Resin Rods/Transparent

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.

Resin Rods/Transparent:Related Image

TypeMaterialColor
RDJAAcrylic - StandardTransparent
RDJCPolycarbonate - Standard
The acrylic rod is made by machining the cast plate into a round rod and finished by centerless grinding.

Specifications

Part Number-L
RDJA3-250
Part NumberL
1mm increment
Unit Price
RDJARDJC
TypeDL10~100L101~200L201~400L401~600L10~100L101~200L201~400L401~600
RDJA
Acrylic - Standard
RDJC
Polycarbonate - Standard
310~250--
4
5
610~500
8
10
1210~600
13
15
16
18
20
25
30
The end face is not transparent because tooling marks remain on the surface.

Part Number:

  • Incomplete part number.
    Please use left hand selections to complete a part number.
Loading...
Part Number
RDJA3-[10-250/1]
RDJA4-[10-250/1]
RDJA5-[10-250/1]
RDJA6-[10-500/1]
RDJA8-[10-500/1]
RDJA10-[10-500/1]
RDJA12-[10-600/1]
RDJA13-[10-600/1]
RDJA15-[10-600/1]
RDJA16-[10-600/1]
RDJA18-[10-600/1]
RDJA20-[10-600/1]
RDJA25-[10-600/1]
RDJA30-[10-600/1]
RDJC3-[10-250/1]
RDJC4-[10-250/1]
RDJC5-[10-250/1]
RDJC6-[10-500/1]
RDJC8-[10-500/1]
RDJC10-[10-500/1]
RDJC12-[10-600/1]
RDJC13-[10-600/1]
RDJC15-[10-600/1]
RDJC16-[10-600/1]
RDJC18-[10-600/1]
RDJC20-[10-600/1]
RDJC25-[10-600/1]
RDJC30-[10-600/1]
Part NumberStandard Unit PriceVolume DiscountShipping Days?RoHSMaterial O.D. D
(Ø)
L
(mm)

-

3 Days 10Acrylic310 ~ 250

-

3 Days 10Acrylic410 ~ 250

-

3 Days 10Acrylic510 ~ 250

-

3 Days 10Acrylic610 ~ 500

-

3 Days 10Acrylic810 ~ 500

-

3 Days 10Acrylic1010 ~ 500

-

3 Days 10Acrylic1210 ~ 600

-

3 Days 10Acrylic1310 ~ 600

-

3 Days 10Acrylic1510 ~ 600

-

3 Days 10Acrylic1610 ~ 600

-

3 Days 10Acrylic1810 ~ 600

-

3 Days 10Acrylic2010 ~ 600

-

3 Days 10Acrylic2510 ~ 600

-

3 Days 10Acrylic3010 ~ 600

-

3 Days 10Polycarbonate310 ~ 250

-

3 Days 10Polycarbonate410 ~ 250

-

3 Days 10Polycarbonate510 ~ 250

-

3 Days 10Polycarbonate610 ~ 500

-

3 Days 10Polycarbonate810 ~ 500

-

3 Days 10Polycarbonate1010 ~ 500

-

3 Days 10Polycarbonate1210 ~ 600

-

3 Days 10Polycarbonate1310 ~ 600

-

3 Days 10Polycarbonate1510 ~ 600

-

3 Days 10Polycarbonate1610 ~ 600

-

3 Days 10Polycarbonate1810 ~ 600

-

3 Days 10Polycarbonate2010 ~ 600

-

3 Days 10Polycarbonate2510 ~ 600

-

3 Days 10Polycarbonate3010 ~ 600

Loading...

  1. 1

More Information

For characteristic values, see >> P.949.
