Elastomer springs / cylindrical / low rebound / polyurethane A70

Click image to view enlarged image

• CatalogP.1514

• Outline drawing
• Part number list
• More Information
• Catalog

Outline drawing

Part number list

Number of items

30 items60 items90 items

1

Part number

AN20-25

AN20-30

AN20-35

AN20-40

AN25-25

AN25-30

AN25-35

AN25-40

AN25-45

AN25-50

AN30-30

AN30-35

AN30-40

AN30-45

AN30-50

AN30-55

AN30-60

AN40-40

AN40-50

AN40-60

AN50-50

AN50-60

AN50-80

AN60-50

AN60-60

AN60-80

Maximum load (N)	L Dimension (L) (mm)	D (Outer diameter) (mm)	Minimum order quantity

617	25	20	1 pieces
617	30	20	1 pieces
617	35	20	1 pieces
617	40	20	1 pieces
912	25	25	1 pieces
912	30	25	1 pieces
912	35	25	1 pieces
912	40	25	1 pieces
912	45	25	1 pieces
912	50	25	1 pieces
1245	30	30	1 pieces
1245	35	30	1 pieces
1245	40	30	1 pieces
1245	45	30	1 pieces
1245	50	30	1 pieces
1245	55	30	1 pieces
1245	60	30	1 pieces
2549	40	40	1 pieces
2549	50	40	1 pieces
2549	60	40	1 pieces
4028	50	50	1 pieces
4028	60	50	1 pieces
4028	80	50	1 pieces
5962	50	60	1 pieces
5962	60	60	1 pieces
5962	80	60	1 pieces

Unit price (excluding VAT)(Unit price including VAT) Sort by	Standard shipping days Sort by

- ( - )	Quote
- ( - )	Quote
- ( - )	Quote
- ( - )	Quote
- ( - )	Quote
- ( - )	Quote
- ( - )	Quote
- ( - )	Quote
- ( - )	Quote
- ( - )	Quote
- ( - )	Quote
- ( - )	Quote
- ( - )	Quote
- ( - )	Quote
- ( - )	Quote
- ( - )	Quote
- ( - )	Quote
- ( - )	Quote
- ( - )	Quote
- ( - )	Quote
- ( - )	Quote
- ( - )	Quote
- ( - )	Quote
- ( - )	Quote
- ( - )	Quote
- ( - )	Quote

1
