Press Die Components
Punches & Dies
Pilot Punches
Straight Pilot Punches
Pilot pins / cylindrical head / immersion side selectable

Configure

Tip shape
- Tip R
- Tapered tip
Material
- SKD11 Equivalent
- Powdered high-speed steel
No. (Nominal diameter)(mm)
- 1.6
- 2.0
- 2.5
- 3
- 4
- 5
- 6
- 8
- 10
- 13
- 16
- 20
- 25
L (L dimension)(mm)
[42-102/10mm units]
LC (Full length alteration)(mm)
[25-101.9/0.1mm units]
LCT (Head thickness tolerance change + Total length alteration)(mm)
[25-101.9/0.1mm units]
LMT (Head thickness tolerance change + Total length alteration)(mm)
[25-101.9/0.1mm units]
P (Tip dimension)(mm)
[1-25/0.01mm units]
Type
- PSTC
- PTTC
- STC
- TTC
CAD
- 2D
- 3D

Pilot pins / cylindrical head / immersion side selectable

Tip R	Powdered high-speed steel	1.6	42 ～ 62	-	-	-	1 ～ 1.6	10	1 pieces
Tip R	Powdered high-speed steel	1.6	-	25 ～ 61.9	-	-	1 ～ 1.6	10	1 pieces
Tip R	Powdered high-speed steel	1.6	-	-	25 ～ 61.9	-	1 ～ 1.6	10	1 pieces
Tip R	Powdered high-speed steel	1.6	-	-	-	25 ～ 61.9	1 ～ 1.6	10	1 pieces
Tip R	Powdered high-speed steel	2.0	42 ～ 62	-	-	-	1 ～ 2	10	1 pieces
Tip R	Powdered high-speed steel	2.0	-	25 ～ 61.9	-	-	1 ～ 2	10	1 pieces
Tip R	Powdered high-speed steel	2.0	-	-	25 ～ 61.9	-	1 ～ 2	10	1 pieces
Tip R	Powdered high-speed steel	2.0	-	-	-	25 ～ 61.9	1 ～ 2	10	1 pieces
Tip R	Powdered high-speed steel	2.5	42 ～ 62	-	-	-	1.5 ～ 2.5	10	1 pieces
Tip R	Powdered high-speed steel	2.5	-	25 ～ 61.9	-	-	1.5 ～ 2.5	10	1 pieces
Tip R	Powdered high-speed steel	2.5	-	-	25 ～ 61.9	-	1.5 ～ 2.5	10	1 pieces
Tip R	Powdered high-speed steel	2.5	-	-	-	25 ～ 61.9	1.5 ～ 2.5	10	1 pieces
Tip R	Powdered high-speed steel	3	42 ～ 92	-	-	-	2 ～ 3	10	1 pieces
Tip R	Powdered high-speed steel	3	-	25 ～ 91.9	-	-	2 ～ 3	10	1 pieces
Tip R	Powdered high-speed steel	3	-	-	25 ～ 91.9	-	2 ～ 3	10	1 pieces
Tip R	Powdered high-speed steel	3	-	-	-	25 ～ 91.9	2 ～ 3	10	1 pieces
Tip R	Powdered high-speed steel	4	42 ～ 92	-	-	-	3 ～ 4	10	1 pieces
Tip R	Powdered high-speed steel	4	-	25 ～ 91.9	-	-	3 ～ 4	10	1 pieces
Tip R	Powdered high-speed steel	4	-	-	25 ～ 91.9	-	3 ～ 4	10	1 pieces
Tip R	Powdered high-speed steel	4	-	-	-	25 ～ 91.9	3 ～ 4	10	1 pieces
Tip R	Powdered high-speed steel	5	42 ～ 92	-	-	-	4 ～ 5	10	1 pieces
Tip R	Powdered high-speed steel	5	-	25 ～ 91.9	-	-	4 ～ 5	10	1 pieces
Tip R	Powdered high-speed steel	5	-	-	25 ～ 91.9	-	4 ～ 5	10	1 pieces
Tip R	Powdered high-speed steel	5	-	-	-	25 ～ 91.9	4 ～ 5	10	1 pieces
Tip R	Powdered high-speed steel	6	42 ～ 92	-	-	-	5 ～ 6	10	1 pieces
Tip R	Powdered high-speed steel	6	-	25 ～ 91.9	-	-	5 ～ 6	10	1 pieces
Tip R	Powdered high-speed steel	6	-	-	25 ～ 91.9	-	5 ～ 6	10	1 pieces
Tip R	Powdered high-speed steel	6	-	-	-	25 ～ 91.9	5 ～ 6	10	1 pieces
Tip R	Powdered high-speed steel	8	42 ～ 92	-	-	-	6 ～ 8	10	1 pieces
Tip R	Powdered high-speed steel	8	-	25 ～ 91.9	-	-	6 ～ 8	10	1 pieces
Tip R	Powdered high-speed steel	8	-	-	25 ～ 91.9	-	6 ～ 8	10	1 pieces
Tip R	Powdered high-speed steel	8	-	-	-	25 ～ 91.9	6 ～ 8	10	1 pieces
Tip R	Powdered high-speed steel	10	42 ～ 102	-	-	-	8 ～ 10	10	1 pieces
Tip R	Powdered high-speed steel	10	-	25 ～ 101.9	-	-	8 ～ 10	10	1 pieces
Tip R	Powdered high-speed steel	10	-	-	25 ～ 101.9	-	8 ～ 10	10	1 pieces
Tip R	Powdered high-speed steel	10	-	-	-	25 ～ 101.9	8 ～ 10	10	1 pieces
Tip R	Powdered high-speed steel	13	42 ～ 102	-	-	-	10 ～ 13	10	1 pieces
Tip R	Powdered high-speed steel	13	-	25 ～ 101.9	-	-	10 ～ 13	10	1 pieces
Tip R	Powdered high-speed steel	13	-	-	25 ～ 101.9	-	10 ～ 13	10	1 pieces
Tip R	Powdered high-speed steel	13	-	-	-	25 ～ 101.9	10 ～ 13	10	1 pieces
Tip R	Powdered high-speed steel	16	42 ～ 102	-	-	-	13 ～ 16	10	1 pieces
Tip R	Powdered high-speed steel	16	-	25 ～ 101.9	-	-	13 ～ 16	10	1 pieces
Tip R	Powdered high-speed steel	16	-	-	25 ～ 101.9	-	13 ～ 16	10	1 pieces
Tip R	Powdered high-speed steel	16	-	-	-	25 ～ 101.9	13 ～ 16	10	1 pieces
Tip R	Powdered high-speed steel	20	42 ～ 102	-	-	-	16 ～ 20	10	1 pieces
Tip R	Powdered high-speed steel	20	-	25 ～ 101.9	-	-	16 ～ 20	10	1 pieces
Tip R	Powdered high-speed steel	20	-	-	25 ～ 101.9	-	16 ～ 20	10	1 pieces
Tip R	Powdered high-speed steel	20	-	-	-	25 ～ 101.9	16 ～ 20	10	1 pieces
Tip R	Powdered high-speed steel	25	42 ～ 102	-	-	-	20 ～ 25	10	1 pieces
Tip R	Powdered high-speed steel	25	-	25 ～ 101.9	-	-	20 ～ 25	10	1 pieces
Tip R	Powdered high-speed steel	25	-	-	25 ～ 101.9	-	20 ～ 25	10	1 pieces
Tip R	Powdered high-speed steel	25	-	-	-	25 ～ 101.9	20 ～ 25	10	1 pieces
Tapered tip	Powdered high-speed steel	1.6	42 ～ 62	-	-	-	1 ～ 1.6	10	1 pieces
Tapered tip	Powdered high-speed steel	1.6	-	25 ～ 61.9	-	-	1 ～ 1.6	10	1 pieces
Tapered tip	Powdered high-speed steel	1.6	-	-	25 ～ 61.9	-	1 ～ 1.6	10	1 pieces
Tapered tip	Powdered high-speed steel	1.6	-	-	-	25 ～ 61.9	1 ～ 1.6	10	1 pieces
Tapered tip	Powdered high-speed steel	2.0	42 ～ 62	-	-	-	1 ～ 2	10	1 pieces
Tapered tip	Powdered high-speed steel	2.0	-	25 ～ 61.9	-	-	1 ～ 2	10	1 pieces
Tapered tip	Powdered high-speed steel	2.0	-	-	25 ～ 61.9	-	1 ～ 2	10	1 pieces
Tapered tip	Powdered high-speed steel	2.0	-	-	-	25 ～ 61.9	1 ～ 2	10	1 pieces
