SG Spiral Tap SGSP
- Volume Discount
-Demonstrates excellent performance in a variety of materials, machining equipment and a wide range of cutting conditions.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Nominal | Pitch, Number of Threading (mm) | Overall Length (L) (mm) | shank diameter Ds (mm) | Class TAP Limit | Thread Length l (mm) | Number of Grooves Flutes | Under-head Length Ln (mm) | Neck diameter dn (mm) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
33.74 € | 1 | Available | 6 Days | M2 | 0.4 | 40 | 3 | REG P1.5 | 8 | 3 | 15 | 2.1 | |
47.85 € | 1 | Available | 6 Days | M2 | 0.25 | 40 | 3 | REG P1 | 8 | 3 | 15 | 2.1 | |
53.49 € | 1 | Available | 6 Days | M2.2 | 0.25 | 42 | 3 | REG P1 | 9.5 | 3 | 15 | 2.3 | |
35.62 € | 1 | Available | 6 Days | M2.2 | 0.45 | 42 | 3 | REG P2 | 9.5 | 3 | 15 | 2.3 | |
31.70 € | 1 | Available | 6 Days | M2.3 | 0.4 | 42 | 3 | REG P1.5 | 9.5 | 3 | 15 | 2.4 | |
40.63 € | 1 | Available | 6 Days | M2.5 | 0.35 | - | 3 | REG P1.5 | 9.5 | 3 | 16 | 2.6 | |
29.63 € | 1 | Available | 6 Days | M2.5 | 0.45 | - | 3 | REG P2 | 9.5 | 3 | 16 | 2.6 | |
27.76 € | 1 | Available | 6 Days | M2.6 | 0.45 | - | 3 | REG P2 | 9.5 | 3 | 16 | 2.7 | |
23.56 € | 1 | Available | 6 Days | M3 | 0.5 | 46 | 4 | ＲＥＧ Ｐ2 | 3.5 | 3 | 18 | 2.35 | |
33.12 € | 1 | Available | 6 Days | M3 | 0.35 | - | 4 | REG P2 | 3.5 | 3 | 18 | 2.55 | |
26.33 € | 1 | Available | 6 Days | M3.5 | 0.6 | - | 4 | REG P2 | 4.2 | 3 | 18 | 2.75 | |
37.22 € | 1 | Available | 6 Days | M3.5 | 0.35 | - | 4 | REG P2 | 4.2 | 3 | 18 | 2.95 | |
28.82 € | 1 | Available | 6 Days | M4 | 0.5 | - | 5 | REG P2 | 4.9 | 3 | 20 | 3.35 | |
25.04 € | 1 | 6 Days | M4 | 0.7 | 52 | 5 | ＲＥＧ Ｐ3 | 4.9 | 3 | 20 | 3.15 | ||
33.47 € | 1 | Available | 6 Days | M4.5 | 0.5 | - | 5 | REG P2 | 5.3 | 3 | 20 | 3.85 | |
28.48 € | 1 | Available | 6 Days | M4.5 | 0.75 | - | 5 | REG P2 | 5.3 | 3 | 20 | 3.55 | |
29.91 € | 1 | Available | 9 Days | M5 | 0.5 | - | 5.5 | REG P2 | 5.6 | 3 | 22 | 4.35 | |
23.37 € | 1 | Available | 6 Days | M5 | 0.8 | 60 | 5.5 | ＲＥＧ Ｐ3 | 5.6 | 3 | 22 | 4.05 | |
34.83 € | 1 | Available | 6 Days | M5.5 | 0.5 | - | 5.5 | REG P2 | 6.3 | 3 | 23 | 4.85 | |
33.47 € | 1 | Available | 6 Days | M6 | 0.5 | - | 6 | REG P2 | 7 | 3 | 24 | 5.35 | |
29.91 € | 1 | Available | 6 Days | M6 | 0.75 | - | 6 | REG P2 | 7 | 3 | 24 | 5.05 | |
24.01 € | 1 | Available | 6 Days | M6 | 1 | 62 | 6 | ＲＥＧ Ｐ3 | 7 | 3 | 24 | 4.75 | |
38.48 € | 1 | Available | 6 Days | M7 | 0.75 | - | 6.2 | REG P2 | 7 | 3 | 26 | 6.05 | |
31.15 € | 1 | Available | 6 Days | M7 | 1 | - | 6.2 | REG P3 | 7 | 3 | 26 | 5.75 | |
40.35 € | 1 | Available | 6 Days | M8 | 0.75 | - | 6.2 | REG P3 | 8.8 | 3 | 29.8 | 6.75 | |
36.77 € | 1 | Available | 6 Days | M8 | 1 | 70 | 6.2 | ＲＥＧ Ｐ3 | 8.8 | 3 | 29.8 | 6.75 | |
31.25 € | 1 | Available | 6 Days | M8 | 1.25 | 70 | 6.2 | ＲＥＧ Ｐ3 | 8.8 | 3 | 29.8 | 6.55 | |
48.76 € | 1 | Available | 6 Days | M9 | 0.75 | 72 | 7 | REG P3 | 8.8 | 3 | 29.8 | 8.05 | |
44.82 € | 1 | Available | 6 Days | M9 | 1 | 72 | 7 | REG P3 | 8.8 | 3 | 29.8 | 7.75 | |
38.20 € | 1 | Available | 6 Days | M9 | - | 72 | 7 | REG P3 | 8.8 | 3 | 29.8 | 7.55 | |
49.81 € | 1 | Available | 6 Days | - | 0.75 | - | 7 | REG P3 | 10.5 | 3 | 31.4 | 9.05 | |
44.91 € | 1 | Available | 6 Days | - | 1 | - | 7 | REG P3 | 10.5 | 3 | 31.4 | 8.75 | |
37.75 € | 1 | Available | 6 Days | M10 | 1.5 | 75 | 7 | ＲＥＧ Ｐ3 | 10.5 | 3 | 31.4 | 8.25 | |
37.75 € | 1 | Available | 6 Days | M10 | 1.25 | 75 | 7 | ＲＥＧ Ｐ3 | 10.5 | 3 | 31.4 | 8.55 | |
62.32 € | 1 | Available | 6 Days | M11 | 0.75 | - | 8 | REG P3 | 10.5 | 3 | 31.4 | 10.05 | |
56.78 € | 1 | Available | 6 Days | M11 | 1 | - | 8 | REG P3 | 10.5 | 3 | 31.4 | 9.75 | |
46.87 € | 1 | Available | 6 Days | M11 | - | - | 8 | REG P3 | 10.5 | 3 | 31.4 | 9.25 | |
54.73 € | 1 | Available | 6 Days | - | 1 | 82 | 8.5 | REG P3 | 12.3 | 3 | 36.2 | 10.75 | |
54.20 € | 1 | 6 Days | M12 | 1.5 | 82 | 8.5 | ＲＥＧ Ｐ3 | 12.3 | 3 | 36.2 | 10.25 | ||
49.28 € | 1 | Available | 6 Days | - | - | 82 | 8.5 | REG P3 | 12.3 | 3 | 36.2 | 10.55 | |
49.28 € | 1 | Available | 6 Days | M12 | 1.75 | 82 | 8.5 | ＲＥＧ Ｐ4 | 12.3 | 3 | 36.2 | 9.95 | |
75.02 € | 1 | Available | 6 Days | - | 1 | - | 10.5 | REG P3 | 14 | 3 | 42.4 | 12.75 | |
70.37 € | 1 | Available | 6 Days | - | - | - | 10.5 | REG P3 | 14 | 3 | 42.4 | 12.25 | |
73.59 € | 1 | Available | 6 Days | - | - | - | 10.5 | REG P3 | 14 | 3 | 42.4 | 12.55 | |
70.37 € | 1 | Available | 6 Days | - | 2 | - | 10.5 | REG P4 | 14 | 3 | 42.4 | 11.65 | |
98.33 € | 1 | 6 Days | M15 | 1 | 90 | 10.5 | REG P3 | 10.5 | 3 | 42.4 | 13.75 | ||
91.18 € | 1 | 6 Days | M15 | - | 90 | 10.5 | REG P3 | 10.5 | 3 | 42.4 | 13.25 | ||
97.43 € | 1 | 6 Days | - | 1 | - | 12.5 | REG P3 | 14 | 3 | 44.4 | 14.75 | ||
91.18 € | 1 | 9 Days | M16 | 1.5 | 95 | 12.5 | ＲＥＧ Ｐ3 | 14 | 3 | 44.4 | 14.25 | ||
91.18 € | 1 | 6 Days | M16 | 2 | 95 | 12.5 | ＲＥＧ Ｐ4 | 14 | 3 | 44.4 | 13.65 | ||
96.78 € | 1 | 6 Days | M17 | 1 | - | 13 | REG P3 | 10.5 | 3 | 44.4 | 15.75 | ||
121.55 € | 1 | 6 Days | M17 | - | - | 13 | REG P3 | 10.5 | 3 | 44.4 | 15.25 | ||
101.77 € | 1 | 6 Days | - | 1 | - | 14 | REG P3 | 17.5 | 3 | 49.2 | 16.75 | ||
118.88 € | 1 | 6 Days | - | - | - | 14 | REG P4 | 17.5 | 3 | 49.2 | 16.25 | ||
121.55 € | 1 | 6 Days | - | 2 | - | 14 | REG P4 | 17.5 | 3 | 49.2 | 15.65 | ||
118.88 € | 1 | 6 Days | M18 | 2.5 | 100 | 14 | ＲＥＧ Ｐ5 | 17.5 | 3 | 49.2 | 15.15 | ||
118.62 € | 1 | 6 Days | - | 1 | - | 15 | REG P3 | 17.5 | 4 | 50.7 | 18.75 | ||
103.64 € | 1 | 6 Days | - | - | - | 15 | REG P4 | 17.5 | 4 | 50.7 | 18.25 | ||
111.13 € | 1 | 6 Days | - | 2 | - | 15 | REG P4 | 17.5 | 4 | 50.7 | 17.65 | ||
103.64 € | 1 | 6 Days | M20 | 2.5 | 105 | 15 | ＲＥＧ Ｐ5 | 17.5 | 4 | 50.7 | 17.15 |
Loading...
Basic information
| Screw Types | Meter | Chamfer threads | 2.5 | Tool Material Type | Alloy HSS |
|---|---|---|---|---|---|
| work material | Low-Carbon Steel (carbon alloy less than 0.25%) / Medium carbon steel (carbon content 0.25 to 0.45%) / High Carbon Steel (C with a content over 0.45%) / Alloy Steel (SCM) / Stainless Steel (JIS-SUS) / Quenched and tempered steel (25 to 35 HRC) / Quenched and tempered steel (35 to 45 HRC) / Ductile Cast Iron (FCD) / Copper (Cu) / Aluminum Rolled Material (AL) / Aluminum Alloy Casting (AC, ADC) | Tap Type | Spiral Tap | Hole type | For through hole / For blind hole |
| Coating Y/N | Available | Surface Treatment | TiCN |
Configure
Basic Attributes
-
Nominal
-
Pitch, Number of Threading(mm)
-
Overall Length (L)(mm)
-
shank diameter Ds(mm)
-
Class TAP Limit
- REG P1
- REG P1.5
- REG P2
- ＲＥＧ Ｐ2
- REG P3
- ＲＥＧ Ｐ3
- REG P4
- ＲＥＧ Ｐ4
- ＲＥＧ Ｐ5
-
Thread Length l(mm)
-
Number of Grooves Flutes
- 3
- 4
-
Under-head Length Ln(mm)
-
Neck diameter dn(mm)
- 2.1
- 2.3
- 2.35
- 2.4
- 2.55
- 2.6
- 2.7
- 2.75
- 2.95
- 3.15
- 3.35
- 3.55
- 3.85
- 4.05
- 4.35
- 4.75
- 4.85
- 5.05
- 5.35
- 5.75
- 6.05
- 6.55
- 6.75
- 7.55
- 7.75
- 8.05
- 8.25
- 8.55
- 8.75
- 9.05
- 9.25
- 9.75
- 9.95
- 10.05
- 10.25
- 10.55
- 10.75
- 11.65
- 12.25
- 12.55
- 12.75
- 13.25
- 13.65
- 13.75
- 14.25
- 14.75
- 15.15
- 15.25
- 15.65
- 15.75
- 16.25
- 16.75
- 17.15
- 17.65
- 18.25
- 18.75
- 19.15
- 19.65
- 20.25
- 20.65
- 20.75
- 21.65
- 22.25
- 22.75
-
Type
- SGSP
Filter by standard shipping days
-
- All
- 6 Days or Less
- 9 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
