Stainless Steel Pipe Fittings / Union Elbow / 90 Deg.
Click on this image to zoom in.
Click on this image to zoom in.
- Promotional pricing ends 30/11/2024
- Volume Discount
- Order quantities extended (D-JIT)
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Drawing / Specifications
- 3D Preview 3D preview is available after complete configuration
- Part Numbers
- Catalog
Specifications
| Part Number | - | D1 |
| SKUSK6 SKUSDK12.7 | - | 6.35 |
| Part Number | L | E | F | ℓ | Square | Unit Price | Volume Discount Rate | ||
| Type | D | Main Body h | Nut H | 1 ~ 9 pc(s). | 10 ~ 30 pcs. | ||||
| SKUEK | 3.18 (1/8) | 24.9 | 2.5 | 13.4 | 18 | 12 | 12 | ||
| 4 | 27.8 | 3.5 | 15.3 | 20.5 | 14 | 14 | |||
| 6 | 27.9 | 5 | 15.4 | 20.5 | 14 | 14 | |||
| 6.35 (1/4) | 27.9 | 5 | 15.4 | 20.5 | 14 | 14 | |||
| 8 | 28.8 | 6 | 16.8 | 21 | 14 | 15.87 | |||
| 9.53 (3/8) | 30.8 | 8 | 17.8 | 23 | 17 | 19 | |||
| 10 | 30.8 | 8 | 17.8 | 23 | 17 | 19 | |||
| 12 | 34.8 | 10 | 22.8 | 24 | 22 | 23 | |||
| 12.7 (1/2) | 34.8 | 10 | 22.8 | 24 | 22 | 23 | |||
Values in ( ) for D dimension are by inch.
Part Number:
- In order to open the 3D preview, the part number must be fixed.
3D preview is not available, because the part number has not yet been determined.
Part Number
|
|---|
| SKUEK3.18 |
| SKUEK4 |
| SKUEK6 |
| SKUEK6.35 |
| SKUEK8 |
| SKUEK9.53 |
| SKUEK10 |
| SKUEK12 |
| SKUEK12.7 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | RoHS | Pipe O.D. D (A1) (Ø) | |
|---|---|---|---|---|---|---|
25.95 € | 1 | Available | 5 Days | 10 | 3.18 | |
25.33 € | 1 | Available | 5 Days | 10 | 4 | |
25.82 € | 1 | Available | 5 Days | 10 | 6 | |
25.82 € 18.07 € | 1 | Available |
Same day
Stock | 10 | 6.35 | |
26.19 € 18.33 € | 1 | Available |
Same day
Stock | 10 | 8 | |
26.19 € | 1 | Available | 5 Days | 10 | 9.53 | |
27.20 € | 1 | Available | 5 Days | 10 | 10 | |
44.84 € | 1 | Available | 5 Days | 10 | 12 | |
44.84 € | 1 | Available | 5 Days | 10 | 12.7 |
Loading...
Basic information
| Type | Fitting | Material | EN 1.4401 Equiv. | Applicable Fluid | Water / Air / Oil |
|---|---|---|---|---|---|
| Connection Type | Pipe-to-Pipe, Equal Diameter | Connection Type - Equal Diameter Tube | Union Elbows | Material of Applicable Pipe | Stainless Steel Pipes |
| Surface Treatment | Not Provided | Operating Temperature Range(°C) | -196::600 |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
