Pipe Nozzles / Steel Pipes for Air Nozzles

Mouse over image to enlarge

CatalogP.2-1474

Part number:

Still undefined. 40 possible part numbers found.

Outline drawing and specifications table
Part number list
More Information
Catalog

Outline drawing and specifications table

Pipe Nozzles/Steel Pipes for Air Nozzles:Related Image

Type		Material	Surface Treatment	Normal Pressure	Accessory:
Threaded and Tapped	Both Ends Tapped
AMR	AMF	EN 1.0305 Equiv.	Zinc Plating	0.7MPa	Tapered Screw Plug (EN 1.7220 Equiv., Black Oxide) 1 pc.
AMRS	AMFS	EN 1.4301 Equiv.	-		Tapered Screw Plug (EN 1.4567 Equiv.) 1 pc.

Accessory Tapered Screw Plug is seal-coated.

Specifications

Part Number	-	H (Number of Holes)	-	P	-	S	-	Q
AMR20A AMF20A	- -	1 8	-	P70	- -	S40 S35	- -	Q50 Q35

Part Number

Number of Side Tapped Holes H

Pitch P 1mm Increment

S, Q 1mm Increment

AMR, AMF Unit Price

AMRS, AMFS Unit Price

Type

No.

H1, 2

H3, 4

H5, 6

H7, 8

H9, 10

H1, 2

H3, 4

H5, 6

H7, 8

H9, 10

(Threaded and Tapped)
AMR
AMRS

(Both Ends Tapped)
AMF
AMFS

20A

1~10

60~80

35~80

When H (the number of side tapped holes) is 1, specifying Pitch P is not necessary.
