Perforated Metal / Standard

Perforated Metal / Standard

MISUMI

MISUMI

  • Order quantities extended (D-JIT)

(i)Remark

  • Cut edges may interrupt the perforations. (Cut location cannot be specified.)

Data sheet

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.

Perforated Metal/Standard:Related Image

Type   Material   Surface Treatment
PMSEN 1.0330 Equiv.Nickel Plating
PMUEN 1.4301 Equiv.-
PMALEN AW-1100 Equiv.-

Specifications

Part Number-A-B-T
PMS4-480-420-1.2
Part Number1mm IncrementT SelectionPMS, PMU, PMAL
TypeDABPMSPMUPMALPPerforated Rate (%)
PMS
PMU		150~70050~7000.5 0.8 0.5 0.8 -222.6
20.5 0.8 1.0 1.0 -340.2
31.0 1.2 1.6 1.0 1.2 1.5 -532.6
4729.6
5835.4
  8-1.5 -1334.3
PMAL3100~700100~700--1.0 2.0 532.6
5835.4
91532.6
  PMS8 is not available. (PMU8 is selectable.)
1mm IncrementPMS
ABD1D2D3D4D5
T=0.5T=0.8T=0.5T=0.8T=1.0T=1.0T=1.2T=1.6T=1.0T=1.2T=1.6T=1.0T=1.2T=1.6
50~10050~100
101~20050~100
101~200
201~30050~100
101~200
201~300
301~50050~100
101~200
201~300
301~400
401~500
501~70050~100
101~200
201~300
301~400
401~500
501~700

1mm IncrementPMU
ABD1D2D3D4D5D8
T=0.5T=0.8T=1.0T=1.0T=1.2T=1.5T=1.0T=1.2T=1.5T=1.0T=1.2T=1.5T=1.5
50~10050~100
101~20050~100
101~200
201~30050~100
101~200
201~300
301~50050~100
101~200
201~300
301~400
401~500
501~70050~100
101~200
201~300
301~400
401~500
501~700

1mm IncrementPMAL
ABD3D5D9
T=1.0T=2.0T=1.0T=2.0T=1.0T=2.0
100~200100~200
201~300100~200
201~300
301~500100~200
201~300
301~400
401~500
501~700100~200
201~300
301~400
401~500
501~700

Alterations

Perforated Metal/Standard:Related Image

Part Number:

    3D preview is not available, because the part number has not yet been determined.

  • In order to open the 3D preview, the part number must be fixed.
Loading...

Plug-in is required for 3D Preview

CAD Download

Data to be displayed
30
45
60
  1. 1
Part Number
PMAL3-[50-700/1]-[50-700/1]-[1,​2]
PMAL5-[50-700/1]-[50-700/1]-[1,​2]
PMAL9-[50-700/1]-[50-700/1]-[1,​2]
PMS1-[50-700/1]-[50-700/1]-[0.5,​0.8]
PMS2-[50-700/1]-[50-700/1]-[0.5,​0.8,​1]
PMS3-[50-700/1]-[50-700/1]-[1,​1.2,​1.6]
PMS4-[50-700/1]-[50-700/1]-[1,​1.2,​1.6]
PMS5-[50-700/1]-[50-700/1]-[1,​1.2,​1.6]
PMU1-[50-700/1]-[50-700/1]-[0.5,​0.8]
PMU2-[50-700/1]-[50-700/1]-1
PMU3-[50-700/1]-[50-700/1]-[1,​1.2,​1.5]
PMU4-[50-700/1]-[50-700/1]-[1,​1.2,​1.5]
PMU5-[50-700/1]-[50-700/1]-[1,​1.2,​1.5]
PMU8-[50-700/1]-[50-700/1]-1.5
Part NumberMinimum order quantityVolume Discount
Standard
Shipping Days
?
RoHSMaterial Punch Hole Dia. D
(φ) 		A
(mm) 		B
(mm) 		T
(mm)
1 8 Days 10EN AW-1100 Equiv.350 ～ 70050 ～ 7001 ～ 2
1 8 Days 10EN AW-1100 Equiv.550 ～ 70050 ～ 7001 ～ 2
1 8 Days 10EN AW-1100 Equiv.950 ～ 70050 ～ 7001 ～ 2
1 9 Days 10EN 1.0330 Equiv.150 ～ 70050 ～ 7000.5 ～ 0.8
1 9 Days 10EN 1.0330 Equiv.250 ～ 70050 ～ 7000.5 ～ 1
1 9 Days 10EN 1.0330 Equiv.350 ～ 70050 ～ 7001 ～ 1.6
1 9 Days 10EN 1.0330 Equiv.450 ～ 70050 ～ 7001 ～ 1.6
1 9 Days 10EN 1.0330 Equiv.550 ～ 70050 ～ 7001 ～ 1.6
1 7 Days 10EN 1.4301 Equiv.150 ～ 70050 ～ 7000.5 ～ 0.8
1 7 Days 10EN 1.4301 Equiv.250 ～ 70050 ～ 7001
1 7 Days 10EN 1.4301 Equiv.350 ～ 70050 ～ 7001 ～ 1.5
1 7 Days 10EN 1.4301 Equiv.450 ～ 70050 ～ 7001 ～ 1.5
1 7 Days 10EN 1.4301 Equiv.550 ～ 70050 ～ 7001 ～ 1.5
1 7 Days 10EN 1.4301 Equiv.850 ～ 70050 ～ 7001.5

Loading...

  1. 1

More Information

  A≥B   Cut edges may interrupt the perforations. (Cut location cannot be specified.)


Basic information

Specifications Round Hole 60ﾟ Staggered Type
