Cutting punches / conical head 45° / bead breaker pin / RW
Click on this image to zoom in.
Click on this image to zoom in.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Drawing
- 3D Preview 3D preview is available after complete configuration
- Part Numbers
- Catalog
Part Number:
- In order to open the 3D preview, the part number must be fixed.
3D preview is not available, because the part number has not yet been determined.
Loading...
| Part Number | Minimum order quantity | Volume Discount | RoHS | Material | B (Tip length) | D (Shank diameter) (mm) | L (L dimension) (mm) | P | |
|---|---|---|---|---|---|---|---|---|---|
| 1 | Quote | 10 | Powdered high-speed steel | L | 8 | 60 ～ 80 | 4 ～ 7.99 | ||
| 1 | Quote | 10 | Powdered high-speed steel | L | 10 | 60 ～ 90 | 5 ～ 9.99 | ||
| 1 | Quote | 10 | Powdered high-speed steel | L | 13 | 70 ～ 100 | 6 ～ 12.99 | ||
| 1 | Quote | 10 | Powdered high-speed steel | L | 16 | 70 ～ 100 | 10 ～ 15.99 | ||
| 1 | Quote | 10 | Powdered high-speed steel | S | 8 | 50 ～ 80 | 4 ～ 7.99 | ||
| 1 | Quote | 10 | Powdered high-speed steel | S | 10 | 55 ～ 90 | 5 ～ 9.99 | ||
| 1 | Quote | 10 | Powdered high-speed steel | S | 13 | 65 ～ 100 | 6 ～ 12.99 | ||
| 1 | Quote | 10 | Powdered high-speed steel | S | 16 | 65 ～ 100 | 10 ～ 15.99 | ||
| 1 | Quote | 10 | SKH51 Equivalent | L | 8 | 60 ～ 80 | 4 ～ 7.99 | ||
| 1 | Quote | 10 | SKH51 Equivalent | L | 10 | 60 ～ 90 | 5 ～ 9.99 | ||
| 1 | Quote | 10 | SKH51 Equivalent | L | 13 | 70 ～ 100 | 6 ～ 12.99 | ||
| 1 | Quote | 10 | SKH51 Equivalent | L | 16 | 70 ～ 100 | 10 ～ 15.99 | ||
| 1 | Quote | 10 | SKH51 Equivalent | S | 8 | 50 ～ 80 | 4 ～ 7.99 | ||
| 1 | Quote | 10 | SKH51 Equivalent | S | 10 | 55 ～ 90 | 5 ～ 9.99 | ||
| 1 | Quote | 10 | SKH51 Equivalent | S | 13 | 65 ～ 100 | 6 ～ 12.99 | ||
| 1 | Quote | 10 | SKH51 Equivalent | S | 16 | 65 ～ 100 | 10 ～ 15.99 |
Loading...
Basic information
| Heavy-load punches | Yes | Shank type | Single-stepped | Jector | Standard type |
|---|---|---|---|---|---|
| Tip shape | A | Surface treatment | RW coating | Shank (mounting part) shape | Tapered head |
| Shank diameter D tolerance | m5 |
Configure
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
