Miniature One-Touch Couplings / Union Tee
Click on this image to zoom in.
Click on this image to zoom in.
- Promotional pricing
- Volume Discount
[Features] Quick coupling type miniature. -Connection T-piece.
- Order quantities extended (D-JIT)
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Drawing / Specifications
- 3D Preview 3D preview is available after complete configuration
- Part Numbers
- More Information
- Catalog
Material: PBT (Polybutylene Terephthalate)
Specifications
| Part Number | - | Nominal Dia. |
| MNCN4 MNUN6 | - | M5 |
| Part Number | B | P | E | F1 | F2 | Mass (g) | Unit Price | Volume Discount Rate | |
| Type | D | 1 ~ 9 pc(s). | 10~50 | ||||||
| MNCLYT | 4 | 13.1 | 8 | 13.1 | 11.2 | 5.6 | 3.3 | ||
| 6 | 15 | 10.5 | 14.95 | 13.2 | 6.6 | 5.3 | |||
Part Number:
- In order to open the 3D preview, the part number must be fixed.
3D preview is not available, because the part number has not yet been determined.
Loading...
Loading...
More Information
Basic information
| Type | Single-Action Coupling | Fitting Type | Union, Equal Dia. | Applicable Fluid | Air |
|---|---|---|---|---|---|
| Main Body Material | PBT Polybutylene Terephthalate (Polybutylene Terephthalate) | Application | Standard, Mini | Thread Material | No Thread |
| Seal Material | Nitrile Rubber | Union: Same Diameter | Union Tees | Operating Temperature Range(°C) | 0::60 |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
