 Days | 0.29 | 1.5 | 38 | End Mill Shank | 3 | 3300029 | 140 | NA | |
53.90 € | 1 | Available | 6 Days | 0.31 | 2 | 38 | End Mill Shank | 3 | 3300031 | 140 | NA | |
53.90 € | 1 | Available | 6 Days | 0.32 | 2 | 38 | End Mill Shank | 3 | 3300032 | 140 | NA | |
53.90 € | 1 | Available | 6 Days | 0.33 | 2 | 38 | End Mill Shank | 3 | 3300033 | 140 | NA | |
53.90 € | 1 | Available | 6 Days | 0.34 | 2 | 38 | End Mill Shank | 3 | 3300034 | 140 | NA | |
48.70 € | 1 | Available | 6 Days | 0.35 | 2 | 38 | End Mill Shank | 3 | 3300035 | 140 | NA | |
53.90 € | 1 | Available | 6 Days | 0.36 | 2 | 38 | End Mill Shank | 3 | 3300036 | 140 | NA | |
53.90 € | 1 | Available | 6 Days | 0.37 | 2 | 38 | End Mill Shank | 3 | 3300037 | 140 | NA | |
53.90 € | 1 | Available | 6 Days | 0.38 | 2 | 38 | End Mill Shank | 3 | 3300038 | 140 | NA | |
53.90 € | 1 | Available | 6 Days | 0.39 | 2.5 | 38 | End Mill Shank | 3 | 3300039 | 140 | NA | |
53.90 € | 1 | Available | 6 Days | 0.41 | 2.5 | 38 | End Mill Shank | 3 | 3300041 | 140 | NA | |
53.90 € | 1 | Available | 6 Days | 0.42 | 2.5 | 38 | End Mill Shank | 3 | 3300042 | 140 | NA | |
53.90 € | 1 | Available | 6 Days | 0.43 | 2.5 | 38 | End Mill Shank | 3 | 3300043 | 140 | NA | |
53.90 € | 1 | Available | 6 Days | 0.44 | 2.5 | 38 | End Mill Shank | 3 | 3300044 | 140 | NA | |
48.70 € | 1 | Available | 6 Days | 0.45 | 2.5 | 38 | End Mill Shank | 3 | 3300045 | 140 | NA | |
53.90 € | 1 | Available | 6 Days | 0.46 | 2.5 | 38 | End Mill Shank | 3 | 3300046 | 140 | NA | |
53.90 € | 1 | Available | 6 Days | 0.47 | 2.5 | 38 | End Mill Shank | 3 | 3300047 | 140 | NA | |
53.90 € | 1 | Available | 6 Days | 0.48 | 2.5 | 38 | End Mill Shank | 3 | 3300048 | 140 | NA | |
53.90 € | 1 | Available | 6 Days | 0.49 | 3 | 38 | End Mill Shank | 3 | 3300049 | 140 | NA | |
48.70 € | 1 | Available | 6 Days | 0.51 | 3 | 38 | End Mill Shank | 3 | 3300051 | 140 | NA | |
48.70 € | 1 | Available | 6 Days | 0.52 | 3 | 38 | End Mill Shank | 3 | 3300052 | 140 | NA | |
48.70 € | 1 | Available | 6 Days | 0.53 | 3 | 38 | End Mill Shank | 3 | 3300053 | 140 | NA | |
48.70 € | 1 | Available | 6 Days | 0.54 | 3.5 | 38 | End Mill Shank | 3 | 3300054 | 140 | NA | |
38.90 € | 1 | Available | 6 Days | 0.55 | 3.5 | 38 | End Mill Shank | 3 | 3300055 | 140 | NA | |
48.70 € | 1 | Available | 6 Days | 0.56 | 3.5 | 38 | End Mill Shank | 3 | 3300056 | 140 | NA | |
48.70 € | 1 | Available | 6 Days | 0.57 | 3.5 | 38 | End Mill Shank | 3 | 3300057 | 140 | NA | |
48.70 € | 1 | Available | 6 Days | 0.58 | 3.5 | 38 | End Mill Shank | 3 | 3300058 | 140 | NA | |
48.70 € | 1 | Available | 6 Days | 0.59 | 3.5 | 38 | End Mill Shank | 3 | 3300059 | 140 | NA | |
48.70 € | 1 | Available | 6 Days | 0.61 | 4 | 38 | End Mill Shank | 3 | 3300061 | 140 | NA | |
48.70 € | 1 | Available | 6 Days | 0.62 | 4 | 38 | End Mill Shank | 3 | 3300062 | 140 | NA | |
48.70 € | 1 | Available | 6 Days | 0.63 | 4 | 38 | End Mill Shank | 3 | 3300063 | 140 | NA | |
48.70 € | 1 | Available | 6 Days | 0.64 | 4 | 38 | End Mill Shank | 3 | 3300064 | 140 | NA | |
38.90 € | 1 | Available | 6 Days | 0.65 | 4 | 38 | End Mill Shank | 3 | 3300065 | 140 | NA | |
48.70 € | 1 | Available | 6 Days | 0.66 | 4 | 38 | End Mill Shank | 3 | 3300066 | 140 | NA | |
48.70 € | 1 | Available | 6 Days | 0.67 | 4 | 38 | End Mill Shank | 3 | 3300067 | 140 | NA | |
48.70 € | 1 | Available | 6 Days | 0.68 | 4.5 | 38 | End Mill Shank | 3 | 3300068 | 140 | NA | |
48.70 € | 1 | Available | 6 Days | 0.69 | 4.5 | 38 | End Mill Shank | 3 | 3300069 | 140 | NA | |
48.70 € | 1 | Available | 6 Days | 0.71 | 4.5 | 38 | End Mill Shank | 3 | 3300071 | 140 | NA | |
48.70 € | 1 | Available | 6 Days | 0.72 | 4.5 | 38 | End Mill Shank | 3 | 3300072 | 140 | NA | |
48.70 € | 1 | Available | 6 Days | 0.73 | 4.5 | 38 | End Mill Shank | 3 | 3300073 | 140 | NA | |
48.70 € | 1 | Available | 6 Days | 0.74 | 4.5 | 38 | End Mill Shank | 3 | 3300074 | 140 | NA | |
38.90 € | 1 | Available | 6 Days | 0.75 | 4.5 | 38 | End Mill Shank | 3 | 3300075 | 140 | NA | |
48.70 € | 1 | Available | 6 Days | 0.76 | 5 | 38 | End Mill Shank | 3 | 3300076 | 140 | NA |
Loading...
Basic information
| Work material | General steel / Stainless Steel / Cast Iron / Aluminum / Copper | Tool Material Type | Carbide | Coating Y/N | Available |
|---|---|---|---|---|---|
| Coating Type | Other | With/without Oil Hole | N/A | Coating Details | WX coated |
Configure
Stock
-
- Show only stock items
Basic Attributes
-
Hole diameter (drill diameter) Dc(mm)
- 0.19
- 0.2
- 0.21
- 0.22
- 0.23
- 0.24
- 0.25
- 0.26
- 0.27
- 0.28
- 0.29
- 0.3
- 0.31
- 0.32
- 0.33
- 0.34
- 0.35
- 0.36
- 0.37
- 0.38
- 0.39
- 0.4
- 0.41
- 0.42
- 0.43
- 0.44
- 0.45
- 0.46
- 0.47
- 0.48
- 0.49
- 0.5
- 0.51
- 0.52
- 0.53
- 0.54
- 0.55
- 0.56
- 0.57
- 0.58
- 0.59
- 0.6
- 0.61
- 0.62
- 0.63
- 0.64
- 0.65
- 0.66
- 0.67
- 0.68
- 0.69
- 0.7
- 0.71
- 0.72
- 0.73
- 0.74
- 0.75
- 0.76
- 0.77
- 0.78
- 0.79
- 0.8
- 0.81
- 0.82
- 0.83
- 0.84
- 0.85
- 0.86
- 0.87
- 0.88
- 0.89
- 0.9
- 0.91
- 0.92
- 0.93
- 0.94
- 0.95
- 0.96
- 0.97
- 0.98
- 0.99
- 1
- 1.01
- 1.02
- 1.03
- 1.04
- 1.05
- 1.06
- 1.07
- 1.08
- 1.09
- 1.1
- 1.11
- 1.12
- 1.13
- 1.14
- 1.15
- 1.16
- 1.17
- 1.18
- 1.19
- 1.2
- 1.21
- 1.22
- 1.23
- 1.24
- 1.25
- 1.26
- 1.27
- 1.28
- 1.29
- 1.3
- 1.31
- 1.32
- 1.33
- 1.34
- 1.35
- 1.36
- 1.37
- 1.38
- 1.39
- 1.4
- 1.41
- 1.42
- 1.43
- 1.44
- 1.45
- 1.46
- 1.47
- 1.48
- 1.49
- 1.5
- 1.51
- 1.52
- 1.53
- 1.54
- 1.55
- 1.56
- 1.57
- 1.58
- 1.59
- 1.6
- 1.61
- 1.62
- 1.63
- 1.64
- 1.65
- 1.66
- 1.67
- 1.68
- 1.69
- 1.7
- 1.71
- 1.72
- 1.73
- 1.74
- 1.75
- 1.76
- 1.77
- 1.78
- 1.79
- 1.8
- 1.81
- 1.82
- 1.83
- 1.84
- 1.85
- 1.86
- 1.87
- 1.88
- 1.89
- 1.9
- 1.91
- 1.92
- 1.93
- 1.94
- 1.95
- 1.96
- 1.97
- 1.98
- 1.99
- 2
- 2.05
- 2.1
- 2.15
- 2.2
- 2.23
- 2.25
- 2.3
- 2.35
- 2.4
- 2.45
- 2.5
- 2.55
- 2.6
- 2.65
- 2.7
- 2.75
- 2.78
- 2.8
- 2.85
- 2.9
- 2.95
- 3
- 3.05
- 3.1
- 3.15
- 3.2
- 3.25
- 3.3
- 3.33
- 3.35
- 3.37
- 3.4
- 3.45
- 3.5
- 3.55
- 3.6
- 3.65
- 3.7
- 3.75
- 3.8
- 3.85
- 3.9
- 3.95
- 3.98
- 4
- 4.05
- 4.1
- 4.15
- 4.2
- 4.25
- 4.3
- 4.35
- 4.4
- 4.45
- 4.5
- 4.55
- 4.6
- 4.65
- 4.7
- 4.75
- 4.8
- 4.85
- 4.9
- 4.95
- 5
-
Groove Length L(mm)
-
Overall Length L(mm)
-
Shank Type
- End Mill Shank
- Straight shank
-
Shank diameter(mm)
-
Tool No.
- 3300020
- 3300021
- 3300022
- 3300023
- 3300024
- 3300025
- 3300026
- 3300027
- 3300028
- 3300029
- 3300030
- 3300031
- 3300032
- 3300033
- 3300034
- 3300035
- 3300036
- 3300037
- 3300038
- 3300039
- 3300040
- 3300041
- 3300042
- 3300043
- 3300044
- 3300045
- 3300046
- 3300047
- 3300048
- 3300049
- 3300050
- 3300051
- 3300052
- 3300053
- 3300054
- 3300055
- 3300056
- 3300057
- 3300058
- 3300059
- 3300060
- 3300061
- 3300062
- 3300063
- 3300064
- 3300065
- 3300066
- 3300067
- 3300068
- 3300069
- 3300070
- 3300071
- 3300072
- 3300073
- 3300074
- 3300075
- 3300076
- 3300077
- 3300078
- 3300079
- 3300080
- 3300081
- 3300082
- 3300083
- 3300084
- 3300085
- 3300086
- 3300087
- 3300088
- 3300089
- 3300090
- 3300091
- 3300092
- 3300093
- 3300094
- 3300095
- 3300096
- 3300097
- 3300098
- 3300099
- 3300100
- 3300101
- 3300102
- 3300103
- 3300104
- 3300105
- 3300106
- 3300107
- 3300108
- 3300109
- 3300110
- 3300111
- 3300112
- 3300113
- 3300114
- 3300115
- 3300116
- 3300117
- 3300118
- 3300119
- 3300120
- 3300121
- 3300122
- 3300123
- 3300124
- 3300125
- 3300126
- 3300127
- 3300128
- 3300129
- 3300130
- 3300131
- 3300132
- 3300133
- 3300134
- 3300135
- 3300136
- 3300137
- 3300138
- 3300139
- 3300140
- 3300141
- 3300142
- 3300143
- 3300144
- 3300145
- 3300146
- 3300147
- 3300148
- 3300149
- 3300150
- 3300151
- 3300152
- 3300153
- 3300154
- 3300155
- 3300156
- 3300157
- 3300158
- 3300159
- 3300160
- 3300161
- 3300162
- 3300163
- 3300164
- 3300165
- 3300166
- 3300167
- 3300168
- 3300169
- 3300170
- 3300171
- 3300172
- 3300173
- 3300174
- 3300175
- 3300176
- 3300177
- 3300178
- 3300179
- 3300180
- 3300181
- 3300182
- 3300183
- 3300184
- 3300185
- 3300186
- 3300187
- 3300188
- 3300189
- 3300190
- 3300191
- 3300192
- 3300193
- 3300194
- 3300195
- 3300196
- 3300197
- 3300198
- 3300199
- 3300200
- 3300205
- 3300210
- 3300215
- 3300220
- 3300225
- 3300230
- 3300235
- 3300240
- 3300245
- 3300250
- 3300255
- 3300260
- 3300265
- 3300270
- 3300275
- 3300280
- 3300285
- 3300290
- 3300295
- 3300300
- 3300305
- 3300310
- 3300315
- 3300320
- 3300325
- 3300330
- 3300335
- 3300340
- 3300345
- 3300350
- 3300355
- 3300360
- 3300365
- 3300370
- 3300375
- 3300380
- 3300385
- 3300390
- 3300395
- 3300400
- 3300405
- 3300410
- 3300415
- 3300420
- 3300425
- 3300430
- 3300435
- 3300440
- 3300445
- 3300450
- 3300455
- 3300460
- 3300465
- 3300470
- 3300475
- 3300480
- 3300485
- 3300490
- 3300495
- 3300500
-
Type
- WX-MS-GDS
Filter by standard shipping days
-
- All
- Same day
- 6 Days or Less
- 8 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
