Floating Joints / T-Slots / (Through Hole Type) Tapped
- Promotional pricing ends 30/11/2024
- Volume Discount
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Drawing / Specifications
- 3D Preview 3D preview is available after complete configuration
- Part Numbers
- Catalog
| Type | Material | Surface Treatment |
| Through Hole Type | ||
| Tapped | ||
| FJW | EN 1.1191 Equiv. | Black Oxide |
Specifications
| Part Number |
| FJW10-1.25 |
| Part Number | D | P | W | B | L1 | L2 | T | h | ℓ | Tip Connection Joint D | |
| Type | M-Pitch | ||||||||||
| Through, Tapped FJW | 4-0.7 | 15 | 5 | 8 | 13 | 21 | 7 | 4 | 4 | 6 | 8 |
| 5-0.8 | 18 | 6 | 9 | 15 | 24 | 8 | 4 | 4 | 8 | 10 | |
| 6-1.0 | 20 | 7 | 11 | 17 | 29 | 9 | 5 | 5 | 10 | 12 | |
| 8-1.25 | 22 | 9 | 13 | 19 | 32 | 10 | 5 | 5 | 12 | 16 | |
| 10-1.25 | 28 | 12 | 17 | 25 | 38 | 11 | 6 | 6 | 15 | 20 | |
| 10-1.5 | 28 | 12 | 17 | 25 | - | - | 6 | 6 | - | 20 | |
| 14-1.5 | 33 | 15 | 21 | 30 | 44 | 13 | 6 | 6 | 21 | 25 | |
| 16-2.0 | 33 | 15 | 21 | 30 | - | - | 6 | 6 | - | 25 | |
Part Number:
- In order to open the 3D preview, the part number must be fixed.
3D preview is not available, because the part number has not yet been determined.
Part Number
|
|---|
| FJW4-0.7 |
| FJW5-0.8 |
| FJW6-1.0 |
| FJW8-1.25 |
| FJW10-1.25 |
| FJW14-1.5 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | RoHS | |
|---|---|---|---|---|---|
11.77 € | 1 | Available | 7 Days | 10 | |
13.16 € | 1 | Available | 7 Days | 10 | |
14.80 € | 1 | Available | 7 Days | 10 | |
16.08 € 11.26 € | 1 | Available |
Same day
Stock | 10 | |
17.96 € | 1 | Available | 7 Days | 10 | |
21.64 € | 1 | Available | 7 Days | 10 |
Loading...
Basic information
| Connection Type, Cylinder Side | Tapped |
|---|
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
