MISUMI

Head support sleeve for piercing punches

Head support sleeve for piercing punches

Mouse over image to enlarge

Part number:

Still undefined. 10 possible part numbers found.
Quantity:

Outline drawing

Part number list

Number of items
  • 1
    • Part number
    PWA3-[0.5,1,2,3,4,5]
    PWA4-[0.5,1,2,3,4,5]
    PWA5-[0.5,1,2,3,4,5]
    PWA6-[0.5,1,2,3,4,5]
    PWA8-[0.5,1,2,3,4,5]
    PWA10-[0.5,1,2,3,4,5]
    PWA13-[0.5,1,2,3,4,5]
    PWA16-[1-5/1]
    PWA20-[1-5/1]
    PWA25-[1-5/1]

    d (Inner diameter)

    (mm)

    T (Thickness)

    (mm)

    		RoHS?Minimum order quantity
    3
    0.5 ～ 5
    10
    1 pieces
    4
    0.5 ～ 5
    10
    1 pieces
    5
    0.5 ～ 5
    10
    1 pieces
    6
    0.5 ～ 5
    10
    1 pieces
    8
    0.5 ～ 5
    10
    1 pieces
    10
    0.5 ～ 5
    10
    1 pieces
    13
    0.5 ～ 5
    10
    1 pieces
    16
    1 ～ 5
    10
    1 pieces
    20
    1 ～ 5
    10
    1 pieces
    25
    1 ～ 5
    10
    1 pieces
    Unit price (excluding VAT)(Unit price including VAT)
    Standard shipping days
    -
    ( - )
    Quote
    -
    ( - )
    Quote
    -
    ( - )
    Quote
    -
    ( - )
    Quote
    -
    ( - )
    Quote
    -
    ( - )
    Quote
    -
    ( - )
    Quote
    -
    ( - )
    Quote
    -
    ( - )
    Quote
    -
    ( - )
    Quote
  • 1

    • More Information
