Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Type | MX | L Dimension | Number of Blocks | Material Hardness | ||
Medium Load | Heavy Load | (Lubrication Units) | ||||
Block Standard | SVRN | SXRN | Blank: None -MX: Provided | Selectable | 1 | Carbon Steel 58HRC~ |
SV2RN | SX2RN | 2 | ||||
SVRNL | SXRNL | Configurable | 1 | |||
SV2RNL | SX2RNL | 2 |
Part Number | - | L | |
SVRN28 SVRN-MX28 RVRN28 SVRN28L SVRN28G | - - - - - | 880 880 880 880 880 | (With Lubrication Units) (LTBC Plating) (L Type Greased) (G Type Greased) |
Part Number | L | Block Dimension | Guide Rail Dimension | |||||||||||||||||||||||||||
Type | MX | H | W | L1 | B | C | S×ℓ | L2 | K | T | Cb | Grease Fitting | Dowel Hole Dimensions | H1 | W1 | W2 | Ca | Counterbored Hole | F | G | ||||||||||
Std. | MX | Mounting Hole | E | T1 | N | Øa | F | P | ℓ1 | d1xd2xh | ||||||||||||||||||||
Medium Load | (1 block) SVRN SVRNL | (2 blocks) SV2RN SV2RNL | Blank: None - MX: With MX | 24 | 100~1480 (160) | 34 | 41 | 50.6 | 26 | - | M4x7 | 25 | 20 | 7 | 0.85 | M5xP0.8 | 6 | 5 | 17 | 3 | - | - | 4 | 12.5 | 15 | 9.5 | 0.5 | 3.5x6x4.5 | 60 | 20 |
28 | 160~1960 (220) | 42 | 47 | 56.6 | 32 | - | M5x7.5 | 27.6 | 22.5 | 7.5 | 1 | M6xP0.75 | 13 | 6 | 21 | 4 | - | - | 5 | 15.5 | 20 | 11 | 0.6 | 6x9.5x8.5 | 60 | 20 | ||||
33 | 160~1960 (220) | 48 | 59 | 68.6 | 35 | - | M6x9 | 37 | 26.5 | 8 | 1 | M6xP0.75 | 13 | 6.8 | 24 | 4 | - | - | 5 | 18 | 23 | 12.5 | 0.8 | 7x11x9 | 60 | 20 | ||||
Heavy Load | (1 block) SXRN SXRNL | (2 blocks) SX2RN SX2RNL | 24 | 100~1480 (220) | 34 | 57 | 66.6 | 26 | 26 | M4x7 | 41 | 20 | 7 | 0.85 | M5xP0.8 | 6 | 5 | 17 | 3 | 4 | 24 | 4 | 12.5 | 15 | 9.5 | 0.5 | 3.5x6x4.5 | 60 | 20 | |
28 | 160~1960 (220) | 42 | 67 | 76.6 | 32 | 32 | M5x7.5 | 47.6 | 22.5 | 7.5 | 1 | M6xP0.75 | 13 | 6 | 21 | 4 | 5 | 28 | 5 | 15.5 | 20 | 11 | 0.6 | 6x9.5x8.5 | 60 | 20 | ||||
33 | 160~1960 (280) | 48 | 83 | 92.6 | 35 | 35 | M6x9 | 61 | 26.5 | 8 | 1 | M6xP0.75 | 13 | 6.8 | 24 | 4 | 5 | 35 | 5 | 18 | 23 | 12.5 | 0.8 | 7x11x9 | 60 | 20 |
H | L | Unit Price | |||
Medium Load | Heavy Load | ||||
1 block | 2 blocks | 1 block | 2 blocks | ||
SVRN | SV2RN | SXRN | SX2RN | ||
24 | 100 | - | - | ||
160 | - | ||||
220 | |||||
280 | |||||
340 | |||||
400 | |||||
460 | |||||
520 | |||||
580 | |||||
640 | |||||
700 | |||||
760 | |||||
820 | |||||
880 | |||||
940 | |||||
1000 | |||||
*1120 | |||||
*1240 | |||||
*1360 | |||||
*1480 | |||||
28 | 160 | - | - | ||
220 | |||||
280 | |||||
340 | |||||
400 | |||||
460 | |||||
520 | |||||
580 | |||||
640 | |||||
700 | |||||
760 | |||||
820 | |||||
880 | |||||
940 | |||||
1000 | |||||
*1120 | |||||
*1240 | |||||
*1360 | |||||
*1480 | |||||
*1600 | |||||
*1720 | |||||
*1840 | |||||
*1960 | |||||
33 | 160 | - | - | ||
220 | - | ||||
280 | |||||
340 | |||||
400 | |||||
460 | |||||
520 | |||||
580 | |||||
640 | |||||
700 | |||||
760 | |||||
820 | |||||
880 | |||||
940 | |||||
1000 | |||||
*1120 | |||||
*1240 | |||||
*1360 | |||||
*1480 | |||||
*1600 | |||||
*1720 | |||||
*1840 | |||||
*1960 |
H | Unit Price | |||
Medium Load | Heavy Load | |||
1 block | 2 blocks | 1 block | 2 blocks | |
SVRNL | SV2RNL | SXRNL | SX2RNL | |
24 | ||||
28 | ||||
33 |
H | Unit Price | |
1 block | 2 blocks | |
24 | ||
28 | ||
33 |
3D preview is not available, because the part number has not yet been determined.
Part Number
|
---|
SV2RN24-[160,220,280,340,400,460,520,580,640,700,760,820,880,940,1000,1120,1240,1360,1480] |
SV2RN24G-[160,220,280,340,400,460,520,580,640,700,760,820,880,940,1000,1120,1240,1360,1480] |
SV2RN24L-[160,220,280,340,400,460,520,580,640,700,760,820,880,940,1000,1120,1240,1360,1480] |
SV2RN28-[220,280,340,400,460,520,580,640,700,760,820,880,940,1000,1120,1240,1360,1480,1600,1720,1840,1960] |
SV2RN28G-[220,280,340,400,460,520,580,640,700,760,820,880,940,1000,1120,1240,1360,1480,1600,1720,1840,1960] |
SV2RN28L-[220,280,340,400,460,520,580,640,700,760,820,880,940,1000,1120,1240,1360,1480,1600,1720,1840,1960] |
SV2RN33-[220,280,340,400,460,520,580,640,700,760,820,880,940,1000,1120,1240,1360,1480,1600,1720,1840,1960] |
SV2RN33G-[220,280,340,400,460,520,580,640,700,760,820,880,940,1000,1120,1240,1360,1480,1600,1720,1840,1960] |
SV2RN33L-[220,280,340,400,460,520,580,640,700,760,820,880,940,1000,1120,1240,1360,1480,1600,1720,1840,1960] |
SV2RN-MX24-[160,220,280,340,400,460,520,580,640,700,760,820,880,940,1000,1120,1240,1360,1480] |
SV2RN-MX28-[220,280,340,400,460,520,580,640,700,760,820,880,940,1000,1120,1240,1360,1480,1600,1720,1840,1960] |
SV2RN-MX33-[220,280,340,400,460,520,580,640,700,760,820,880,940,1000,1120,1240,1360,1480,1600,1720,1840,1960] |
SV2RNL24-[161-1479/1] |
SV2RNL24G-[161-1479/1] |
SV2RNL24L-[161-1479/1] |
SV2RNL28-[221-1959/1] |
SV2RNL28G-[221-1959/1] |
SV2RNL28L-[221-1959/1] |
SV2RNL33-[221-1959/1] |
SV2RNL33G-[221-1959/1] |
SV2RNL33L-[221-1959/1] |
SV2RNL-MX24-[161-1479/1] |
SV2RNL-MX28-[221-1959/1] |
SV2RNL-MX33-[221-1959/1] |
SVRN24-[100,160,220,280,340,400,460,520,580,640,700,760,820,880,940,1000,1120,1240,1360,1480] |
SVRN24G-[100,160,220,280,340,400,460,520,580,640,700,760,820,880,940,1000,1120,1240,1360,1480] |
SVRN24L-[100,160,220,280,340,400,460,520,580,640,700,760,820,880,940,1000,1120,1240,1360,1480] |
SVRN28-[160,220,280,340,400,460,520,580,640,700,760,820,880,940,1000,1120,1240,1360,1480,1600,1720,1840,1960] |
SVRN28G-[160,220,280,340,400,460,520,580,640,700,760,820,880,940,1000,1120,1240,1360,1480,1600,1720,1840,1960] |
SVRN28L-[160,220,280,340,400,460,520,580,640,700,760,820,880,940,1000,1120,1240,1360,1480,1600,1720,1840,1960] |
SVRN33-[160,220,280,340,400,460,520,580,640,700,760,820,880,940,1000,1120,1240,1360,1480,1600,1720,1840,1960] |
SVRN33G-[160,220,280,340,400,460,520,580,640,700,760,820,880,940,1000,1120,1240,1360,1480,1600,1720,1840,1960] |
SVRN33L-[160,220,280,340,400,460,520,580,640,700,760,820,880,940,1000,1120,1240,1360,1480,1600,1720,1840,1960] |
SVRN-MX24-[100,160,220,280,340,400,460,520,580,640,700,760,820,880,940,1000,1120,1240,1360,1480] |
SVRN-MX28-[160,220,280,340,400,460,520,580,640,700,760,820,880,940,1000,1120,1240,1360,1480,1600,1720,1840,1960] |
SVRN-MX33-[160,220,280,340,400,460,520,580,640,700,760,820,880,940,1000,1120,1240,1360,1480,1600,1720,1840,1960] |
SVRNL24-[101-1479/1] |
SVRNL24G-[101-1479/1] |
SVRNL24L-[101-1479/1] |
SVRNL28-[161-1959/1] |
SVRNL28G-[161-1959/1] |
SVRNL28L-[161-1959/1] |
SVRNL33-[161-1959/1] |
SVRNL33G-[161-1959/1] |
SVRNL33L-[161-1959/1] |
SVRNL-MX24-[101-1479/1] |
SVRNL-MX28-[161-1959/1] |
SVRNL-MX33-[161-1959/1] |
SX2RN24-[160,220,280,340,400,460,520,580,640,700,760,820,880,940,1000,1120,1240,1360,1480] |
SX2RN24G-[160,220,280,340,400,460,520,580,640,700,760,820,880,940,1000,1120,1240,1360,1480] |
SX2RN24L-[160,220,280,340,400,460,520,580,640,700,760,820,880,940,1000,1120,1240,1360,1480] |
SX2RN28-[220,280,340,400,460,520,580,640,700,760,820,880,940,1000,1120,1240,1360,1480,1600,1720,1840,1960] |
SX2RN28G-[220,280,340,400,460,520,580,640,700,760,820,880,940,1000,1120,1240,1360,1480,1600,1720,1840,1960] |
SX2RN28L-[220,280,340,400,460,520,580,640,700,760,820,880,940,1000,1120,1240,1360,1480,1600,1720,1840,1960] |
SX2RN33-[220,280,340,400,460,520,580,640,700,760,820,880,940,1000,1120,1240,1360,1480,1600,1720,1840,1960] |
SX2RN33G-[220,280,340,400,460,520,580,640,700,760,820,880,940,1000,1120,1240,1360,1480,1600,1720,1840,1960] |
SX2RN33L-[220,280,340,400,460,520,580,640,700,760,820,880,940,1000,1120,1240,1360,1480,1600,1720,1840,1960] |
SX2RN-MX24-[160,220,280,340,400,460,520,580,640,700,760,820,880,940,1000,1120,1240,1360,1480] |
SX2RN-MX28-[220,280,340,400,460,520,580,640,700,760,820,880,940,1000,1120,1240,1360,1480,1600,1720,1840,1960] |
SX2RN-MX33-[220,280,340,400,460,520,580,640,700,760,820,880,940,1000,1120,1240,1360,1480,1600,1720,1840,1960] |
Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | RoHS | Rail Width W1 (mm) | Assembly Height H (mm) | No. of Blocks | Rail Length L (mm) | Nominal Part Number | Basic Load Rating: Dynamic Load (N) | Basic Load Rating: Static Load (N) | Allowable Static Moment MA (Nm) | Allowable Static Moment MB (Nm) | Allowable Static Moment MC (Nm) | Lubrication Type | L Dimension Type | |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
- | 1 | 7 Days | 10 | 15 | 24 | 2 | 160 ~ 1480 | 15 | 5000 | 8230 | 33 | 33 | 57 | Lithium Soap Base Grease filled | Selectable Type | ||
- | 1 | 7 Days | 10 | 15 | 24 | 2 | 160 ~ 1480 | 15 | 5000 | 8230 | 33 | 33 | 57 | Low Dust Generation Grease (G Type) | Selectable Type | ||
- | 1 | 7 Days | 10 | 15 | 24 | 2 | 160 ~ 1480 | 15 | 5000 | 8230 | 33 | 33 | 57 | Heat Resistant Grease (L Type) | Selectable Type | ||
- | 1 | 7 Days | 10 | 20 | 28 | 2 | 220 ~ 1960 | 20 | 7200 | 12100 | 58 | 58 | 135 | Lithium Soap Base Grease filled | Selectable Type | ||
- | 1 | 7 Days | 10 | 20 | 28 | 2 | 220 ~ 1960 | 20 | 7200 | 12100 | 58 | 58 | 135 | Low Dust Generation Grease (G Type) | Selectable Type | ||
- | 1 | 7 Days | 10 | 20 | 28 | 2 | 220 ~ 1960 | 20 | 7200 | 12100 | 58 | 58 | 135 | Heat Resistant Grease (L Type) | Selectable Type | ||
- | 1 | 7 Days | 10 | 23 | 33 | 2 | 220 ~ 1960 | 25 | 11700 | 19600 | 109 | 109 | 225 | Lithium Soap Base Grease filled | Selectable Type | ||
- | 1 | 7 Days | 10 | 23 | 33 | 2 | 220 ~ 1960 | 25 | 11700 | 19600 | 109 | 109 | 225 | Low Dust Generation Grease (G Type) | Selectable Type | ||
- | 1 | 7 Days | 10 | 23 | 33 | 2 | 220 ~ 1960 | 25 | 11700 | 19600 | 109 | 109 | 225 | Heat Resistant Grease (L Type) | Selectable Type | ||
- | 1 | 7 Days | 10 | 15 | 24 | 2 | 160 ~ 1480 | 15 | 5000 | 8230 | 33 | 33 | 57 | Lubrication Units | Selectable Type | ||
- | 1 | 7 Days | 10 | 20 | 28 | 2 | 220 ~ 1960 | 20 | 7200 | 12100 | 58 | 58 | 135 | Lubrication Units | Selectable Type | ||
- | 1 | 7 Days | 10 | 23 | 33 | 2 | 220 ~ 1960 | 25 | 11700 | 19600 | 109 | 109 | 225 | Lubrication Units | Selectable Type | ||
- | 1 | 7 Days | 10 | 15 | 24 | 2 | 161 ~ 1479 | 15 | 5000 | 8230 | 33 | 33 | 57 | Lithium Soap Base Grease filled | Configurable Type | ||
- | 1 | 7 Days | 10 | 15 | 24 | 2 | 161 ~ 1479 | 15 | 5000 | 8230 | 33 | 33 | 57 | Low Dust Generation Grease (G Type) | Configurable Type | ||
- | 1 | 7 Days | 10 | 15 | 24 | 2 | 161 ~ 1479 | 15 | 5000 | 8230 | 33 | 33 | 57 | Heat Resistant Grease (L Type) | Configurable Type | ||
- | 1 | 7 Days | 10 | 20 | 28 | 2 | 221 ~ 1959 | 20 | 7200 | 12100 | 58 | 58 | 135 | Lithium Soap Base Grease filled | Configurable Type | ||
- | 1 | 7 Days | 10 | 20 | 28 | 2 | 221 ~ 1959 | 20 | 7200 | 12100 | 58 | 58 | 135 | Low Dust Generation Grease (G Type) | Configurable Type | ||
- | 1 | 7 Days | 10 | 20 | 28 | 2 | 221 ~ 1959 | 20 | 7200 | 12100 | 58 | 58 | 135 | Heat Resistant Grease (L Type) | Configurable Type | ||
- | 1 | 7 Days | 10 | 23 | 33 | 2 | 221 ~ 1959 | 25 | 11700 | 19600 | 109 | 109 | 225 | Lithium Soap Base Grease filled | Configurable Type | ||
- | 1 | 7 Days | 10 | 23 | 33 | 2 | 221 ~ 1959 | 25 | 11700 | 19600 | 109 | 109 | 225 | Low Dust Generation Grease (G Type) | Configurable Type | ||
- | 1 | 7 Days | 10 | 23 | 33 | 2 | 221 ~ 1959 | 25 | 11700 | 19600 | 109 | 109 | 225 | Heat Resistant Grease (L Type) | Configurable Type | ||
- | 1 | 7 Days | 10 | 15 | 24 | 2 | 161 ~ 1479 | 15 | 5000 | 8230 | 33 | 33 | 57 | Lubrication Units | Configurable Type | ||
- | 1 | 7 Days | 10 | 20 | 28 | 2 | 221 ~ 1959 | 20 | 7200 | 12100 | 58 | 58 | 135 | Lubrication Units | Configurable Type | ||
- | 1 | 7 Days | 10 | 23 | 33 | 2 | 221 ~ 1959 | 25 | 11700 | 19600 | 109 | 109 | 225 | Lubrication Units | Configurable Type | ||
- | 1 | 7 Days | 10 | 15 | 24 | 1 | 100 ~ 1480 | 15 | 5000 | 8230 | 33 | 33 | 57 | Lithium Soap Base Grease filled | Selectable Type | ||
- | 1 | 7 Days | 10 | 15 | 24 | 1 | 100 ~ 1480 | 15 | 5000 | 8230 | 33 | 33 | 57 | Low Dust Generation Grease (G Type) | Selectable Type | ||
- | 1 | 7 Days | 10 | 15 | 24 | 1 | 100 ~ 1480 | 15 | 5000 | 8230 | 33 | 33 | 57 | Heat Resistant Grease (L Type) | Selectable Type | ||
- | 1 | 7 Days | 10 | 20 | 28 | 1 | 160 ~ 1960 | 20 | 7200 | 12100 | 58 | 58 | 135 | Lithium Soap Base Grease filled | Selectable Type | ||
- | 1 | 7 Days | 10 | 20 | 28 | 1 | 160 ~ 1960 | 20 | 7200 | 12100 | 58 | 58 | 135 | Low Dust Generation Grease (G Type) | Selectable Type | ||
- | 1 | 7 Days | 10 | 20 | 28 | 1 | 160 ~ 1960 | 20 | 7200 | 12100 | 58 | 58 | 135 | Heat Resistant Grease (L Type) | Selectable Type | ||
- | 1 | 7 Days | 10 | 23 | 33 | 1 | 160 ~ 1960 | 25 | 11700 | 19600 | 109 | 109 | 225 | Lithium Soap Base Grease filled | Selectable Type | ||
- | 1 | 7 Days | 10 | 23 | 33 | 1 | 160 ~ 1960 | 25 | 11700 | 19600 | 109 | 109 | 225 | Low Dust Generation Grease (G Type) | Selectable Type | ||
- | 1 | 7 Days | 10 | 23 | 33 | 1 | 160 ~ 1960 | 25 | 11700 | 19600 | 109 | 109 | 225 | Heat Resistant Grease (L Type) | Selectable Type | ||
- | 1 | 7 Days | 10 | 15 | 24 | 1 | 100 ~ 1480 | 15 | 5000 | 8230 | 33 | 33 | 57 | Lubrication Units | Selectable Type | ||
- | 1 | 7 Days | 10 | 20 | 28 | 1 | 160 ~ 1960 | 20 | 7200 | 12100 | 58 | 58 | 135 | Lubrication Units | Selectable Type | ||
- | 1 | 7 Days | 10 | 23 | 33 | 1 | 160 ~ 1960 | 25 | 11700 | 19600 | 109 | 109 | 225 | Lubrication Units | Selectable Type | ||
- | 1 | 7 Days | 10 | 15 | 24 | 1 | 101 ~ 1479 | 15 | 5000 | 8230 | 33 | 33 | 57 | Lithium Soap Base Grease filled | Configurable Type | ||
- | 1 | 7 Days | 10 | 15 | 24 | 1 | 101 ~ 1479 | 15 | 5000 | 8230 | 33 | 33 | 57 | Low Dust Generation Grease (G Type) | Configurable Type | ||
- | 1 | 7 Days | 10 | 15 | 24 | 1 | 101 ~ 1479 | 15 | 5000 | 8230 | 33 | 33 | 57 | Heat Resistant Grease (L Type) | Configurable Type | ||
- | 1 | 7 Days | 10 | 20 | 28 | 1 | 161 ~ 1959 | 20 | 7200 | 12100 | 58 | 58 | 135 | Lithium Soap Base Grease filled | Configurable Type | ||
- | 1 | 7 Days | 10 | 20 | 28 | 1 | 161 ~ 1959 | 20 | 7200 | 12100 | 58 | 58 | 135 | Low Dust Generation Grease (G Type) | Configurable Type | ||
- | 1 | 7 Days | 10 | 20 | 28 | 1 | 161 ~ 1959 | 20 | 7200 | 12100 | 58 | 58 | 135 | Heat Resistant Grease (L Type) | Configurable Type | ||
- | 1 | 7 Days | 10 | 23 | 33 | 1 | 161 ~ 1959 | 25 | 11700 | 19600 | 109 | 109 | 225 | Lithium Soap Base Grease filled | Configurable Type | ||
- | 1 | 7 Days | 10 | 23 | 33 | 1 | 161 ~ 1959 | 25 | 11700 | 19600 | 109 | 109 | 225 | Low Dust Generation Grease (G Type) | Configurable Type | ||
- | 1 | 7 Days | 10 | 23 | 33 | 1 | 161 ~ 1959 | 25 | 11700 | 19600 | 109 | 109 | 225 | Heat Resistant Grease (L Type) | Configurable Type | ||
- | 1 | 7 Days | 10 | 15 | 24 | 1 | 101 ~ 1479 | 15 | 5000 | 8230 | 33 | 33 | 57 | Lubrication Units | Configurable Type | ||
- | 1 | 7 Days | 10 | 20 | 28 | 1 | 161 ~ 1959 | 20 | 7200 | 12100 | 58 | 58 | 135 | Lubrication Units | Configurable Type | ||
- | 1 | 7 Days | 10 | 23 | 33 | 1 | 161 ~ 1959 | 25 | 11700 | 19600 | 109 | 109 | 225 | Lubrication Units | Configurable Type | ||
- | 1 | 7 Days | 10 | 15 | 24 | 2 | 160 ~ 1480 | 15 | 8600 | 14200 | 69 | 69 | 98 | Lithium Soap Base Grease filled | Selectable Type | ||
- | 1 | 7 Days | 10 | 15 | 24 | 2 | 160 ~ 1480 | 15 | 8600 | 14200 | 69 | 69 | 98 | Low Dust Generation Grease (G Type) | Selectable Type | ||
- | 1 | 7 Days | 10 | 15 | 24 | 2 | 160 ~ 1480 | 15 | 8600 | 14200 | 69 | 69 | 98 | Heat Resistant Grease (L Type) | Selectable Type | ||
- | 1 | 7 Days | 10 | 20 | 28 | 2 | 220 ~ 1960 | 20 | 12500 | 21300 | 155 | 155 | 232 | Lithium Soap Base Grease filled | Selectable Type | ||
- | 1 | 7 Days | 10 | 20 | 28 | 2 | 220 ~ 1960 | 20 | 12500 | 21300 | 155 | 155 | 232 | Low Dust Generation Grease (G Type) | Selectable Type | ||
- | 1 | 7 Days | 10 | 20 | 28 | 2 | 220 ~ 1960 | 20 | 12500 | 21300 | 155 | 155 | 232 | Heat Resistant Grease (L Type) | Selectable Type | ||
- | 1 | 7 Days | 10 | 23 | 33 | 2 | 220 ~ 1840 | 25 | 20200 | 34500 | 275 | 275 | 393 | Lithium Soap Base Grease filled | Selectable Type | ||
- | 1 | 7 Days | 10 | 23 | 33 | 2 | 220 ~ 1960 | 25 | 20200 | 34500 | 275 | 275 | 393 | Low Dust Generation Grease (G Type) | Selectable Type | ||
- | 1 | 7 Days | 10 | 23 | 33 | 2 | 220 ~ 1960 | 25 | 20200 | 34500 | 275 | 275 | 393 | Heat Resistant Grease (L Type) | Selectable Type | ||
- | 1 | 7 Days | 10 | 15 | 24 | 2 | 160 ~ 1480 | 15 | 8600 | 14200 | 69 | 69 | 98 | Lubrication Units | Selectable Type | ||
- | 1 | 7 Days | 10 | 20 | 28 | 2 | 220 ~ 1960 | 20 | 12500 | 21300 | 155 | 155 | 232 | Lubrication Units | Selectable Type | ||
- | 1 | 7 Days | 10 | 23 | 33 | 2 | 220 ~ 1840 | 25 | 20200 | 34500 | 275 | 275 | 393 | Lubrication Units | Selectable Type |
Loading...
Set / Single Item | Set | Block Type | Standard Blocks with Dowel Holes | Rail Type | Standard Rail |
---|---|---|---|---|---|
Material | Carbon steel | Preload | Normal Clearance | Accuracy Standards | Standard Grade |
Ball Arrangement | Medium, Heavy Load Type | Retainer | Not Provided | Rolling Element | Balls |
Configure
Basic Attributes
Rail Width W1(mm)
Assembly Height H(mm)
No. of Blocks
Rail Length L(mm)
[101-1959/1mm Unit(s)]
Nominal Part Number
Lubrication Type
L Dimension Type
Type
Filter by CAD data type
Filter by standard shipping days
Optional Attributes
