PVC Pipe Fittings / TS Fittings / Adhesive
Click image to view enlarged image
Part number:
possible part numbers found.Outline drawing and specifications table
Specification Table
| Part Number |
| PVCHSB20 PVCHBN100 |
| Part Number | Weight by Volume (g) | |
| Type | No. | |
| PVCTBN | 100 | 100 |
| 500 | 500 | |
| Part Number | Weight by Volume (g) | |
| Type | No. | |
| PVCHBN | 100 | 100 |
| 500 | 500 | |
How to Cut Off / How to Bond
● How to Cut Off
| By Electric Circular Saw | By Disk Sander | By PVC Pipe Saw |
 |  |  |
| Cut perpendicular to axis of pipe, using cut line as a guide. | ||
● How to Bond
| Cleaning | Applying Adhesive | Insertion | Completed | |||
 |  |  | |  | |  |
| Clean the inside of fittings and outer surface of insertion part with dry cloth. | Apply adhesive evenly with the inside of fittings, and then outer surface of insertion part in circular order. | Insert the pipe into the fitting up to the marking line in one stroke after applying adhesive, and hold it for 30 seconds or more. | Wipe off extra adhesive immediately, and prevent excessive pressure on the junction. |
More Information
Basic information
[Features] This PVC pipe adhesive is easy to handle and waterproof.
